Ortronics EW3X0000714-A Citrix XFP Module - 10GbE LC Duplex 10GBase-LR Single-Mode 10 km
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This XFP transceiver operates on 10 Gigabit Ethernet standards, specifically implementing the 10GBase-LR protocol for long-reach single-mode fiber connections. The module features one LC duplex port, providing a standardized interface for fiber optic cabling.
It supports single-mode fiber media, which uses a single wavelength of light to transmit data with minimal signal loss over extended distances. The 10 km reach capability makes it ideal for campus, metro, and data center interconnects where longer fiber runs are necessary.
Key Product Advantages
The Ortronics Citrix XFP Module offers several advantages for network deployments requiring high-speed, long-distance fiber connectivity.
High-Speed Performance
Delivers full 10 Gbps data transfer rates, optimizing network performance for bandwidth-intensive applications and reducing bottlenecks in data-intensive environments.
- 10 Gigabit Ethernet technology
- 10GBase-LR protocol compliance
Extended Reach Capability
Supports transmission distances up to 10 kilometers over single-mode fiber, enabling connectivity across larger physical spaces without signal degradation.
- 10 km maximum distance
- Single-mode fiber optimization
Reliable Fiber Connectivity
Utilizes LC duplex connectors and single-mode fiber media for durable, low-loss connections that maintain signal integrity over long distances.
- LC duplex interface
- Minimal signal loss design
Deployment / Use Cases
This XFP module is designed for integration into network equipment supporting XFP interfaces, providing 10GbE connectivity for various optical networking scenarios.
Common deployment environments include data center interconnects linking switches or routers across different racks or buildings, campus networks connecting multiple buildings within an organization, and metro Ethernet applications requiring reliable long-distance fiber links.
Data Center Interconnects
Connect switches, routers, or servers across data center racks or between data center facilities using single-mode fiber infrastructure.
Campus & Metro Networks
Establish high-speed links between buildings or across metropolitan areas where 10 km reach meets typical distance requirements.
Physical Profile
The module features a compact XFP form factor measuring 0.33" (8.40 mm) in height, 0.64" (16.30 mm) in width, and 3.07" (78 mm) in depth. This standardized size ensures compatibility with XFP slots in network equipment from various manufacturers.
- Width
- 0.64" (16.30 mm)
- Depth
- 3.07" (78 mm)
- Height
- 0.33" (8.40 mm)
Highlights
- 10 Gigabit Ethernet XFP optical transceiver module
- 10GBase-LR technology for long-reach single-mode fiber
- LC duplex connector interface
- Supports up to 10 Gbps data transfer rate
- Maximum transmission distance of 10 kilometers
- Single-mode fiber media support
- Hot-pluggable design for easy installation
- Compact form factor for space-efficient deployment
- RoHS compliant for environmental safety
- Lifetime limited warranty
Specifications
| Specifications | |
|---|---|
| Manufacturer | Legrand Group |
| Manufacturer Part Number | EW3X0000714-A |
| Brand Name | Approved Networks |
| Product Name | Citrix XFP Module |
| Product Type | XFP |
| Technical Information | |
| Application/Usage | Optical Network,Data Networking |
| Interfaces/Ports | |
| Total Number of Ports | 1 |
| Connector Type | LC |
| Interfaces/Ports Details | 1 x LC Duplex 10GBase-LR Network |
| Media & Performance | |
| Media Type Supported | Optical Fiber |
| Fiber Mode Supported | Single-mode |
| Ethernet Technology | 10 Gigabit Ethernet |
| Network Technology | 10GBase-LR |
| Maximum Distance Supported | 10 km (6.21 Mile) |
| Maximum Data Transfer Rate | 10 Gbit/s |
| Physical Characteristics | |
| Height | 0.33" (8.40 mm) |
| Width | 0.64" (16.30 mm) |
| Depth | 3.07" (78 mm) |
| Miscellaneous | |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | Lifetime |
FAQ
What type of optical transceiver is the Ortronics EW3X0000714-A?
The Ortronics EW3X0000714-A is an XFP (10 Gigabit Small Form Factor Pluggable) optical transceiver module. It implements 10GBase-LR technology for 10 Gigabit Ethernet over single-mode fiber optic cables with LC duplex connectors, supporting data transfer rates up to 10 Gbps.
What distance can this XFP module support over fiber?
This XFP module supports transmission distances up to 10 kilometers (approximately 6.21 miles) over single-mode fiber optic cable. The 10GBase-LR technology is specifically designed for long-reach applications, making it suitable for campus, metro, and data center interconnects where extended fiber runs are required.
What type of fiber and connectors does this module use?
The module uses single-mode fiber optic media and features LC duplex connectors. Single-mode fiber employs a single wavelength of light for data transmission with minimal signal loss over long distances. The LC duplex connector interface provides a standardized, reliable connection for fiber optic cabling in network equipment.
