Ortronics 45W2812-A IBM XFP Module - 10GBase-ER LC Duplex Single-mode 40 km
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This XFP module operates on 10 Gigabit Ethernet technology, specifically using the 10GBase-ER standard for extended reach applications. It supports single-mode fiber optic media, which utilizes a single wavelength of light to transmit data over long distances with minimal signal loss.
The module's LC duplex connector ensures secure and stable optical connections, while its design complies with industry standards for interoperability and performance. With a maximum supported distance of 40 km (24.85 miles), it is suitable for metropolitan area networks, campus backbones, and other extended-reach scenarios.
Key Product Advantages
The Ortronics IBM XFP Module offers several advantages for network deployments. Its compatibility with IBM platforms ensures seamless integration into existing infrastructure, reducing compatibility concerns and simplifying procurement.
The use of single-mode fiber and 10GBase-ER technology provides a balance of high speed and long reach, supporting reliable performance over extended distances. The module's compact dimensions and standard XFP form factor allow for high-density installations in switches and routers.
Long-Distance Performance
Supports transmissions up to 40 km on single-mode fiber, making it ideal for connecting geographically dispersed network segments without intermediate equipment.
High-Speed Connectivity
Delivers 10 Gbit/s data transfer rates, providing the bandwidth necessary for data-intensive applications, server connections, and network aggregation.
Deployment / Use Cases
This XFP module is suited for various networking scenarios that require high-speed, long-distance optical connectivity. It can be deployed in enterprise networks to link core switches to distribution layers or to connect remote offices to central hubs.
In telecommunications, it supports carrier Ethernet services, backhaul links, and fiber-to-the-building applications. The module's reliability and performance make it a practical choice for network upgrades, expansions, or new installations where 10GbE over fiber is required.
Data Center Interconnects
Connect servers, storage arrays, and core switches within data centers or between data center sites using high-speed 10GbE links over single-mode fiber.
Metropolitan Area Networks
Extend network reach across campuses, business parks, or urban areas with 40 km capability, supporting applications like video surveillance, VoIP, and cloud access.
Physical Profile
The module has a compact design with dimensions of 0.33 inches in height, 0.64 inches in width, and 3.07 inches in depth (8.40 mm x 16.30 mm x 78 mm). This small form factor allows for efficient use of space in network equipment, supporting high-port-density configurations. The module is hot-pluggable, enabling installation or replacement without powering down the host device, which minimizes network downtime during maintenance or upgrades.
- Width
- 0.64" (16.30 mm)
- Depth
- 3.07" (78 mm)
- Height
- 0.33" (8.40 mm)
Highlights
- 10GBase-ER technology for 10 Gbit/s data transfer over optical fiber
- LC duplex connector for reliable single-mode fiber connections
- Supports maximum distances up to 40 km (24.85 miles)
- Compatible with IBM networking platforms
- Hot-pluggable XFP form factor for easy installation
- Single-mode fiber support for long-distance transmissions
- Compact dimensions for high-density deployments
- Lifetime limited warranty for long-term reliability
Specifications
| Specifications | |
|---|---|
| Manufacturer | Legrand Group |
| Manufacturer Part Number | 45W2812-A |
| Brand Name | Approved Networks |
| Product Name | IBM XFP Module |
| Product Type | XFP |
| Technical Information | |
| Application/Usage | Optical Network,Data Networking |
| Interfaces/Ports | |
| Total Number of Ports | 1 |
| Connector Type | LC |
| Interfaces/Ports Details | 1 x LC Duplex 10GBase-ER Network |
| Media & Performance | |
| Media Type Supported | Optical Fiber |
| Fiber Mode Supported | Single-mode |
| Ethernet Technology | 10 Gigabit Ethernet |
| Network Technology | 10GBase-ER |
| Maximum Distance Supported | 40 km (24.85 Mile) |
| Maximum Data Transfer Rate | 10 Gbit/s |
| Physical Characteristics | |
| Height | 0.33" (8.40 mm) |
| Width | 0.64" (16.30 mm) |
| Depth | 3.07" (78 mm) |
| Miscellaneous | |
| Country of Origin | China |
| Warranty | |
| Limited Warranty | Lifetime |
FAQ
What is the maximum data transfer rate of this XFP module?
This XFP module supports a maximum data transfer rate of 10 Gbit/s using 10 Gigabit Ethernet technology. It operates on the 10GBase-ER standard, which is designed for extended reach over single-mode fiber optic cables, providing high-speed connectivity for data-intensive network applications.
What type of fiber and connector does this module use?
The module uses single-mode fiber optic media and features an LC duplex connector. Single-mode fiber is optimized for long-distance transmissions with minimal signal loss, while the LC connector ensures a secure and stable optical interface for reliable network performance.
How far can this XFP module transmit data?
This module supports a maximum distance of 40 km (approximately 24.85 miles) over single-mode fiber. This extended reach makes it suitable for connecting network segments across campuses, metropolitan areas, or between data centers without requiring signal regeneration equipment.
Is this module compatible with IBM equipment?
Yes, this XFP module is designed for compatibility with IBM networking platforms. It can be used in IBM switches, routers, or other devices that support XFP transceivers, ensuring seamless integration into existing IBM-based network infrastructure.
