Chief FCAXV1U Fusion Wall Mount for Storage Box - Black - 55" to 100" Screen Support - 249. 12 lb Load Capacity
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This wall mount delivers precise mechanical performance with features like tilt, extension, and plumb adjustment, allowing for fine-tuning of the storage box position after installation. The recessed mount profile minimizes protrusion from the wall, contributing to a streamlined aesthetic while maintaining structural integrity. The construction supports heavy loads up to 249.12 pounds, ensuring stability for large screens and stored equipment.
Compatibility is a key technical aspect, with the mount designed to work with specific Chief wall storage boxes, including models PAC525, PAC526, and PAC527, as well as the Chief Proximity CSPR Component Storage Panel. This ensures a secure fit and optimal performance within Chief's ecosystem of mounting solutions.
Key Product Advantages
The Chief FCAXV1U offers significant advantages for AV integrators and IT professionals seeking a unified mounting and storage solution. Its high load capacity and broad screen size support make it versatile for various display types, from large monitors to digital signage.
Enhanced Organization
Integrates storage boxes directly into the mount, reducing clutter and improving cable management behind displays.
- Supports Chief storage boxes
- Keeps components accessible
Durable Construction
Built to handle heavy loads with a 10-year warranty, ensuring long-term reliability in commercial settings.
- 249.12 lb capacity
- Robust materials
Adjustable Design
Features tilt, extension, and plumb adjustment for precise positioning and easy maintenance access.
- Fine-tuning capabilities
- Recessed for clean look
Deployment / Use Cases
This wall mount is deployed in environments where display installation requires integrated storage for ancillary equipment. It is commonly used in corporate boardrooms, educational institutions, retail digital signage, and control rooms, where both visual display and equipment organization are priorities.
Typical use cases include mounting large interactive displays in classrooms with storage for media players, installing digital signage in retail stores with space for content devices, and setting up video walls in command centers with cable management solutions. The compatibility with Chief storage boxes ensures seamless integration into existing AV infrastructures, supporting efficient workflows and reducing installation time.
Highlights
- Supports storage boxes for integrated component organization
- Handles loads up to 249.12 lb (113000 g) for heavy displays
- Compatible with 55" to 100" screen sizes
- Features tilt, extension, and plumb adjustment for precise positioning
- Recessed mount profile for a clean, low-profile installation
- Black color blends with most AV setups
- Designed for Chief wall storage boxes (PAC525, PAC526, PAC527) and CSPR panel
- Backed by a 10-year limited warranty for long-term reliability
Specifications
| Specifications | |
|---|---|
| Manufacturer | Legrand Group |
| Manufacturer Part Number | FCAXV1U |
| Brand Name | Chief |
| Product Line | Fusion |
| Product Series | FCAXV1U |
| Product Name | Fusion 11.5" Pull Out Accessory - For Monitors 55-100" - Black |
| Product Type | Wall Mount |
| Product Information | |
| Device Supported | Storage Box |
| Maximum Load Capacity | 249.12 lb (113000 g) |
| Minimum Screen Size Supported | 55" |
| Maximum Screen Size Supported | 100" |
| Features | Tilt,Extendable,Adjustable,Plumb Adjustment |
| Mount Profile | Recessed |
| Physical Characteristics | |
| Product Color | Black |
| Miscellaneous | |
| Application/Usage | Wall |
| Compatibility | Chief Wall Storage Boxes: PAC525 PAC526 PAC527 Chief Proximity CSPR Component Storage Panel |
| Warranty | |
| Limited Warranty | 10 Year |
User Manual
FAQ
What types of devices does this wall mount support?
This wall mount is specifically designed to support storage boxes, not displays directly. It integrates with Chief wall storage boxes, such as models PAC525, PAC526, and PAC527, and the Chief Proximity CSPR Component Storage Panel, allowing you to organize cables, media players, or other equipment behind large screens.
What is the maximum load capacity of this mount?
The Chief FCAXV1U Fusion wall mount has a maximum load capacity of 249.12 pounds (113000 grams). This robust capacity ensures it can securely hold heavy storage boxes and the equipment inside them, making it suitable for demanding commercial AV installations.
What screen sizes are compatible with this mount?
This mount supports screens ranging from 55 inches to 100 inches in size. It is engineered to work with large displays commonly used in professional settings, such as digital signage or interactive monitors, providing a stable base for the integrated storage solution.
What adjustment features does this wall mount offer?
The mount includes tilt, extension, and plumb adjustment features. These allow for fine-tuning the position of the storage box after installation, ensuring optimal alignment and easy access to stored components, which is essential for maintenance and setup in AV environments.
Is this mount compatible with other brands of storage boxes?
No, this mount is specifically designed for compatibility with Chief brand storage boxes, including models PAC525, PAC526, PAC527, and the Chief Proximity CSPR Component Storage Panel. It is optimized to fit these products securely, so using non-Chief storage boxes may not provide a proper fit or performance.
What warranty comes with this wall mount?
The Chief FCAXV1U Fusion wall mount comes with a 10-year limited warranty. This extensive warranty period reflects the product's durability and reliability, offering peace of mind for long-term use in commercial or institutional applications where equipment longevity is critical.
