HPE P71682-005 ProLiant DL20 G11 Server - 1U Rack - Intel Xeon E-2436 2. 90 GHz Hexa-core - 32 GB DDR5 RAM - 1. 92 TB SSD (2 x 960GB)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The server's compute foundation centers on the Intel Xeon E-2436 processor, featuring six cores with a 2.90 GHz base frequency and 18 MB of L3 cache. This processor is paired with the Intel C262 chipset and supports DDR5 memory technology, providing improved bandwidth and efficiency over previous generations.
Storage architecture includes four internal 2.5" small form factor bays that support hot-swappable drives, plus one external 5.25" bay for additional expansion. The MR408i-o Gen11 controller manages both Serial ATA and 12Gb/s SAS interfaces, offering flexibility for mixed storage environments while supporting RAID configurations for data redundancy and performance optimization.
This section brings together practical product details such as Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The ProLiant DL20 G11 combines enterprise features with approachable deployment, making it suitable for organizations needing rack density without sacrificing management capabilities. Integrated Lights-Out (iLO) management provides comprehensive remote administration, while the server's security features help protect against firmware-level threats.
Built-in Security Framework
Hardware-level security includes UEFI Secure Boot, Immutable Silicon Root of Trust, TPM 2.0, and FIPS 140-2 validation. These features help establish a trusted computing base and protect against unauthorized firmware modifications.
- Secure firmware recovery mechanisms
- Smart card and Kerberos authentication support
- Configurable for PCI DSS compliance
Expansion Flexibility
Three PCI Express expansion slots (including PCIe 5.0 and OCP options) allow for network, storage, or specialized adapter additions. The five drive bays support various storage configurations to match workload requirements.
- PCIe 5.0 for high-bandwidth devices
- OCP slots for standardized network/storage cards
- Mixed drive bay options
Deployment / Use Cases
This server is well-suited for branch office deployments, remote site infrastructure, and departmental server consolidation where rack space is limited but performance requirements remain substantial. The 1U form factor allows efficient use of rack real estate while providing essential enterprise features.
Common deployment scenarios include virtualization hosts for small-scale VMware or Hyper-V environments, file and print servers for workgroup collaboration, and application servers for business software like accounting systems or CRM platforms. The server's support for multiple operating systems—including Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, and Ubuntu—provides flexibility for diverse IT environments.
Virtualization Platform
With six processor cores, substantial memory capacity, and fast SSD storage, the DL20 G11 can host multiple virtual machines for consolidated infrastructure at remote offices or smaller data centers.
Business Application Server
The reliable compute platform supports database applications, web servers, and line-of-business software with the redundancy features needed for business continuity.
Physical Profile
Designed for standard 19-inch racks, the DL20 G11 occupies just 1U of vertical space (1.70 inches/43.20 mm) while providing substantial compute and storage capabilities. The chassis measures 17.11 inches (434.60 mm) wide and 14.90 inches (378.40 mm) deep, with a weight of approximately 26.46 pounds (12,000 grams).
The compact footprint makes efficient use of rack space while still accommodating dual hot-swappable power supplies and multiple drive bays. The included bezel locking kit helps secure front-panel components in shared environments.
- Width
- 17.11" (434.60 mm)
- Depth
- 14.90" (378.40 mm)
- Height
- 1U
- Weight
- 26.46 lb (12000 g)
What's in the Box
The server ships with all necessary components for rack installation and initial operation.
Highlights
- Intel Xeon E-2436 hexa-core processor at 2.90 GHz with 18 MB cache
- 32 GB DDR5 ECC memory installed, expandable to 128 GB maximum
- 1.92 TB SSD storage via two 960GB Serial ATA solid-state drives
- MR408i-o Gen11 storage controller with RAID support for data protection
- Four internal 2.5" hot-swappable drive bays plus one external 5.25" bay
- 1U rack form factor with dual 500W hot-swappable redundant power supplies
- Integrated Lights-Out (iLO) remote management for comprehensive administration
- Four Gigabit Ethernet ports for network connectivity
- Support for Windows Server, Red Hat Enterprise Linux, SUSE Linux, and Ubuntu
- Three-year warranty with parts, labor, and next-business-day onsite support
Specifications
| Specifications | |
|---|---|
| Manufacturer | Hewlett Packard Enterprise |
| Manufacturer Part Number | P71682-005 |
| Brand Name | HPE |
| Product Line | ProLiant |
| Product Series | DL20 G11 |
| Product Name | ProLiant DL20 Gen11 Server |
| Product Type | Server |
| Processor | |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Type | Xeon |
| Processor Model | E-2436 |
| Processor Core | Hexa-core (6 Core) |
| Processor Speed | 2.90 GHz |
| Cache | 18 MB |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | C262 |
| Memory | |
| Standard Memory | 32 GB |
| Maximum Memory Supported | 128 GB |
| Memory Technology | DDR5 SDRAM |
| Number of Occupied Memory Slots | 1 |
| Error Checking | ECC |
| Signal Processing | Unregistered (Unbuffered) |
| Storage | |
| Number of Solid State Drives | 2 |
| Total Solid State Drive Capacity | 1.92 TB |
| Solid State Drive Interface | Serial ATA |
| Controllers | |
| Controller Type | Serial ATA,12Gb/s SAS |
| Controller Model | MR408i-o Gen11 |
| RAID Supported | Yes |
| I/O Expansions | |
| Number of Total Expansion Bays | 5 |
| Number of External 5.25" Bays | 1 |
| Number of Internal 2.5" Bays | 4 |
| Number of SFF Bays | 4 |
| Hot Swappable Bays | Yes |
| Total Number of Expansion Slots | 3 |
| PCI Express Details | 1x PCIe 5.0 CEM slot, 1 Internal OCP Storage Controller slot, 1 External OCP 3.0 Network Controller slot |
| Display & Graphics | |
| Graphics Controller Model | G200 |
| Graphics Memory Capacity | 16 MB |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Interfaces/Ports | |
| Total Number of USB Ports | 10 |
| Number of USB 2.0 Ports | 1 |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 4 |
| VGA | Yes |
| Remote Management | Yes |
| Remote Management Controller | iLO Management |
| DisplayPort | Yes |
| Operating System | |
| Operating System Supported | Windows Server,Red Hat Enterprise Linux,SuSE Linux Enterprise Server,Ubuntu |
| Power Description | |
| Input Voltage | 120 V AC,130 V AC |
| Number of Power Supplies Supported | 2 |
| Number of Power Supplies Installed | 2 |
| Plug/Connector Type | C13/C14 |
| Maximum Power Supply Wattage | 500 W |
| Redundant Power Supply | Yes |
| Hot Swappable Power Supply | Yes |
| Miscellaneous | |
| Package Contents | ProLiant DL20 Gen11 Server 6-foot IEC C-13/C-14 Jumper Cord Easy Install Rail 12 Kit |
| Security Features | UEFI Secure Boot and Secure Start support. Immutable Silicon Root of Trust FIPS 140-2 validation Common Criteria certification Configurable for PCI DSS compliance Advanced Encryption Standard (AES) and Triple Data Encryption Standard (3DES) on browser Support for Commercial National Security Algorithms (CNSA) iLO Security Modes Granular control over iLO interfaces Smart card (PIV/CAC) and Kerberos based 2-factor Authentication. Tamper-free updates - components digitally signed and verified. Secure Recovery - recover critical firmware to known good state on detection of compromised FW. Ability to rollback firmware Secure erase of NAND TPM (Trusted Platform Module) 2.0 Bezel Locking Kit |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Energy Efficiency Certification | ENERGY STAR 4.0 |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Physical Characteristics | |
| Form Factor | Rack |
| Rack Height | 1U |
| Height | 1.70" (43.20 mm) |
| Width | 17.11" (434.60 mm) |
| Depth | 14.90" (378.40 mm) |
| Weight (Approximate) | 26.46 lb (12000 g) |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | Server warranty includes 3-year parts, 3-year labor, 3-year onsite support with next business day response. |
User Manual
FAQ
What processor does this HPE ProLiant DL20 G11 server use?
The server features an Intel Xeon E-2436 processor with six cores (hexa-core) running at a base frequency of 2.90 GHz. This processor includes 18 MB of L3 cache and supports the Intel C262 chipset platform for enterprise workloads.
How much memory is installed and what is the maximum supported?
This configuration includes 32 GB of DDR5 SDRAM with ECC (error-correcting code) protection installed in one memory slot. The server supports up to 128 GB of total memory across its memory channels, providing substantial expansion capacity for memory-intensive applications.
What storage configuration comes with this server?
The server includes two 960GB solid-state drives configured for a total of 1.92 TB of storage capacity. These drives use Serial ATA interfaces and are managed by the MR408i-o Gen11 storage controller, which supports RAID configurations for data protection and performance optimization.
How many drive bays does the DL20 G11 have for expansion?
The server provides five total expansion bays: four internal 2.5" small form factor bays that support hot-swappable drives, plus one external 5.25" bay. The internal bays are designed for 2.5" drives and include hot-swap capability for maintenance without server downtime.
What remote management features are included?
HPE's Integrated Lights-Out (iLO) management controller provides comprehensive remote administration capabilities including power control, virtual media, remote console access, and health monitoring. The iLO interface supports secure authentication methods and is accessible through the server's dedicated management network port.
What operating systems are supported by this server?
The ProLiant DL20 G11 supports multiple enterprise operating systems including Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, and Ubuntu. This broad compatibility allows deployment in diverse IT environments with different platform preferences and application requirements.
What processor or CPU is listed for this server or storage platform?
This product uses the 1 processor for everyday performance and multitasking.
What processor speed is listed?
This product uses the 2.90 GHz processor for everyday performance and multitasking.
