HPE ProLiant DL320 G11 1U Rack Server - 1 Xeon Gold 5416S 2 GHz - 64 GB RAM - NVMe Controller - Intel C741 Chip - 1 Processor Support (P69302-005)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
- ProLiant DL320 G11 Server
- Rail Kit
- 6-foot IEC C-13/C-14 Jumper Cord
- UEFI Secure Boot and Secure Start support
- Tamper-free updates - components digitally signed and verified
- Immutable Silicon Root of Trust
- Ability to rollback firmware
- FIPS 140-2 validation
- Secure erase of NAND/User data
- Common Criteria certification
- Configurable for PCI DSS compliance
- Embedded TPM (Trusted Platform Module) 2.0. Excluded for shipments to China.
- Advanced Encryption Standard (AES) and Triple Data Encryption Standard (3DES) on browser
- Bezel Locking Kit option
- Support for Commercial National Security Algorithms (CNSA)
- Chassis Intrusion detection option
- Secure Recovery - recover critical firmware to a known good state on detection of compromised firmware
Number of Processors Supported: 1
Number of Processors Installed: 1
Processor Type: Xeon Gold
Processor Generation: 4th Gen
Processor Model: 5416S
Processor Core: Hexadeca-core (16 Core)
Processor Speed: 2 GHz
Cache: 30 MB
Chipset Manufacturer: Intel
Chipset Model: C741
Standard Memory: 64 GB
Maximum Memory Supported: 2.04 TB
Memory Technology: DDR5 SDRAM
Total Number of Memory Slots: 16
Number of Occupied Memory Slots: 2
Error Checking: ECC
Signal Processing: Registered (Buffered)
Controller Type: NVMe
Controller Model: NS204i-u
Number of Total Expansion Bays: 9
Number of Internal 2.5" Bays: 8
Number of Media Drive Bays: 1
Number of SFF Bays: 8
Hot Swappable Bays: Yes
Total Number of Expansion Slots: 2
PCI Express Details: 1 x16 FHHL PCIe Gen5; 1 OCP 3.0 Slot as default. 1 x16 FHHL PCIe Gen5 optional
Graphics Memory Capacity: 16 MB
Ethernet Technology: Gigabit Ethernet
Total Number of USB Ports: 4
Network (RJ-45): Yes
Number of Network (RJ-45) Ports: 2
VGA: Yes
Remote Management: Yes
Remote Management Controller: HPE iLO6
Operating System Supported: Windows Server,Red Hat Enterprise Linux,SuSE Linux Enterprise Server,Ubuntu,Oracle Linux,Citrix XenServer,CentOS
Input Voltage: 120 V AC,230 V AC
Number of Power Supplies Supported: 2
Number of Power Supplies Installed: 2
Plug/Connector Type: C13/C14
Maximum Power Supply Wattage: 800 W
Redundant Power Supply: Yes
Hot Swappable Power Supply: Yes
Package Contents:
Security Features:
Energy Star: Yes
Environmentally Friendly: Yes
Energy Efficiency Certification: ENERGY STAR 4.0
Energy Efficiency Compliance: Energy-related Products Directive Lot 9 (ErP Lot 9)
Environmental Compliance: Waste Electrical and Electronic Equipment Directive (WEEE)
Form Factor: Rack
Rack Height: 1U
Height: 1.69" (42.80 mm)
Width: 17.11" (434.60 mm)
Depth: 23.82" (605.10 mm)
Weight (Approximate): 36.84 lb (16710 g)
Limited Warranty: 3 Year
Additional Warranty Information:
3-year parts, 3-year labor, 3-year onsite support with next business day response.
- 1 processors supported for optimal performance and maximum reliability in mission-critical server environments
- 64 GB powerful memory for any computational task
- 800 W power supply unit (PSU) fulfills system power needs, ensuring smooth operation under heavy workloads
- Xeon Gold 2 GHz processor handles computing tasks effectively for better productivity
- Rack form factor delivers added reliability and structural integrity, supporting consistent performance in enterprise setups
- 4th Gen server generation improves power efficiency and ensures long-lasting reliability
- With DDR5 SDRAM memory technology, achieve faster data rates and enhanced system responsiveness for enterprise applications
- Gigabit Ethernet is ideal for frequent large file transfers, such as backups and replication, ensuring smooth and efficient operations
- 2 Network (RJ-45) Ports simplify integration and enable powered devices in areas without dedicated electrical circuits
- 4 USB ports provide a refined design and safer connectivity, ensuring reliable and secure device connections every time
[custom-specifications]
| Specifications | |
| Manufacturer | Hewlett Packard Enterprise |
| Manufacturer Part Number | P69302-005 |
| Manufacturer Website Address | http://www.hpe.com |
| Brand Name | HPE |
| Product Line | ProLiant |
| Product Series | DL320 G11 |
| Product Name | ProLiant DL320 G11 Server |
| Product Type | Server |
| Processor | |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Type | Xeon Gold |
| Processor Generation | 4th Gen |
| Processor Model | 5416S |
| Processor Core | Hexadeca-core (16 Core) |
| Processor Speed | 2 GHz |
| Cache | 30 MB |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | C741 |
| Memory | |
| Standard Memory | 64 GB |
| Maximum Memory Supported | 2.04 TB |
| Memory Technology | DDR5 SDRAM |
| Total Number of Memory Slots | 16 |
| Number of Occupied Memory Slots | 2 |
| Error Checking | ECC |
| Signal Processing | Registered (Buffered) |
| Controllers | |
| Controller Type | NVMe |
| Controller Model | NS204i-u |
| I/O Expansions | |
| Number of Total Expansion Bays | 9 |
| Number of Internal 2.5" Bays | 8 |
| Number of Media Drive Bays | 1 |
| Number of SFF Bays | 8 |
| Hot Swappable Bays | Yes |
| Total Number of Expansion Slots | 2 |
| PCI Express Details | 1 x16 FHHL PCIe Gen5; 1 OCP 3.0 Slot as default. 1 x16 FHHL PCIe Gen5 optional |
| Display & Graphics | |
| Graphics Memory Capacity | 16 MB |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Interfaces/Ports | |
| Total Number of USB Ports | 4 |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 2 |
| VGA | Yes |
| Remote Management | Yes |
| Remote Management Controller | HPE iLO6 |
| Operating System | |
| Operating System Supported | Windows Server,Red Hat Enterprise Linux,SuSE Linux Enterprise Server,Ubuntu,Oracle Linux,Citrix XenServer,CentOS |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Number of Power Supplies Supported | 2 |
| Number of Power Supplies Installed | 2 |
| Plug/Connector Type | C13/C14 |
| Maximum Power Supply Wattage | 800 W |
| Redundant Power Supply | Yes |
| Hot Swappable Power Supply | Yes |
| Miscellaneous | |
| Package Contents |
|
| Security Features |
|
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Energy Efficiency Certification | ENERGY STAR 4.0 |
| Energy Efficiency Compliance | Energy-related Products Directive Lot 9 (ErP Lot 9) |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Physical Characteristics | |
| Form Factor | Rack |
| Rack Height | 1U |
| Height | 1.69" (42.80 mm) |
| Width | 17.11" (434.60 mm) |
| Depth | 23.82" (605.10 mm) |
| Weight (Approximate) | 36.84 lb (16710 g) |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | 3-year parts, 3-year labor, 3-year onsite support with next business day response. |
