IOGEAR GWLRSSKIT4K Long Range Wireless 4K Video Transmitter/Receiver Kit - 1 Input - 2 Output - 600 ft Range - Local Passthrough
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This wireless video extender operates on robust wireless technology with built-in MIMO for stable signal transmission. The system supports video resolutions from standard 640x480 up to 4K Ultra HD at 4096x2160, with wireless transmission at 30Hz and wired passthrough at 60Hz for local monitors.
Connectivity options include HDMI inputs and outputs, USB ports for remote console functionality, network RJ-45 ports for integration with control systems, and RS-232 serial control for projector and display management. The IR extender system enables remote control of source devices from display locations.
Relevant factors for this section include Connectivity Technology, Number of Input Devices Supported, Number of Output Devices Supported, Graphics Modes. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The GWLRSSKIT4K distinguishes itself through operational versatility and professional-grade performance. The dual-mode functionality allows the same hardware to serve as either a multi-source switcher or single-source splitter, adapting to changing installation requirements without additional equipment.
Extended Control Capabilities
RS-232 serial control extends command functionality to compatible projectors and displays, while the IR extender system maintains remote control of source devices from display locations.
- RS-232 port for device control
- IR receiver and emitter cables included
- Remote source control capability
Remote Console Functionality
Two dedicated USB ports enable keyboard and mouse connection for remote computer control, allowing users to operate source PCs or laptops from display locations.
- Two USB ports for peripherals
- Remote PC/laptop control
- Keyboard and mouse support
Deployment / Use Cases
This wireless video extender kit serves professional AV installations where cable runs are impractical or aesthetically undesirable. The 600-foot operating range makes it suitable for large venues, educational facilities, corporate environments, and residential whole-home distribution systems.
Common applications include conference room presentations where presenters need to share content from laptops to multiple displays, digital signage distribution across retail spaces, auditorium and lecture hall installations, and home theater systems where source equipment must remain concealed while delivering content to multiple viewing areas.
Commercial Presentation Environments
Enable presenters to share laptop or media player content wirelessly to projectors and displays throughout meeting spaces without cable limitations.
- Conference room presentations
- Training facility content sharing
- Boardroom display distribution
Digital Signage Distribution
Distribute content from a single media player to multiple displays across retail stores, lobbies, or transportation hubs without extensive cabling infrastructure.
- Retail store signage
- Hotel lobby displays
- Airport information screens
What's in the Box
The complete kit includes all necessary components for immediate deployment. Each package contains the transmitter and receiver units, power supplies, connectivity cables, mounting hardware, and documentation for straightforward setup.
Highlights
- Wireless 4K video transmission up to 600 feet operating distance
- Supports switch mode (10 transmitters to 1 receiver) or splitter mode (1 transmitter to 4 receivers)
- Maximum 4K wireless resolution of 4096x2160@30Hz
- Local HDMI passthrough supports 4096x2160@60Hz for direct monitor connection
- IR extender enables remote control of video source from display location
- RS-232 port extends control to compatible projectors and displays
- Remote Console feature with 2 USB ports for keyboard and mouse control
- Auxiliary audio input and output for external speaker or amplifier connection
- Supports HDMI resolutions from 640x480 to 4096x2160@60Hz
- Includes mounting kits for flexible installation options
Specifications
| Specifications | |
|---|---|
| Manufacturer | IOGEAR, Inc |
| Manufacturer Part Number | GWLRSSKIT4K |
| Brand Name | IOGEAR |
| Product Model | GWLRSSKIT4K |
| Product Name | Long Range Wireless 4K Video Transmitter and Receiver Kit with Local Passthrough |
| Packaged Quantity | 1 |
| Product Type | Video Extender Transmitter/Receiver |
| Technical Information | |
| Connectivity Technology | Wireless |
| Number of Input Devices Supported | 1 |
| Number of Output Devices Supported | 2 |
| Maximum Operating Distance | 600 ft (182880 mm) |
| Video | |
| Graphics Modes | 4K |
| Maximum Video Resolution | 4096 x 2160 |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| HDMI In | Yes |
| HDMI Out | Yes |
| USB | Yes |
| Number of Network (RJ-45) Ports | 2 |
| Number of USB Ports | 3 |
| Number of HDMI Inputs | 1 |
| Number of HDMI Outputs | 2 |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Transmitter Height | 1" (25.40 mm) |
| Transmitter Width | 2.50" (63.50 mm) |
| Transmitter Depth | 9.75" (247.65 mm) |
| Receiver Height | 1" (25.40 mm) |
| Receiver Width | 2.50" (63.50 mm) |
| Receiver Depth | 9.75" (247.65 mm) |
| Transmitter Weight (Approximate) | 11.20 oz (317.51 g) |
| Receiver Weight (Approximate) | 11.20 oz (317.51 g) |
| Miscellaneous | |
| Package Contents | 1 x Transmitter 1 x Receiver 2 x 12V/1A Power Supply 4 x Antennas 2 x Mounting Kits 1 x IR Receiver Cable 1 x IE Emitter Cable 2 x HDMI Cables 1 x USB-A Male to USB-A Male Cable 1 x Quick Start Guide for Transmitter 1 x Quick Start Guide for Receiver 2 x Warranty Cards |
| Environmentally Friendly | Yes |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE),Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 1 Year |
User Manual
FAQ
What is the maximum wireless transmission distance for this video extender kit?
The IOGEAR GWLRSSKIT4K provides wireless video transmission up to 600 feet (approximately 182 meters) under optimal conditions. This extended range utilizes built-in MIMO technology to maintain signal integrity across large spaces, making it suitable for auditoriums, conference centers, and distributed display installations where long-distance wireless transmission is required.
How many displays can this wireless video extender support simultaneously?
This system supports two output devices in its standard configuration. However, when configured in splitter mode, it can distribute a single source to up to four receivers. The kit's operational flexibility allows it to function as either a 1-input, 2-output extender or be reconfigured for different distribution scenarios based on installation requirements.
What video resolutions does this wireless extender support?
The GWLRSSKIT4K supports a wide range of HDMI video resolutions from standard definition 640x480 up to 4K Ultra HD at 4096x2160. Wireless transmission operates at 30Hz for 4K content, while the local passthrough connection supports 4K at 60Hz for directly connected monitors. This comprehensive resolution support ensures compatibility with most modern video sources and displays.
What control options are available with this video extender system?
The system includes multiple control options: an IR extender for remote control of source devices from display locations, RS-232 serial control for compatible projectors and displays, and a Remote Console feature with two USB ports for keyboard and mouse connection to control source computers remotely. These integrated control capabilities simplify system operation in professional installations.
Does this kit include everything needed for installation?
Yes, the complete kit includes all necessary components: transmitter and receiver units, two 12V/1A power supplies, four antennas, two mounting kits, IR receiver and emitter cables, two HDMI cables, a USB-A male-to-male cable, quick start guides for both units, and warranty cards. The comprehensive package enables immediate deployment without requiring additional purchases for basic installation.
What is the difference between switch mode and splitter mode operation?
Switch mode configures the system to support multiple sources (up to 10 transmitters) connecting to a single receiver, ideal for presentation environments with multiple input devices. Splitter mode enables a single transmitter to distribute content to multiple receivers (up to 4), perfect for digital signage or multi-room distribution from one source. The same hardware supports both configurations based on setup parameters.
