NEC Display NP-PA1505UL-B Professional LCD Projector - 15000 Lumens - WUXGA 1920 x 1200 - Laser - Ceiling Mountable - Black
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Product Overview
The NEC Display NP-PA1505UL-B is a professional-grade LCD projector engineered for demanding large-venue installations where consistent, high-brightness performance is non-negotiable. Its 15,000-lumen laser light source ensures vivid, detailed imagery even in well-lit environments, making it a reliable choice for corporate auditoriums, educational facilities, and event spaces.
Designed with installation flexibility in mind, this projector supports front, rear, front-ceiling, and rear-ceiling projection methods. The WUXGA native resolution (1920 x 1200) provides a 16:10 aspect ratio, delivering ample screen real estate for detailed presentations, data visualization, and high-definition video content. With a maximum supported resolution of 4096 x 2160, it is ready for future content standards.
Relevant factors for this section include Projection Method, Native Resolution, Graphic Mode, Maximum Resolution. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Technical Overview
At the core of the NP-PA1505UL-B is a laser phosphor illumination system rated for 20,000 hours of operation in normal mode, significantly reducing long-term maintenance and lamp replacement costs compared to traditional lamp-based projectors. This solid-state light source provides immediate on/off capability and maintains consistent brightness and color output throughout its lifespan.
The projector's imaging engine delivers a 3,000,000:1 contrast ratio, producing deep blacks and bright highlights for enhanced image depth. It accepts HDTV signals and outputs a 1080p scan format, ensuring compatibility with common video sources. A comprehensive set of connectivity options includes HDMI, 3G-SDI, USB, and wired network (RJ-45) ports for seamless integration into professional AV systems.
Relevant factors for this section include Projection Method, Native Resolution, Graphic Mode, Maximum Resolution. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
This projector combines exceptional light output with long-term reliability, offering a total cost of ownership advantage for institutional buyers. The laser engine eliminates the frequent lamp replacements associated with high-use scenarios, while the 15,000-lumen brightness ensures content remains visible and impactful in challenging lighting conditions.
Installation Versatility
The ceiling-mountable form factor and support for multiple projection orientations allow integrators to deploy the unit in various room layouts, from traditional front projection to rear-projection setups for permanent installations.
- Front/Rear/Ceiling projection
- Integrated mounting points
- Black finish for discreet blending
Professional Connectivity Suite
Beyond standard HDMI, the inclusion of 3G-SDI provides a robust, long-distance digital video interface preferred in broadcast and pro-AV environments, while the network port enables remote monitoring and control.
- 3G-SDI for professional video
- HDMI for consumer sources
- RJ-45 for IP-based management
Deployment / Use Cases
The NP-PA1505UL-B is purpose-built for fixed installations where performance and durability are paramount. Its high brightness and laser reliability make it suitable for venues that operate for extended hours or require consistent image quality over many years.
In higher education, this projector can illuminate large lecture halls or auditoriums with detailed schematics, video lectures, and guest presentations. Corporate training centers and boardrooms benefit from its ability to handle detailed financial charts, engineering diagrams, and video conferencing content with clarity. For large venues like houses of worship or performing arts centers, it delivers bright, stable imagery for live events, broadcasts, and informational displays.
Physical Profile
The projector features a substantial, industrial-grade chassis measuring 23.60" W x 9.40" D x 19.30" H (599 x 239 x 490 mm) and weighing approximately 63.3 pounds (28.7 kg). Its black finish and clean lines are designed for discreet integration into ceiling mounts or custom enclosures. The form factor is explicitly designed for ceiling mounting, with appropriate mounting points and orientation flexibility built-in for professional installers.
- Width
- 23.60" (599.44 mm)
- Depth
- 9.40" (238.76 mm)
- Height
- 19.30" (490.22 mm)
- Weight
- 63.30 lb (28712.40 g)
What's in the Box
The projector ships with essential accessories for initial setup and operation.
Highlights
- 15,000-lumen laser light source for exceptional brightness
- WUXGA native resolution (1920x1200) with 16:10 aspect ratio
- Long-life laser engine rated for 20,000 hours of operation
- 3,000,000:1 contrast ratio for superior image depth
- Flexible installation supports front, rear, and ceiling projection
- Professional connectivity includes HDMI, 3G-SDI, USB, and RJ-45
- Ceiling-mountable black chassis for discreet integration
- 5-year or 20,000-hour limited warranty with next-business-day exchange
Specifications
| Specifications | |
|---|---|
| Manufacturer | Sharp |
| Manufacturer Part Number | NPPA1505ULB |
| Brand Name | NEC Display |
| Product Series | NP |
| Product Model | NP-PA1505UL-B |
| Product Name | 15,000-Lumen Professional Installation Projector |
| Product Type | LCD Projector |
| Technical Information | |
| Projection Method | Front,Rear,Front Ceiling,Rear Ceiling |
| Display & Graphics | |
| Native Resolution | 1920 x 1200 |
| Graphic Mode | WUXGA |
| Maximum Resolution | 4096 x 2160 |
| Native Aspect Ratio | 16:10 |
| Projection Lens | |
| Maximum Diagonal Image Size | 41.67 ft (12700 mm) |
| Lamp | |
| Number of Lamps | 1 |
| Lamp Type | Laser |
| Normal Mode Lamp Life | 20000 Hour |
| Image | |
| Standard Mode Brightness | 15000 lm |
| Contrast Ratio | 3,000,000:1 |
| Video | |
| Video Signal Standard | HDTV |
| Output Scan Format | 1080p |
| Interfaces/Ports | |
| HDMI | Yes |
| SDI Standard | 3G-SDI |
| USB | Yes |
| Network (RJ-45) | Yes |
| Power Description | |
| Operating Power Consumption | 960 W |
| Physical Characteristics | |
| Product Color | Black |
| Form Factor | Ceiling Mountable |
| Height | 19.30" (490.22 mm) |
| Width | 23.60" (599.44 mm) |
| Depth | 9.40" (238.76 mm) |
| Weight (Approximate) | 63.30 lb (28712.40 g) |
| Miscellaneous | |
| Application/Usage | Education,Corporate,Class Room,Meeting,Room,Auditorium,Large Venue |
| Package Contents | 15,000-Lumen Professional Installation Projector Remote Control Batteries Power Cord Lens Hole Cap User Manual (Web Download) Installation Manual (Web Download) Quick Start Guide Important Information Product registration Card Lens Anti-Theft Screw Security Sticker |
| Warranty | |
| Limited Warranty | 5 Year |
| Additional Warranty Information | Registered owners receive a 5-year or 20,000 hours parts and labor warranty including instacare next business day exchange. |
User Manual
FAQ
What is the brightness of the NEC NP-PA1505UL-B projector?
The projector delivers 15,000 lumens of brightness in standard mode. This high light output is designed for large venues like auditoriums, lecture halls, and corporate spaces where ambient light is present, ensuring vivid and clearly visible images.
What type of light source does this projector use?
It uses a laser phosphor light source. This solid-state technology offers a rated lamp life of 20,000 hours in normal mode, providing long-term reliability and significantly reducing maintenance costs associated with traditional lamp replacements.
What is the native resolution and aspect ratio?
The native resolution is 1920 x 1200, which is the WUXGA standard. This provides a 16:10 aspect ratio, offering more vertical screen space than standard 16:9 widescreen, which is beneficial for displaying documents, data, and presentations.
Can this projector be mounted on a ceiling?
Yes, its form factor is specifically designed as ceiling mountable. It supports front-ceiling and rear-ceiling projection methods, making it suitable for permanent installation in commercial and institutional environments where a clean, out-of-the-way setup is required.
What video inputs are available on this projector?
It includes HDMI and 3G-SDI inputs. HDMI is common for consumer and prosumer devices, while 3G-SDI is a professional digital video interface often used in broadcast and high-end AV systems for reliable, long-distance signal transmission.
What warranty coverage is provided with this projector?
Registered owners receive a 5-year or 20,000-hour parts and labor limited warranty. This warranty includes an 'InstaCare' next-business-day exchange service, providing substantial protection and support for this professional installation product.
