Pelco SRXP4-5V10-EMD-IR Sarix Professional 5MP Dome Network Camera - Full HD - 131. 23 ft Night Vision - Varifocal Lens - Vandal Resistant - White
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This network camera captures video in H.264, H.265, and Motion JPEG formats, optimizing bandwidth and storage efficiency. The 1/2.8" CMOS sensor enables high-quality imaging with features like wide dynamic range, 3D digital noise reduction, and backlight compensation to handle challenging lighting conditions. Exposure control ranges from 1/30000 to 1/7.5 seconds, accommodating fast motion and low-light scenarios.
Remote management is fully supported, allowing administrators to configure and monitor the camera via standard protocols including ONVIF, IPv4, IPv6, HTTP, HTTPS, and SNMP. Storage options include local memory card support via USB, while network connectivity is provided through an RJ-45 port. The camera operates on 12V DC or Power over Ethernet (PoE), simplifying installation and power delivery in varied deployment environments.
This section brings together practical product details such as HD Recording, Recording Formats, Night Vision, Image Sensor Type, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The SRXP4-5V10-EMD-IR stands out with its combination of high-resolution imaging, extended night vision, and industrial-grade durability. Its vandal-resistant dome design and IP66/IP67 ratings ensure reliable performance in harsh indoor or outdoor settings, from retail spaces to industrial perimeters.
These strengths make the product easier to deploy and manage in real environments, especially where reliability, usability, and day-to-day operational continuity matter. Notable benefits include Advanced Imaging Features, Robust Construction.
Advanced Imaging Features
Incorporates video content analytics, privacy masking, and audio compression for enhanced security monitoring and data management.
- Wide Dynamic Range
- 3D Digital Noise Reduction
- Back Light Compensation
Robust Construction
Built to withstand physical impact and environmental extremes, with an IK10 impact rating and operation in temperatures from -40°F to 140°F.
- Vandal Resistant
- Weather Resistant
- 95% Max Humidity Tolerance
Deployment / Use Cases
This camera is ideal for commercial and institutional security systems requiring detailed video evidence and continuous monitoring. Its varifocal lens and adjustable field of view make it suitable for covering entrances, parking lots, warehouses, or corridors where focal length needs may vary.
Common applications include retail loss prevention, school campus security, office building surveillance, and industrial facility monitoring. The PoE capability allows for streamlined installation in networked environments, reducing wiring complexity while maintaining power reliability. Integration with ONVIF-compliant video management systems ensures compatibility with a wide range of security platforms.
Perimeter Security
Deploy along building exteriors or fences to monitor unauthorized access, leveraging the 131.23 ft night vision for after-hours coverage.
High-Traffic Areas
Install in lobbies, hallways, or retail floors where the 5MP resolution and 30 fps frame rate capture clear details of movement and activity.
Highlights
- 5-megapixel resolution for detailed Full HD video capture
- Infrared night vision up to 131.23 ft (40 m) for 24/7 monitoring
- Varifocal lens with 3.1x optical zoom and adjustable field of view
- Vandal-resistant dome with IP66/IP67 environmental protection
- Supports H.264, H.265, and Motion JPEG video formats
- Power over Ethernet (PoE) and 12V DC power options
- ONVIF compliant for easy integration with security systems
- Includes wide dynamic range and 3D noise reduction features
- Remote management via standard network protocols
- 5-year limited warranty for long-term reliability
Specifications
| Specifications | |
|---|---|
| Manufacturer | Schneider Electric SA |
| Manufacturer Part Number | SRXP4-5V10-EMD-IR |
| Brand Name | Pelco |
| Product Line | Sarix Professional |
| Product Series | 4 |
| Product Model | SRXP4-5V10-EMD-IR |
| Product Name | Sarix Professional 4 SRXP4-5V10-EMD-IR Network Camera |
| Product Type | Network Camera |
| Technical Information | |
| HD Recording | Yes |
| Recording Formats | Full HD |
| Night Vision | Yes |
| Night Vision Distance | 131.23 ft (40 m) |
| Night Vision Type | Infrared/Color |
| Display & Graphics | |
| Image Sensor Type | CMOS |
| Image Sensor Size | 1/2.8" |
| Color Supported | Color,Monochrome |
| Field of View | Horizontal Angle of View 95° - 28° Vertical Angle of View 69° - 21° |
| Effective Camera Resolution | 5 Megapixel |
| Video | |
| Video Formats | H.264,H.265,Motion JPEG,MJPEG |
| Maximum Video Resolution | 1920 x 1080 |
| Maximum Frame Rate | 30 fps |
| Lens | |
| Lens Type | Varifocal |
| Minimum Focal Length | 3.4 mm (0.13") |
| Maximum Focal Length | 10.5 mm (0.41") |
| Lens Included | Yes |
| Maximum Aperture | f/1.6 |
| Optical Zoom | 3.1x |
| Exposure | |
| Shortest Shutter Speed | 1/30000 Second |
| Longest Shutter Speed | 1/7.5 Second |
| Network & Communication | |
| Connectivity Technology | Wired |
| Remote Management | Yes |
| Ethernet Technology | Fast Ethernet |
| Protocols | ONVIF,IPv4,IPv6,HTTP,HTTPS,SOAP,NTP,DNS,RTSP,RTCP,RTP,TCP,UDP,IGMP,ICMP,DHCP,ZeroConf,ARP,RTP/UDP,SNMP v2c,SNMP v3 |
| Storage | |
| Storage Type | Memory Card |
| Interfaces/Ports | |
| USB | Yes |
| Network (RJ-45) | Yes |
| Power Description | |
| Input Voltage | 12 V DC |
| Power Source Type | DC,PoE |
| Physical Characteristics | |
| Color Family | White |
| Product Color | White |
| Form Factor | Dome |
| Durability | Vandal Resistant,Weather Resistant |
| Environmental Conditions | |
| Minimum Operating Temperature | -40°F (-40°C) |
| Maximum Operating Temperature | 140°F (60°C) |
| Maximum Operating Humidity | 95% |
| Miscellaneous | |
| Features | Wide Dynamic Range,3D Digital Noise Reduction,White Balance,Back Light Compensation (BLC),Privacy Masking,Video Content Analytics,Audio Compression |
| Impact Protection Rating | IK10 |
| Ingress Protection Rating | IP66,IP67 |
| TAA Compliant | No |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 5 Year |
User Manual
FAQ
What is the maximum video resolution of this Pelco camera?
The Pelco SRXP4-5V10-EMD-IR captures video at a maximum resolution of 1920 x 1080 (Full HD) at 30 frames per second. This ensures high-definition footage suitable for identifying details like faces or license plates in security applications.
How far does the night vision reach on this network camera?
The camera provides infrared night vision up to 131.23 ft (40 m), allowing for clear monochrome imaging in low-light or complete darkness. This extended range makes it effective for perimeter monitoring and outdoor areas during nighttime hours.
What type of lens does this camera have, and is it adjustable?
It features a varifocal lens with a 3.1x optical zoom, offering focal lengths from 3.4 mm to 10.5 mm. This allows you to adjust the field of view horizontally from 95° to 28° and vertically from 69° to 21°, providing flexibility to cover wide or narrow areas as needed.
Is this camera suitable for outdoor installation?
Yes, the camera is built for outdoor use with an IP66/IP67 ingress protection rating, making it dust-tight and resistant to water jets or temporary immersion. It also operates in temperatures from -40°F to 140°F (-40°C to 60°C) and has a vandal-resistant IK10 impact rating.
What power options are available for this Pelco dome camera?
The camera supports both 12V DC power and Power over Ethernet (PoE). PoE simplifies installation by delivering power and data over a single Ethernet cable, reducing wiring costs and enabling placement in locations without direct power access.
Does this camera support remote management and integration with other systems?
Yes, it includes remote management capabilities and supports protocols like ONVIF, SNMP, HTTP, and HTTPS. This ensures compatibility with most video management software and allows for centralized configuration, monitoring, and integration into existing network security setups.
What storage is included?
The system includes Memory Card of storage for applications, files, and everyday business data.
