Perle 05061450 C-1000MM-S2LC160 Media Converter - 2 x LC Ports - 1000Base-ZX/SX - 160 km - Internal Mounting
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This media converter operates on 1000Base-ZX and 1000Base-SX network technologies, delivering full-duplex Gigabit Ethernet performance over single-mode or multimode fiber. It supports maximum transmission distances of 160 kilometers, enabling long-haul network connections without signal degradation.
The unit is compatible with 50/125 µm and 62.5/125 µm fiber optic cable specifications, providing flexibility for various existing cable plant installations. Its internal mounting design ensures secure placement within standard networking equipment, while the lightweight construction at 149.7 grams minimizes added bulk.
Key Product Advantages
The C-1000MM-S2LC160 delivers extended network reach with minimal deployment complexity, making fiber connectivity accessible for diverse networking scenarios.
Extended Distance Support
With 160-kilometer maximum distance capability, this converter eliminates geographical limitations for network expansion, supporting campus-wide, metropolitan, and long-distance fiber links without intermediate equipment.
- 160 km maximum reach
- Suitable for long-haul applications
- Reduces need for repeaters
Dual LC Port Configuration
Two LC duplex ports provide dedicated fiber interfaces for bidirectional communication, ensuring reliable signal transmission and reception across both single-mode and multimode fiber installations.
- Two LC duplex ports
- Bidirectional communication
- Compatible with common fiber types
Deployment / Use Cases
This media converter is specifically designed for environments where extending copper-based Gigabit Ethernet networks over fiber optic cabling is required. Its internal form factor makes it suitable for integration into existing network equipment racks, patch panels, or enclosure systems.
Common deployment scenarios include connecting network segments between buildings in campus environments, extending network reach in industrial settings where electromagnetic interference is a concern, and integrating fiber backbones into predominantly copper-based network infrastructures. The converter also serves telecommunications applications where signal must traverse extended distances without degradation.
Building-to-Building Connectivity
Connect network segments across separate buildings or facilities using existing fiber infrastructure, maintaining Gigabit speeds over distances up to 160 kilometers.
EMI-Sensitive Environments
Replace copper runs in industrial or high-interference areas with fiber optic connections that are immune to electromagnetic interference, ensuring data integrity.
Physical Profile
The converter features an internal mounting design that integrates discreetly within networking equipment. With an approximate weight of 149.7 grams, it adds minimal load to installation environments. The compact form factor optimizes space utilization in rack-mounted systems and enclosure installations.
- Weight
- 149.7 g
Highlights
- Extends network reach up to 160 kilometers over fiber optic cable
- Supports 1000Base-ZX and 1000Base-SX Gigabit Ethernet standards
- Features two LC duplex ports for bidirectional fiber connectivity
- Compatible with 50/125 µm and 62.5/125 µm fiber cable specifications
- Internal mounting form factor for discreet equipment integration
- Lightweight design at approximately 149.7 grams
- Manufactured in Canada with environmentally friendly considerations
- Backed by Perle's lifetime limited warranty
Specifications
| Specifications | |
|---|---|
| Manufacturer | Perle Systems, Inc |
| Manufacturer Part Number | 05061450 |
| Brand Name | Perle |
| Product Model | C-1000MM-S2LC160 |
| Product Name | C-1000MM-S2LC160 Media Converter |
| Product Type | Transceiver/Media Converter |
| Interfaces/Ports | |
| Total Number of Ports | 2 |
| Number of LC Ports | 2 |
| LC Port Type | Duplex |
| Media & Performance | |
| Maximum Distance Supported | 160 km |
| Fiber Optic Cable Core/Cladding Specification | 50/125 µm,62.5/125 µm |
| Network & Communication | |
| Network Technology | 1000Base-ZX,1000Base-SX |
| Physical Characteristics | |
| Form Factor | Internal |
| Weight (Approximate) | 149.7 g |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Country of Origin | Canada |
| Warranty | |
| Limited Warranty | Lifetime |
FAQ
What is the maximum distance this media converter supports?
The Perle C-1000MM-S2LC160 supports fiber optic connections up to 160 kilometers (approximately 99.42 miles). This extended reach makes it suitable for connecting network segments across large campuses, between buildings, or in metropolitan area networks where long-distance fiber runs are required without signal degradation.
What types of fiber optic cable are compatible with this converter?
This media converter is compatible with both 50/125 µm and 62.5/125 µm fiber optic cable specifications. This dual compatibility ensures flexibility for integration with existing multimode fiber installations commonly found in enterprise and data center environments, allowing network administrators to utilize available cable plant infrastructure.
How is this media converter installed?
The converter features an internal form factor designed for mounting within networking equipment racks, patch panels, or enclosure systems. This installation approach provides secure placement while minimizing visible hardware, making it ideal for data centers and telecommunications environments where space optimization and clean installation are priorities.
What network standards does this converter support?
The converter supports both 1000Base-ZX and 1000Base-SX Gigabit Ethernet standards over fiber optic connections. These standards deliver full-duplex data transfer rates up to 1000 Mbps, providing high-performance connectivity for bandwidth-intensive applications while maintaining compatibility with existing Gigabit Ethernet network infrastructure.
