Honeywell 1300G-1USB-N Hyperion 1300g Barcode Scanner - 1D Single Line - 270 scan/s - USB Cable - Ivory - IP41
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
Engineered for consistent performance, the Hyperion 1300g features a 65° reading angle for both skew and pitch, accommodating flexible scanning positions. The scanner maintains accurate reading at motion tolerances up to 20 in/s (508 mm/s) and operates effectively in ambient light conditions up to 70,000 lux.
Technical specifications include a minimum print contrast requirement of 20%, short-range scanning capability, and automatic interface detection that simplifies setup by eliminating the need for programming barcodes. The device draws 200 mA during operation with 125 mA standby current, supporting efficient power management.
This section brings together practical product details such as Connectivity Technology, Scanning Capability, Barcode Symbology Supported, Host Interface, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
The Hyperion 1300g stands out with class-leading durability and versatile scanning capabilities that reduce the need for multiple specialty scanners. Its reliable design incorporates no moving parts and full impact-resistant bumpers, increasing uptime while reducing service costs.
Enhanced Productivity
Superior hand-held scanning performance increases throughput with intuitive operation and aggressive scanning capabilities that read barcodes up to 18 inches (457mm) on 13 mil codes.
- 270 scans per second speed
- Wide 65° reading angles
- High-density barcode reading
Management & Compatibility
Remote MasterMind scanner management software enables IT administrators to manage all scanners within their network from a single location, while automatic interface detection supports popular interfaces without manual configuration.
- Centralized network management
- Automatic interface detection
- USB connectivity
Deployment / Use Cases
The Honeywell Hyperion 1300g is ideally suited for retail point-of-sale environments, warehouse inventory management, and manufacturing floor applications where reliable 1D barcode scanning is essential. Its durable construction and high-speed performance make it effective for high-volume scanning operations.
Common deployment scenarios include checkout counters for price verification, receiving docks for shipment processing, and production lines for tracking work-in-progress. The scanner's environmental resilience allows operation in various conditions, from climate-controlled retail spaces to more demanding industrial settings.
This section brings together practical product details such as Connectivity Technology, Scanning Capability, Barcode Symbology Supported, Host Interface, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Retail POS Operations
Provides fast, accurate scanning at checkout counters with comfortable ergonomics for extended use during peak shopping periods.
Warehouse Inventory Management
Supports efficient stock counting and order fulfillment with durable construction that withstands accidental drops in busy warehouse environments.
Physical Profile
Designed for handheld operation, the Hyperion 1300g features a gun-shaped form factor optimized for intensive scanning use. The ivory-colored scanner weighs approximately 5.64 ounces (160 grams), providing a balanced feel during extended operation. The ergonomic design ensures operator comfort and productivity, with form factors that accommodate various hand sizes and scanning techniques.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 5.64 oz (160 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Weight
- 5.64 oz (160 g)
Highlights
- 270 scans per second for high-speed barcode reading
- 1D and GS1 DataBar™ symbology support for versatile scanning
- USB cable connectivity with automatic interface detection
- IP41 rating for basic dust and water protection
- Withstands 50 drops from 1.5m on concrete for durability
- Gun-shaped ergonomic design for comfortable handheld use
- 65° reading angles for flexible scanning positions
- Remote MasterMind software for centralized network management
- 5-year limited warranty for long-term reliability
- RoHS and WEEE compliant for environmental responsibility
Specifications
| Specifications | |
|---|---|
| Manufacturer | Honeywell International, Inc |
| Manufacturer Part Number | 1300G-1USB-N |
| Brand Name | Honeywell |
| Product Line | Hyperion |
| Product Model | 1300g |
| Product Name | Hyperion 1300g Barcode Scanner |
| Product Type | Barcode Scanner |
| Technical Information | |
| Connectivity Technology | Cable |
| Scanning Capability | 1D |
| Barcode Symbology Supported | Reads standard 1D and GS1 DataBar™ symbologies |
| Scan Rate | 270 scan/s |
| Scan Pattern | Single Line |
| Scanner Range | Short Range |
| Reading Angle (Skew) | 65° |
| Reading Angle (Pitch) | 65° |
| Motion Tolerance | 20 in/s (508 mm/s) |
| Maximum Ambient Light | 70000 lux |
| Drop Specification | Designed to withstand 50 drops on concrete from 1.5m |
| Minimum Print Contrast | 20% |
| Interfaces/Ports | |
| Host Interface | USB |
| Power Description | |
| Input Current | 200 mA |
| Standby Current | 125 mA |
| Environmental Conditions | |
| Operating Temperature | 122°F (50°C) |
| Storage Temperature | -40°F (-40°C) to 140°F (60°C) |
| Humidity (Non-condensing) | 95% |
| Physical Characteristics | |
| Form Factor | Handheld |
| Color Family | White |
| Product Color | Ivory |
| Weight (Approximate) | 5.64 oz (160 g) |
| Miscellaneous | |
| Ingress Protection (IP) Rating | IP41 |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Warranty | |
| Limited Warranty | 5 Year |
User Manual
FAQ
What types of barcodes can the Honeywell Hyperion 1300g scanner read?
The Hyperion 1300g reads standard 1D barcodes and GS1 DataBar™ symbologies. This includes common linear barcodes used in retail, logistics, and inventory management applications. The scanner supports high-density barcode reading and can read codes up to 18 inches (457mm) on 13 mil barcodes, providing versatility across different printing qualities and sizes.
How fast does this barcode scanner operate?
The Hyperion 1300g operates at 270 scans per second, delivering high-speed performance suitable for busy retail environments and warehouse operations. This rapid scan rate increases throughput by quickly capturing barcode data, while the 20 in/s (508 mm/s) motion tolerance ensures accurate reading even when scanning moving items or during rapid hand movements.
What connectivity options does this scanner support?
This scanner features USB cable connectivity with automatic interface detection. The USB host interface provides reliable data transfer to connected systems, while the automatic detection eliminates the need for scanning programming barcodes to configure the interface. The cable connectivity ensures stable communication without wireless interference concerns.
How durable is the Hyperion 1300g barcode scanner?
The Hyperion 1300g is designed for durability with a construction that withstands 50 drops from 1.5 meters onto concrete surfaces. It features no moving parts and full impact-resistant bumpers to increase reliability and reduce service costs. The IP41 rating provides basic protection against dust and water ingress, making it suitable for various operational environments.
What is the reading angle capability of this scanner?
The scanner offers 65° reading angles for both skew and pitch, providing flexible scanning positions. This wide angle tolerance allows operators to scan barcodes from various orientations without requiring precise alignment. The combination of 65° skew and pitch angles accommodates different scanning techniques and barcode placements in real-world applications.
What management features are available for this scanner?
The Hyperion 1300g supports Remote MasterMind scanner management software, which enables IT administrators to manage all scanners within their network from a single remote location. This centralized management solution provides configuration, monitoring, and maintenance capabilities across multiple devices, simplifying IT operations in environments with numerous scanners deployed.
What print speed is listed?
Honeywell Hyperion 1300g Barcode Scanner - Cable Connectivity - 270 scan/s - 1D - Single Line - USB - Ivory - IP41 (1300G-1USB-N) is described for practical deployment use, and the specification set helps buyers confirm fit, compatibility, and expected day-to-day operation.
What sheet capacity, media size, or paper handling detail is listed?
Honeywell Hyperion 1300g Barcode Scanner - Cable Connectivity - 270 scan/s - 1D - Single Line - USB - Ivory - IP41 (1300G-1USB-N) is described for practical deployment use, and the specification set helps buyers confirm fit, compatibility, and expected day-to-day operation.
