65ft - 20m 12-Fiber Singlemode MPO/APC Female (no guide pins) to 12x LC/UPC (not clipped), OFNP
SKU:
FN-FO-1015-65P
Write a Review
Write a Review
Fleet Network
65ft - 20m 12-Fiber Singlemode MPO/APC Female (no guide pins) to 12x LC/UPC (not clipped), OFNP
$118.33
$118.00
Weight:
0.60 LBS
Have questions?
1-844-836-8268
Ask an Experts-
Business Pricing
Volume deals available
-
IT Experts
Consulting & support
-
Config Service
From PC to server ready
-
Canada Delivery
UPS, FedEx, Purolator
Products Features
- Whether you are a lefty or a righty, the symmetrically shaped mouse suits both
- USB Type A connectivity for a easy connection
- Optical LED for smoother movement and hassle-free performance
Description
This singlemode fiber optic MPO breakout cable is made with Corning glass fiber and consists of a MPO/MTP female connector on one end and 4 duplex LC male connectors on the other. It is used in high bandwidth datacenter applications connecting switches or MPO/MTP cassettes.
| Physical Characteristics | |
|---|---|
| Cable Length | 20m [65 foot] |
| Breakout Length | 24 inches |
| Color | Yellow |
| Cable Diameter | 3mm |
| Fiber Count | 12 Fibers |
| Fiber Type | Singlemode 9/125 Micron |
| Glass Manufacturer | Corning Glass |
| Jacket Rating | Plenum (OFNP) |
Connector(s) | |
| Connector A | 1 - 12-Position MPO/APC Female (no guide pins) Elite Connectors |
| Connector B | 12 - LC Simplex Male |
Performance | |
| MPO Insertion Loss | ¤0.35 dB |
| MPO Return Loss | ¥60db |
| LC Insertion Loss | ¤0.3 dB |
| LC Return Loss | ¥50 dB |
| testing | 100% IL, RL and Interferometer Tested |
| Environmental | |
| RoHS | Yes |
| UL | UL Listed Cable |
| Packaging Information | |
| Package Quantity | 1 |
| Product Weight | 0.60 lbs [0.27kg] |
| Warranty Information | |
| Warranty | Limited Lifetime |
