Product Features
Technical Overview
This SFP transceiver operates at a 1310nm wavelength with a reach of up to 10 kilometers, suitable for long-distance backbone connections or campus network links. It supports Gigabit Ethernet technology, ensuring full duplex data transmission at 1000 Mbps over optical fiber media.
The module is compatible with a wide range of HP ProCurve switch series, including the 1400, 1700, 1800, 2510, 2600, 2610, 2810, 2900, 3400cl, 3500yl, 4200vl, 5300xl, 5400zl, 6108, 6200yl, 8100fl, 8212zl, and 9300m series, as well as modules for the 4100gl, 5300xl, and 9300m switch series. This broad compatibility ensures it can be deployed in existing HP network environments without compatibility concerns.
Key Product Advantages
This transceiver combines high performance with broad compatibility, offering a reliable drop-in replacement for HP J4859C modules in ProCurve switch deployments. Its support for both singlemode and multimode fiber provides deployment flexibility across different network segments.
Cost-Effective Compatibility
As a compatible alternative to the HP J4859C, this transceiver delivers the same technical specifications and performance at a competitive price point, reducing total cost of ownership for network expansions or replacements.
- Direct HP J4859C replacement
- Lifetime warranty
- Made in the USA
Operational Reliability
With DOM monitoring capabilities, network administrators can track real-time performance metrics such as temperature, voltage, and optical power levels, enabling proactive maintenance and reducing downtime risks.
- Real-time diagnostics
- Hot-swappable for zero downtime
- 10km reach for extended connections
Deployment / Use Cases
This 1000Base-LX SFP transceiver is ideal for Gigabit Ethernet fiber optic connections in enterprise networks, data centers, and campus environments. Its 10km reach makes it suitable for connecting buildings or network segments over longer distances where copper cabling is impractical.
Common deployment scenarios include uplinks between switches, connections to servers or storage devices, and backbone links in network infrastructure. The compatibility with HP ProCurve switches makes it particularly valuable for organizations standardizing on HP networking equipment, allowing for seamless integration into existing switch portfolios without requiring vendor-locked modules.
Enterprise Network Backbone
Deploy this transceiver for core network connections between switches in different buildings or floors, leveraging its 10km reach and Gigabit Ethernet speed for reliable backbone performance.
Data Center Interconnects
Use in data center environments for server-to-switch connections or switch-to-switch links, where fiber optic media provides noise immunity and longer distance capabilities compared to copper alternatives.
Physical Profile
The transceiver features a compact, hot-swappable SFP form factor with dimensions of 0.40" (10.16 mm) in height, 0.60" (15.24 mm) in width, and 2.20" (55.88 mm) in depth, weighing approximately 0.64 oz (18.14 g). This small footprint allows for high-density installations in switch chassis without occupying excessive space, while the hot-swappable design supports easy field replacements without powering down network equipment.
- Width
- 0.60" (15.24 mm)
- Depth
- 2.20" (55.88 mm)
- Height
- 0.40" (10.16 mm)
- Weight
- 0.64 oz (18.14 g)
Highlights
- Compatible replacement for HP J4859C 1000Base-LX SFP transceiver
- Gigabit Ethernet speed with 1000 Mbps data transfer rate
- LC connector for reliable fiber optic connections
- 1310nm wavelength with 10km reach over optical fiber
- Supports both singlemode and multimode fiber modes
- DOM (Digital Optical Monitoring) for real-time diagnostics
- Hot-swappable SFP form factor for easy installation
- Broad compatibility with HP ProCurve switch series
- Lifetime warranty for long-term reliability
- Manufactured in the United States
Specifications
| Specifications | |
|---|---|
| Manufacturer | AddOn |
| Manufacturer Part Number | J4859C-AO |
| Brand Name | AddOn |
| Product Model | J4859C-AO |
| Product Name | HP Compatible 1000Base-LX SFP mini-GBIC |
| Product Type | SFP (mini-GBIC) |
| Technical Information | |
| Application/Usage | Data Networking |
| Interfaces/Ports | |
| Total Number of Ports | 1 |
| Connector Type | LC |
| Interfaces/Ports Details | 1 x LC 1000Base-LX |
| Media & Performance | |
| Media Type Supported | Optical Fiber |
| Fiber Optic Cable Core/Cladding Specification | 50/125 µm,62.5/125 µm |
| Fiber Mode Supported | Multi-mode,Single-mode |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 1000Base-LX |
| Physical Characteristics | |
| Form Factor | Hot-swappable |
| Height | 0.40" (10.16 mm) |
| Width | 0.60" (15.24 mm) |
| Depth | 2.20" (55.88 mm) |
| Weight (Approximate) | 0.64 oz (18.14 g) |
| Miscellaneous | |
| Compatibility | HP ProCurve Modules: Modules for ProCurve Switch 4100gl Series Modules for ProCurve Switch 5300xl Series Modules for ProCurve Switch 9300m Series HP ProCurve Switches: ProCurve Switch 1400 Series Procurve Switch 1700 Series ProCurve Switch 1800 Series ProCurve Switch 2510 Series ProCurve Switch 2600 Series ProCurve Switch 2600-PWR Series ProCurve Switch 2610 Series ProCurve Switch 2610-PWR Series ProCurve Switch 2810 Series ProCurve Switch 2900 Series ProCurve Switch 3400cl Series ProCurve Switch 3500yl Series ProCurve Switch 4200vl Series ProCurve Switch 5300xl Series ProCurve Switch 5400zl Series ProCurve Switch 6108 ProCurve Switch 6200yl Series ProCurve Switch 8100fl Series ProCurve Switch 8212zl Series ProCurve Switch 9300m Series |
| Country of Origin | United States |
| Warranty | |
| Limited Warranty | Lifetime |
User Manual
FAQ
What is the speed and network technology of this SFP transceiver?
This transceiver supports 1000Base-LX network technology, delivering Gigabit Ethernet speeds of 1000 Mbps (1 Gbps) over optical fiber. It operates at full duplex, providing reliable high-speed data transmission for network backbone connections, server links, and switch interconnects in enterprise environments.
What types of fiber optic cable does this transceiver support?
The transceiver supports both singlemode and multimode optical fiber, with compatibility for cable core/cladding specifications of 50/125 µm and 62.5/125 µm. This flexibility allows deployment in various network segments, using either multimode fiber for shorter distances within buildings or singlemode fiber for longer reaches up to 10 kilometers.
What is the connector type and reach distance of this module?
It features an LC duplex connector interface, which is standard for SFP fiber optic transceivers, providing secure and low-loss connections. The reach distance is up to 10 kilometers (approximately 6.2 miles) when used with singlemode fiber, making it suitable for campus network links, building-to-building connections, or extended backbone deployments.
Which HP switch models is this transceiver compatible with?
This transceiver is compatible with numerous HP ProCurve switch series, including the 1400, 1700, 1800, 2510, 2600, 2610, 2810, 2900, 3400cl, 3500yl, 4200vl, 5300xl, 5400zl, 6108, 6200yl, 8100fl, 8212zl, and 9300m series. It also works with modules for the ProCurve Switch 4100gl, 5300xl, and 9300m series, ensuring broad integration into existing HP network infrastructures.
Does this SFP transceiver include monitoring capabilities?
Yes, it features DOM (Digital Optical Monitoring) support, which enables real-time monitoring of key parameters such as temperature, supply voltage, laser bias current, and transmitted/received optical power. This allows network administrators to perform proactive diagnostics, troubleshoot link issues, and maintain optimal performance without physical inspection.
What is the warranty and country of origin for this product?
This transceiver comes with a lifetime limited warranty, providing long-term assurance of quality and reliability. It is manufactured in the United States, ensuring adherence to production standards and supporting domestic manufacturing. The hot-swappable design further enhances reliability by allowing easy replacement if needed.
