Altronix
Altronix Dual Output Offline Power Supply/Charger. 12VDC or 24VDC @ 3A and 12VDC @ 1A. - Rack-mountable - 120 V AC, 230 V AC Input - V (OLS120D2X)
Marketing Information: OLS120D2X dual output power supply/charger converts a 115VAC, 50/60Hz or 230VAC, 50/60Hz input to a 12VDC/24VDC output and a 12VDC fixed output (see specifications). This unit has a wide range of applications for access control and security system accessories that require additional power.
Protection Type: Short Circuit,Thermal Overload
Input Voltage: 120 V AC,230 V AC
Output Voltage: 12 V DC,24 V DC
Output Voltage Detail: 12 V DC @ 3 A,12 V DC @ 1 A,24 V DC @ 3 A
Output Current: 3 A,1 A
Form Factor: Rack-mountable
Height: 13.50" (342.90 mm)
Width: 13" (330.20 mm)
Depth: 3.25" (82.55 mm)
Weight (Approximate): 3.36 kg
Country of Origin: United States
Environmentally Friendly: Yes
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Limited Warranty: Lifetime
- Dual output power supply/charger.
- 115VAC, 50/60Hz or 230VAC, 50/60Hz input.
- One 12VDC/24VDC selectable output and one 12VDC fixed output.
- CE approved.
[custom-specifications]
| Specifications | |
| Manufacturer | Altronix Corporation |
| Manufacturer Part Number | OLS120D2X |
| Manufacturer Website Address | http://www.altronix.com |
| Brand Name | Altronix |
| Product Model | OLS120D2X |
| Product Name | Dual Output Offline Power Supply/Charger. 12VDC or 24VDC @ 3A and 12VDC @ 1A. |
| Packaged Quantity | 1 |
| Product Type | Proprietary Power Supply |
| Technical Information | |
| Protection Type | Short Circuit,Thermal Overload |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Output Voltage | 12 V DC,24 V DC |
| Output Voltage Detail | 12 V DC @ 3 A,12 V DC @ 1 A,24 V DC @ 3 A |
| Output Current | 3 A,1 A |
| Physical Characteristics | |
| Form Factor | Rack-mountable |
| Height | 13.50" (342.90 mm) |
| Width | 13" (330.20 mm) |
| Depth | 3.25" (82.55 mm) |
| Weight (Approximate) | 3.36 kg |
| Miscellaneous | |
| Country of Origin | United States |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | Lifetime |
[/custom-specifications]
