Lexmark SMC1000C APC Smart-UPS C 1000VA/600W Line Interactive Tower UPS - 120V - 8 Outlets - SmartConnect - AVR - Pure Sine Wave
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Product Overview
The APC Smart-UPS C 1000VA/600W line interactive tower UPS delivers reliable power protection for critical business infrastructure. This unit combines 1 kVA/600W capacity with pure sine wave output, automatic voltage regulation (AVR), and eight NEMA 5-15R outlets to safeguard servers, networking equipment, POS terminals, and VoIP systems.
Designed for entry-level server rooms, network closets, and retail environments, the Smart-UPS C provides sufficient runtime to handle brief outages or initiate graceful shutdowns. Its tower form factor supports standalone deployment or optional 2U rack mounting, offering flexibility for diverse IT environments. The integrated LCD provides clear status information, while SmartConnect enables cloud-based remote monitoring without additional management cards.
With a 10 ms transfer time, the UPS maintains continuous power during minor fluctuations, switching to battery during outages to prevent downtime. The pure sine wave output ensures compatibility with sensitive active PFC power supplies in modern servers and networking gear, while AVR corrects input voltage variations between 93-130V AC without draining the battery, extending runtime and reducing wear.
The 1000VA/600W capacity supports typical loads such as an entry-level server with a switch and router, providing 9.2 minutes of runtime at full load for orderly shutdowns. The hot-swappable lead-acid battery allows replacement without powering down connected equipment, minimizing maintenance downtime and ensuring continuous operation.
Technical Overview
This line interactive UPS operates with a 10 ms typical transfer time, maintaining continuous power during minor fluctuations and switching to battery during outages. The pure sine wave output ensures compatibility with sensitive active PFC power supplies found in modern servers and networking gear. Automatic Voltage Regulation corrects minor undervoltage and overvoltage conditions without draining the battery, extending runtime and reducing wear.
The 1000VA/600W capacity supports typical loads such as an entry-level server with a switch and router. At full 600W load, the lead-acid battery delivers 9.2 minutes of runtime, providing adequate time for orderly shutdowns or riding through short interruptions. The hot-swappable battery design allows replacement without powering down connected equipment, minimizing downtime.
Relevant product facts for this section include Plug/Connector Type: NEMA 5-15P, Receptacle Type: NEMA 5-15P, Receptacle Detail: 8 x NEMA 5-15R, Load Capacity (VA): 1 kVA. When those details are considered together, they give buyers a clearer picture of how the product is equipped, how it connects, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The Smart-UPS C balances robust protection features with straightforward management, making it accessible for businesses without dedicated power infrastructure expertise. Its combination of capacity, connectivity, and physical design addresses common pain points in small to medium IT deployments.
SmartConnect Remote Monitoring
The integrated Ethernet port enables cloud-based monitoring without additional management cards. View status, receive alerts, and manage power events remotely through a web interface, reducing the need for onsite checks.
- No additional management card required
- Cloud-based monitoring and alerts
- Simplifies remote infrastructure management
Automatic Voltage Regulation
AVR actively corrects input voltage variations between 93-130V, maintaining stable 120V output without switching to battery. This extends battery life and provides cleaner power to connected equipment.
- Corrects undervoltage and overvoltage
- Reduces unnecessary battery usage
- Improves power quality to sensitive loads
Flexible Deployment Options
The tower design works well on shelves or under desks, while the 2U rack-mountable form factor allows integration into standard server racks. This dual-format approach accommodates evolving infrastructure needs.
- Tower form factor for standalone use
- 2U rack-mountable with optional kit
- Black finish blends with IT equipment
Deployment / Use Cases
This 1000VA UPS suits environments where brief power interruptions could disrupt operations or cause data loss. Its capacity and outlet count match typical small business infrastructure requirements, while the communication ports enable integration with existing management systems.
Common deployment scenarios include protecting single servers in branch offices, supporting networking equipment in retail environments, and ensuring uptime for VoIP phone systems. The unit's runtime provides sufficient buffer for short outages or controlled shutdowns during extended power events.
Server & Network Protection
Ideal for entry-level servers, switches, routers, and network hubs. The 8 outlets accommodate multiple devices, while the pure sine wave output ensures compatibility with server power supplies.
- Protects single servers with peripherals
- Supports networking equipment clusters
- Maintains connectivity during outages
Retail & Point-of-Sale
Safeguards POS terminals, receipt printers, and payment processors against power disturbances that could interrupt transactions or corrupt data. The tower form factor fits under counters or in back offices.
- Prevents transaction interruptions
- Protects sensitive payment hardware
- Fits retail environment footprints
Physical Profile
The black tower measures 8.62" H × 6.73" W × 17.28" D (219 × 171 × 439 mm) and weighs 37.48 lb. Its compact footprint fits on standard shelves or under desks, while the 2U rack height allows optional rack mounting with appropriate hardware. The design includes front-panel controls and status display for easy access during operation.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 8.62" (219 mm), 6.73" (171 mm), 17.28" (439 mm), 37.48 lb (17000.64 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 6.73" (171 mm)
- Depth
- 17.28" (439 mm)
- Height
- 8.62" (219 mm)
- Weight
- 37.48 lb (17000.64 g)
- Length
- 6 ft (1.83 m)
What's in the Box
The package includes the Smart-UPS C 1000VA LCD 120V unit with SmartConnect capability and a USB cable for local management. All necessary components for basic operation are provided.
Highlights
- 1000VA/600W line interactive tower UPS with pure sine wave output
- 8 NEMA 5-15R outlets for battery backup and surge protection
- SmartConnect Ethernet port enables cloud-based remote monitoring
- Automatic Voltage Regulation (AVR) corrects input voltage fluctuations
- 9.2 minutes runtime at full 600W load for orderly shutdowns
- Hot-swappable lead-acid battery for maintenance without downtime
- Tower form factor with optional 2U rack mounting capability
- USB and serial communication ports for graceful shutdown management
- Energy Star certified for energy efficiency
- 2-year limited warranty with RoHS environmental compliance
Specifications
| Specifications | |
|---|---|
| Manufacturer | Schneider Electric SA |
| Manufacturer Part Number | SMC1000C |
| Brand Name | APC by Schneider Electric |
| Product Line | Smart-UPS |
| Product Name | Smart-UPS C 1000VA LCD 120V with SmartConnect |
| Packaged Quantity | 1 |
| Product Type | Line-interactive UPS |
| Technical Information | |
| Plug/Connector Type | NEMA 5-15P |
| Receptacle Type | NEMA 5-15P |
| Receptacle Detail | 8 x NEMA 5-15R |
| Number of Battery & Surge Outlets | 8 |
| Cord Length | 6 ft (1.83 m) |
| Transfer Time | 10 ms |
| Application/Usage | Server,Router,Switch,Network Hub,Network Device,POS Terminal |
| Power Description | |
| Load Capacity (VA) | 1 kVA |
| Load Capacity (Watt) | 600 W |
| Input Voltage | 120 V AC |
| Input Voltage Range | 93 V AC - 130 V AC |
| Output Voltage | 120 V AC |
| Waveform Type | Sine Wave |
| Surge Energy Rating | 680 J |
| Management | |
| Network Management | SmartConnect |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Battery Information | |
| Battery Chemistry | Lead Acid |
| Backup/Run Time (Full Load) | 9.20 Minute |
| Hot Swappable | Yes |
| Typical Battery Recharge Time | 3 Hour |
| Physical Characteristics | |
| Product Color | Black |
| Height | 8.62" (219 mm) |
| Width | 6.73" (171 mm) |
| Depth | 17.28" (439 mm) |
| Rack Height | 2U |
| Form Factor | Tower |
| Weight (Approximate) | 37.48 lb (17000.64 g) |
| Miscellaneous | |
| Package Contents | Smart-UPS C 1000VA LCD 120V with SmartConnect USB cable |
| Energy Star | Yes |
| Country of Origin | Philippines |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 2 Year |
User Manual
FAQ
What is the power capacity of this UPS?
This APC Smart-UPS C provides 1000VA (1 kVA) and 600W of power capacity, suitable for protecting entry-level servers, networking equipment, and POS systems. The 1000VA rating indicates the apparent power the unit can deliver, while the 600W wattage represents the actual power available for connected devices.
How long does the battery last during a power outage?
At full 600W load, the lead-acid battery delivers 9.2 minutes of runtime, providing sufficient time for orderly shutdowns or riding through brief interruptions. Runtime varies with actual load—lighter loads extend backup time significantly. The hot-swappable design allows battery replacement without powering down connected equipment.
How many devices can I connect to this UPS?
The unit features eight NEMA 5-15R outlets that provide both battery backup and surge protection. This outlet count accommodates typical small business setups including a server, switch, router, and peripherals. All outlets support the 120V output voltage and pure sine wave waveform.
What voltage does this UPS support?
This 120V unit accepts input voltage from 93-130V AC and maintains stable 120V AC output. The automatic voltage regulation (AVR) corrects minor voltage fluctuations without switching to battery, extending runtime and protecting sensitive equipment from brownouts and overvoltage conditions.
Can this UPS be installed in a server rack?
Yes, the tower form factor measures 2U in height (8.62 inches), making it rack-mountable with optional hardware. The compact dimensions of 8.62" H × 6.73" W × 17.28" D also allow standalone deployment on shelves or under desks, offering flexible installation options for different IT environments.
What remote management features are included?
The SmartConnect Ethernet port enables cloud-based remote monitoring without additional management cards. You can view status, receive alerts, and manage power events through a web interface. USB and serial communication ports support graceful shutdowns via PowerChute software, ensuring data protection during extended outages.
