APC by Schneider Electric
APC Smart-UPS RT 5000VA Tower/Rack-mountable UPS - 5000VA/4000W - 4.8 Minute Full Load - 1 x NEMA L6-20R, 1 x NEMA L14-30R, 4 x NEMA (SURTD5000RMXLP3U)
- Smart-UPS RT 5000VA Tower/Rack-mountable UPS
- CD with software
- Rack mounting support rails
- Removable support feet
- Smart UPS signalling RS-232 cable
- User manual
Marketing Information: High density, double-conversion on-line power protection with scalable runtime
Plug/Connector Type: NEMA L14-30P
Receptacle Type: NEMA L14-30P
Receptacle Detail: 1 x NEMA L14-30R,1 x NEMA L6-30R,4 x NEMA 5-20R
Number of Battery & Surge Outlets: 6
Cord Length: 10 ft
Load Capacity (VA): 5 kVA
Load Capacity (Watt): 4 kW
Input Voltage: 208 V
Output Voltage: 120 V AC,208 V AC
Waveform Type: Sine Wave
Surge Energy Rating: 365 J
Serial Port: Yes
Battery Characteristics: Maintenance-free, Sealed, Spill-proof
Battery Chemistry: Lead Acid
Backup/Run Time (Full Load): 4.80 Minute
Backup/Run Time (Half Load): 15.10 Minute
Hot Swappable: Yes
Typical Battery Recharge Time: 2.50 Hour
Product Color: Black
Height: 5.12" (130 mm)
Width: 17.01" (432 mm)
Depth: 25.98" (660 mm)
Rack Height: 3U
Form Factor: Rack-mountable
Weight (Approximate): 58.06 kg
Package Contents:
Environmentally Friendly: Yes
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Limited Warranty: 2 Year
Additional Warranty Information: 2 years repair or replace
- 4 kW load capacity - backup power for your valuable electronics
- Keep your sensitive devices powered with a backup of up to 4.80 minute at full load
- 5 kVA load capacity provides sufficient backup during power failures
[custom-specifications]
| Specifications | |
| Manufacturer | Schneider Electric SA |
| Manufacturer Part Number | SURTD5000RMXLP3U |
| Manufacturer Website Address | http://www.schneider-electric.com |
| Brand Name | APC by Schneider Electric |
| Product Line | Smart-UPS |
| Product Series | RT |
| Product Name | Smart-UPS RT 5000VA Tower/Rack-mountable UPS |
| Product Type | Double Conversion Online UPS |
| Technical Information | |
| Plug/Connector Type | NEMA L14-30P |
| Receptacle Type | NEMA L14-30P |
| Receptacle Detail | 1 x NEMA L14-30R,1 x NEMA L6-30R,4 x NEMA 5-20R |
| Number of Battery & Surge Outlets | 6 |
| Cord Length | 10 ft |
| Power Description | |
| Load Capacity (VA) | 5 kVA |
| Load Capacity (Watt) | 4 kW |
| Input Voltage | 208 V |
| Output Voltage | 120 V AC,208 V AC |
| Waveform Type | Sine Wave |
| Surge Energy Rating | 365 J |
| Interfaces/Ports | |
| Serial Port | Yes |
| Battery Information | |
| Battery Characteristics | Maintenance-free, Sealed, Spill-proof |
| Battery Chemistry | Lead Acid |
| Backup/Run Time (Full Load) | 4.80 Minute |
| Backup/Run Time (Half Load) | 15.10 Minute |
| Hot Swappable | Yes |
| Typical Battery Recharge Time | 2.50 Hour |
| Physical Characteristics | |
| Product Color | Black |
| Height | 5.12" (130 mm) |
| Width | 17.01" (432 mm) |
| Depth | 25.98" (660 mm) |
| Rack Height | 3U |
| Form Factor | Rack-mountable |
| Weight (Approximate) | 58.06 kg |
| Miscellaneous | |
| Package Contents | |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 2 Year |
| Additional Warranty Information | 2 years repair or replace |
[/custom-specifications]
