Aten 2A-136G Multi-Mode SFP Transceiver - 1. 25G - 1000Base-X - 550M Reach - Hot-Pluggable
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This transceiver operates on multi-mode fiber optic media, supporting a reach of up to 550 meters, making it suitable for intra-building links and campus network deployments. The 1000Base-X technology ensures stable and high-speed data, audio, and video transmission over supported fiber optic cables.
The module features a single duplex 1000Base-X network port, providing full-duplex communication for simultaneous data sending and receiving. Its hot-pluggable design allows for installation and removal without powering down the network device, minimizing downtime during maintenance or upgrades.
Key Product Advantages
The ATEN 2A-136G SFP transceiver offers several advantages for network administrators and IT professionals seeking reliable fiber optic connectivity.
High-Speed Performance
Supports 1.25 Gigabit Ethernet and 1000Base-X technology, enabling fast data transfer rates up to 1000 Mbps for efficient network operations.
- 1.25 Gigabit Ethernet capability
- 1000Base-X network technology
Easy Deployment
Hot-pluggable SFP form factor allows for tool-free installation and removal, reducing network downtime and simplifying maintenance.
- Hot-pluggable design
- MSA-compliant for broad compatibility
Environmental Compliance
Manufactured in compliance with RoHS and WEEE directives, ensuring reduced hazardous substances and responsible electronic waste management.
- RoHS compliant
- WEEE compliant
Deployment / Use Cases
This multi-mode SFP transceiver is typically deployed in scenarios requiring short-distance, high-speed fiber optic connections within a single building or campus environment.
Common use cases include linking network switches in data center racks, connecting routers in enterprise network closets, and extending optical network segments for audio/video transmission applications. Its 550-meter reach makes it suitable for backbone links, server-to-switch connections, and inter-building links within close proximity.
Data Center Networking
Ideal for connecting servers and switches in data centers, providing reliable multi-mode fiber optic links for high-speed data transfer.
Enterprise Network Expansion
Used to extend network segments within office buildings, supporting data networking and optical network applications with minimal signal loss.
Physical Profile
The transceiver has a compact design with dimensions of 0.57" (14.60 mm) width, 0.51" (13 mm) height, and 2.20" (55.90 mm) depth, making it suitable for high-density network equipment. Its lightweight construction at approximately 20 grams ensures minimal impact on network device port density and airflow.
- Width
- 0.57" (14.60 mm)
- Depth
- 2.20" (55.90 mm)
- Height
- 0.51" (13 mm)
- Weight
- 20 g
Highlights
- 1.25 Gigabit Ethernet SFP transceiver for multi-mode fiber optic networks
- Supports 1000Base-X technology with up to 1000 Mbps data transfer rate
- 550-meter maximum reach over multi-mode fiber for short-distance applications
- Hot-pluggable SFP (mini-GBIC) form factor for easy installation and maintenance
- MSA-compliant design ensures broad compatibility with standard SFP ports
- Single duplex 1000Base-X network port for full-duplex communication
- Ideal for data networking and optical network applications within buildings
- Environmentally friendly with RoHS and WEEE compliance
- Compact dimensions: 0.57" x 0.51" x 2.20" (14.60 mm x 13 mm x 55.90 mm)
- Lightweight at approximately 20 grams for high-density deployments
Specifications
| Specifications | |
|---|---|
| Manufacturer | ATEN Technology, Inc |
| Manufacturer Part Number | 2A-136G |
| Brand Name | ATEN |
| Product Model | 2A-136G |
| Product Name | Fiber Multi-Mode 1.25G SFP Transceiver Module (550M) |
| Product Type | SFP (mini-GBIC) |
| Packaged Quantity | 2 |
| Technical Information | |
| Application/Usage | Data Networking,Optical Network |
| Interfaces/Ports | |
| Total Number of Ports | 1 |
| Interfaces/Ports Details | 1 x Duplex 1000Base-X Network |
| Media & Performance | |
| Media Type Supported | Optical Fiber |
| Fiber Mode Supported | Multi-mode |
| Ethernet Technology | 1.25 Gigabit Ethernet |
| Network Technology | 1000Base-X |
| Physical Characteristics | |
| Form Factor | Hot-pluggable |
| Height | 0.51" (13 mm) |
| Width | 0.57" (14.60 mm) |
| Depth | 2.20" (55.90 mm) |
| Weight (Approximate) | 20 g |
| Miscellaneous | |
| Compatibility | MSA Compliant |
| Country of Origin | Taiwan |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
FAQ
What type of fiber optic cable does this SFP transceiver support?
This ATEN SFP transceiver supports multi-mode fiber optic cable, which is typically used for short-distance applications up to 550 meters. It is designed for optical fiber media and is ideal for data transmission within buildings or campus environments.
What is the maximum data transfer rate of this transceiver?
The transceiver supports 1.25 Gigabit Ethernet and 1000Base-X network technology, delivering a maximum data transfer rate of up to 1000 Mbps (1 Gbps) over supported multi-mode fiber optic cabling. This ensures high-speed performance for data networking and optical network applications.
Is this SFP module hot-pluggable?
Yes, this SFP transceiver features a hot-pluggable form factor, allowing you to install or remove it without powering down the network device. This design minimizes downtime during maintenance, upgrades, or replacements, making it convenient for live network environments.
What is the reach distance for this multi-mode SFP transceiver?
This transceiver supports a maximum reach of 550 meters over multi-mode fiber optic cable. This distance is suitable for short-range applications such as intra-building links, data center connections, and campus network segments where high-speed fiber optic transmission is required.
