Axiom LCLCMD6O-3M-AX LC/LC Multimode Duplex OM1 62. 5/125 Fiber Optic Cable 9. 8 ft Orange
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This fiber optic cable is built to OM1 specifications with a 62.5/125 µm core/cladding design, optimized for multimode transmission at common networking wavelengths like 850 nm and 1300 nm. The LC connectors ensure low insertion loss and high return loss, maintaining signal integrity across the cable length.
The duplex construction supports simultaneous bidirectional data transfer, making it suitable for Gigabit Ethernet, Fibre Channel, and other high-speed network protocols that require separate transmit and receive paths.
Key Product Advantages
This Axiom fiber optic cable combines precise optical performance with durable construction for stable network links. The LC connectors offer a small form factor that saves space in high-density patch panels while maintaining reliable mating and unmating cycles.
Reliable Connectivity
The LC connectors provide consistent alignment and low loss, ensuring minimal signal degradation for clear data transmission across multimode fiber networks.
- Precision ceramic ferrule alignment
- Secure latch mechanism
- Low insertion loss design
Durable Construction
Built with quality materials to withstand the rigors of data center environments, including repeated connections and cable management stresses.
- Robust connector housing
- Flexible yet protective cable jacket
- Strain relief at connector junctions
Deployment / Use Cases
This LC/LC multimode duplex cable is ideal for connecting network equipment within racks, between adjacent racks, or in structured cabling systems where short to medium reach multimode fiber links are required.
Common applications include connecting switches to switches, switches to servers, patch panels to active equipment, and storage area network (SAN) components. The 9.8-foot length provides flexibility for clean cable management while avoiding excessive slack in confined spaces.
Highlights
- LC to LC multimode duplex fiber optic cable with 9.8-foot length
- OM1 62.5/125 µm core/cladding specification for multimode applications
- Two LC male connectors on each end for duplex connectivity
- Orange color jacket for easy visual identification as multimode fiber
- Lifetime limited warranty for long-term reliability assurance
- Suitable for Gigabit Ethernet, Fibre Channel, and other high-speed protocols
- Precision LC connectors with secure latching mechanism
- Duplex construction supports simultaneous bidirectional data transfer
Specifications
| Specifications | |
|---|---|
| Manufacturer | Axiom Memory Solutions |
| Manufacturer Part Number | LCLCMD6O-3M-AX |
| Brand Name | Axiom |
| Product Name | LC/LC Multimode Duplex OM1 62.5/125 Fiber Optic Cable 3m |
| Product Type | Network Cable |
| Technical Information | |
| Cable Type | Fiber Optic |
| Fiber Optic Mode | Multi-mode |
| Fiber Optic Cable Core/Cladding Specification | 62.5/125 µm |
| Cable Length | 9.8 ft |
| Connector Type on First End | LC Network - Male |
| Connector on First End Details | 2 x LC Network - Male |
| Connector Type on Second End | LC Network - Male |
| Connector on Second End Details | 2 x LC Network - Male |
| Device Supported | Network Device |
| Physical Characteristics | |
| Color Family | Orange |
| Product Color | Orange |
| Warranty | |
| Limited Warranty | Lifetime |
FAQ
What type of fiber optic cable is this?
This is a multimode duplex fiber optic cable meeting OM1 specifications with a 62.5/125 µm core/cladding design. It uses LC connectors on both ends and features an orange jacket that identifies it as multimode fiber, suitable for short to medium distance network connections.
What connectors does this cable have on each end?
Both ends of this cable feature two LC male connectors each, providing a duplex connection with separate transmit and receive paths. The LC connectors offer a small form factor that saves space in high-density patch panels while ensuring reliable optical alignment.
What is the length of this fiber optic cable?
This cable measures 9.8 feet (approximately 3 meters) in length, making it suitable for rack-to-rack connections, equipment-to-patch-panel links, and other short to medium reach applications within data centers and server rooms.
What color is the cable jacket and why does it matter?
The cable features an orange jacket, which is the standard color for identifying multimode fiber optic cables. This color coding helps network technicians quickly distinguish multimode cables from single-mode cables (typically yellow) during installation, troubleshooting, and maintenance procedures.
