Axiom 331-5217-AX 40GBASE-CR4 QSFP+ Passive DAC Cable - Dell Compatible - 3. 3 ft - 1m - 40 Gbit/s
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This DAC cable operates on the 40GBASE-CR4 standard, utilizing four lanes of 10 Gbit/s to achieve an aggregate bandwidth of 40 Gbit/s. The passive copper architecture eliminates the need for signal conditioning electronics, reducing power consumption and potential points of failure. The cable length of 3.3 feet (1 meter) is optimized for top-of-rack or adjacent-rack deployments where minimal latency and cost-effectiveness are priorities.
The QSFP+ connectors are hot-pluggable, allowing for installation and removal without powering down connected devices, which supports flexible network maintenance and upgrades. The male connectors ensure a firm physical connection, reducing the risk of disconnection in high-vibration environments.
Key Product Advantages
This cable delivers high-performance connectivity with several distinct benefits for network administrators and IT professionals.
High-Speed Performance
Supports 40 Gbit/s data transfer rates, enabling rapid data movement for bandwidth-intensive applications like virtualization, storage networking, and high-performance computing.
- 40GBASE-CR4 standard
- Low-latency copper transmission
- Ideal for short-reach links
Reliable Compatibility
Designed for compatibility with Dell network devices, ensuring seamless integration into existing infrastructure without configuration hassles.
- Tested for Dell equipment
- QSFP+ interface standard
- Wide device support
Durable Construction
Built with quality materials and backed by a lifetime warranty, providing long-term reliability and reducing total cost of ownership.
- Robust cable jacket
- Secure male connectors
- Lifetime warranty coverage
Deployment / Use Cases
This QSFP+ DAC cable is suited for various networking scenarios where high-speed, short-distance connections are required. Its passive design and compatibility make it a versatile component in modern data centers and enterprise networks.
Common use cases include connecting switches to servers within the same rack, linking network appliances in adjacent racks, and establishing high-speed interconnects for clustered computing environments. The 3.3-foot length is particularly effective for minimizing cable clutter and optimizing airflow in densely packed racks, while the 40 Gbit/s bandwidth supports demanding applications such as data analytics, video streaming, and cloud services.
Highlights
- 40 Gbit/s data transfer rate for high-speed networking
- QSFP+ passive DAC cable with 3.3-foot length
- Dell compatible for seamless integration
- Hot-pluggable QSFP+ male connectors on both ends
- Passive design reduces power consumption and complexity
- Lifetime warranty for long-term reliability
- Ideal for short-reach data center and enterprise links
- Supports 40GBASE-CR4 standard for efficient data transmission
Specifications
| Specifications | |
|---|---|
| Manufacturer | Axiom Memory Solutions |
| Manufacturer Part Number | 331-5217-AX |
| Brand Name | Axiom |
| Product Name | 40GBASE-CR4 QSFP+ Passive DAC Cable Dell Compatible 1m |
| Product Type | Network Cable |
| Technical Information | |
| Cable Type | QSFP |
| Cable Length | 3.3 ft |
| Connector Type on First End | QSFP+ Network - Male |
| Connector on First End Details | 1 x QSFP+ Network - Male |
| Connector Type on Second End | QSFP+ Network - Male |
| Connector on Second End Details | 1 x QSFP+ Network - Male |
| Device Supported | Network Device |
| Data Transfer Rate | 40 Gbit/s |
| Features | Passive |
| Warranty | |
| Limited Warranty | Lifetime |
FAQ
What is the data transfer rate of this QSFP+ DAC cable?
This cable supports a data transfer rate of 40 Gbit/s, utilizing the 40GBASE-CR4 standard to deliver high-speed connectivity for network devices. It aggregates four lanes of 10 Gbit/s each, making it suitable for bandwidth-intensive applications in data centers and enterprise environments.
Is this cable compatible with Dell networking equipment?
Yes, this Axiom DAC cable is designed for compatibility with Dell network devices. It has been tested to ensure reliable performance with Dell switches, routers, and other networking hardware, providing a seamless integration option for existing Dell-based infrastructure.
What does 'passive' mean for this DAC cable?
A passive DAC cable uses copper conductors without active electronics for signal conditioning. This design reduces power consumption, lowers latency, and minimizes potential failure points compared to active cables. It is ideal for short-distance connections up to a few meters, such as within a rack or between adjacent racks.
What is the length of this cable, and why is it suitable for my setup?
This cable is 3.3 feet (1 meter) long, making it optimal for short-reach connections in data center racks. It minimizes cable clutter, improves airflow, and reduces signal attenuation, which is beneficial for top-of-rack switching, server-to-switch links, or connecting nearby network appliances efficiently.
