Black Box KV04AUS-REM ServSwitch CATmix KVM Extender - 1 Computer - 1 Remote User - 984.25 ft Range - WUXGA 1900 x 1440
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
Technically, the ServSwitch CATmix extender uses wired connectivity to transmit KVM signals, supporting one computer and one remote user simultaneously. It achieves a maximum operating distance of 984.25 feet, which is equivalent to 300 meters, allowing flexible placement of the remote station relative to the host computer.
The device handles WUXGA graphic mode with a maximum video resolution of 1900 x 1440, providing sharp and accurate visual feedback for administrative or operational tasks. This resolution is well-suited for standard desktop applications and system monitoring interfaces.
Relevant factors for this section include Connectivity Technology, Number of Computers Supported, Number of Remote Users Supported, Graphic Mode. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The ServSwitch CATmix extender offers several advantages for IT professionals needing reliable remote access solutions. Its long-range capability up to 984.25 feet allows for flexible deployment in large facilities, while the WUXGA video support ensures high-quality display output without degradation over distance.
Port Flexibility
Includes VGA, USB, PS/2, and RJ-45 ports to connect various peripherals and network interfaces, supporting comprehensive KVM functionality.
- 1 VGA port for video output
- 1 USB port for peripheral connectivity
- 2 PS/2 ports for legacy keyboard/mouse
Compact Design
The external receiver has a small form factor with dimensions of 0.98" x 1.77" x 2.56" and weighs approximately 100 grams, making it easy to install in tight spaces.
- External form factor
- Lightweight at 100 g
- Minimal desk or rack footprint
Deployment / Use Cases
This KVM extender is ideal for scenarios where direct physical access to a computer is impractical or restricted. It enables remote management of a single computer from a distance, useful in environments like server rooms, industrial control systems, or secure areas where operators need to monitor and control systems from a separate location.
Common use cases include IT administration in data centers, where technicians can manage servers from a centralized console room; educational labs, allowing instructors to demonstrate on a primary machine while students observe remotely; and broadcast or production studios, where equipment racks are located away from control desks. The wired connection ensures stable and secure transmission without wireless interference.
Relevant factors for this section include Connectivity Technology, Number of Computers Supported, Number of Remote Users Supported, Graphic Mode. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
What's in the Box
The package includes all necessary components for immediate setup and operation.
Package contents include ServSwitch CATmix KVM Extender, 1 x 5VDC 2.5A Power Supply. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- Extends KVM control up to 984.25 feet (300 meters) over wired connection
- Supports one computer and one remote user simultaneously
- Delivers WUXGA video resolution at 1900 x 1440 for clear display output
- Includes VGA, USB, PS/2, and RJ-45 ports for comprehensive connectivity
- Compact external receiver with dimensions of 0.98" x 1.77" x 2.56"
- Lightweight design at approximately 100 grams for easy installation
- Comes with a 5VDC 2.5A power supply for reliable operation
- Backed by a 2-year limited warranty for peace of mind
- Environmentally friendly manufacturing
- Made in the United Kingdom
Specifications
| Specifications | |
|---|---|
| Manufacturer | Black Box Corporation |
| Manufacturer Part Number | KV04AUS-REM |
| Brand Name | Black Box |
| Product Line | ServSwitch |
| Product Name | ServSwitch CATmix KVM Extender |
| Packaged Quantity | 1 |
| Product Type | KVM Console |
| Technical Information | |
| Connectivity Technology | Wired |
| Number of Computers Supported | 1 |
| Number of Remote Users Supported | 1 |
| Maximum Operating Distance | 984.25 ft (300000 mm) |
| Video | |
| Graphic Mode | WUXGA |
| Maximum Video Resolution | 1900 x 1440 |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| USB | Yes |
| VGA | Yes |
| Number of VGA Ports | 1 |
| Number of Network (RJ-45) Ports | 1 |
| Number of PS/2 Ports | 2 |
| Number of USB Ports | 1 |
| Physical Characteristics | |
| Form Factor | External |
| Receiver Height | 0.98" (25 mm) |
| Receiver Width | 1.77" (45 mm) |
| Receiver Depth | 2.56" (65 mm) |
| Receiver Weight (Approximate) | 100 g |
| Miscellaneous | |
| Package Contents | ServSwitch CATmix KVM Extender 1 x 5VDC 2.5A Power Supply |
| Environmentally Friendly | Yes |
| Country of Origin | United Kingdom |
| Warranty | |
| Limited Warranty | 2 Year |
User Manual
FAQ
What is the maximum distance this KVM extender supports?
The Black Box ServSwitch CATmix KVM Extender supports a maximum operating distance of 984.25 feet, which is equivalent to 300 meters. This wired range allows flexible placement of the remote user station relative to the host computer, making it suitable for large server rooms, data centers, or industrial environments where extended reach is necessary for effective remote management.
How many computers and users can this extender handle?
This extender is designed to support one computer and one remote user simultaneously. It provides dedicated KVM extension for a single host system, enabling one operator to control and monitor that computer from a remote location. This configuration is ideal for scenarios where individual machines need isolated remote access without sharing resources across multiple users or systems.
What video resolution does the ServSwitch CATmix extender support?
The extender supports WUXGA graphic mode with a maximum video resolution of 1900 x 1440. This resolution ensures high-quality display output for remote sessions, suitable for administrative tasks, system monitoring, and general desktop applications. The WUXGA standard provides clear and detailed visuals, maintaining image integrity over the extended distance without significant degradation.
What types of ports are available on this KVM extender?
The extender includes multiple ports for comprehensive connectivity: one VGA port for video output, one USB port for peripheral devices, two PS/2 ports for legacy keyboard and mouse connections, and one network (RJ-45) port. These ports enable full KVM functionality, allowing users to connect a variety of input devices and display monitors to the remote station for complete control of the host computer.
Is the extender easy to install and set up?
Yes, the ServSwitch CATmix extender is designed for straightforward installation. It comes as an external receiver with a compact form factor, and the package includes a 5VDC 2.5A power supply. Setup involves connecting the extender to the host computer via the appropriate ports, linking it to the remote user station, and powering it on. The wired connectivity eliminates complex configuration, making it a plug-and-play solution for most environments.
What warranty and support are provided with this product?
The Black Box ServSwitch CATmix KVM Extender comes with a 2-year limited warranty, covering defects in materials and workmanship. Additionally, it is manufactured in the United Kingdom with environmentally friendly practices. For support, users can refer to the included user manual and additional documentation available online, ensuring reliable operation and assistance throughout the product's lifecycle.
