Product Features
Technical Overview
This network camera utilizes a CMOS image sensor that delivers 4-megapixel resolution with true color reproduction. The sensor's f/1.6 maximum aperture allows for excellent low-light performance, while advanced imaging features including Back Light Compensation (BLC), Highlight Compensation (HLC), 3D Digital Noise Reduction, and Wide Dynamic Range ensure optimal image quality in varying lighting conditions. The camera supports multiple video compression formats including H.265+, H.265, H.264+, H.264, and MJPEG for efficient bandwidth utilization and storage optimization.
Network connectivity is provided through a wired RJ-45 interface, enabling reliable Power over Ethernet (PoE) deployment when used with compatible switches or injectors. The camera includes a built-in microphone with audio compression capabilities, supporting two-way audio communication. Security features include password protection and HTTPS encryption for secure data transmission. Local storage is supported via SD card, providing backup recording capability independent of network video recorder systems.
Key Product Advantages
The AcuSense technology represents a significant advancement in surveillance intelligence, utilizing deep learning algorithms to distinguish between human and vehicle targets. This intelligent classification reduces false alarms by focusing only on relevant security events, improving overall system efficiency and reducing monitoring workload. The camera's infrared night vision extends to 30 meters, providing reliable 24/7 surveillance capability with clear imaging even in complete darkness.
Advanced Detection Capabilities
Beyond basic motion detection, this camera features cross-line detection, face detection, tampering alarm, and privacy masking functions. These intelligent analytics enable precise event triggering and privacy protection in sensitive areas.
- Human/Vehicle Classification
- Cross-Line Detection
- Face Detection
- Tampering Alarm
- Privacy Masking Zones
Professional Imaging Features
The camera incorporates multiple image enhancement technologies including Day/Night functionality with IR cut filter, automatic white balance, and configurable shutter speeds from 1/100000 to 1/30 second for optimal exposure control in any lighting scenario.
Deployment / Use Cases
This versatile network camera is ideally suited for commercial and institutional surveillance applications where reliable 24/7 monitoring is required. Its compact dome design and multiple mounting options make it perfect for retail environments, office buildings, educational facilities, and parking areas where discreet installation is preferred. The camera's weather-resistant construction and wide operating temperature range enable deployment in outdoor locations such as building entrances, perimeter fencing, and loading docks.
The AcuSense intelligence makes this camera particularly valuable for applications requiring accurate event detection, such as perimeter security where distinguishing between human intruders and wildlife is critical. The built-in microphone adds value for environments requiring audio monitoring or two-way communication, such as entry control points or customer service areas. With support for SD card local storage, the camera can function as a standalone recording solution or as part of a comprehensive network video surveillance system.
Retail & Commercial Security
Monitor store entrances, cash handling areas, and inventory storage with intelligent human/vehicle detection that reduces false alarms from passing traffic or environmental movement.
Perimeter & Outdoor Protection
Secure building exteriors, parking lots, and fence lines with 30-meter infrared night vision and IP67 weather resistance that ensures reliable operation in rain, snow, and extreme temperatures.
Physical Profile
The camera features a compact mini dome design with a 110mm (4.33") diameter and weighs approximately 380 grams, making it lightweight yet durable for various installation scenarios. The vandal-resistant IK08 rating ensures protection against physical impacts, while the IP67 ingress protection guarantees operation in wet and dusty environments. Five mounting options provide installation flexibility: corner mounting for wall-ceiling junctions, pendant mounting for ceiling drops, pole mounting for outdoor posts, junction box mounting for concealed wiring, and standard wall mounting for straightforward installations.
- Weight
- 380 g
- Length
- 2.8 mm
Highlights
- 4MP resolution delivers clear 2688 x 1520 video at 30 fps
- AcuSense deep learning technology distinguishes human from vehicle targets
- 30-meter infrared night vision ensures 24/7 surveillance capability
- IP67 and IK08 ratings provide weather and vandal resistance
- Fixed 2.8mm lens with 104.3° horizontal field of view
- H.265+ compression reduces bandwidth and storage requirements
- Built-in microphone supports audio monitoring and two-way communication
- SD card slot enables local storage independent of NVR systems
- Multiple mounting options for flexible installation
- Operates from -30°C to 60°C for reliable performance in extreme conditions
Specifications
| Specifications | |
|---|---|
| Manufacturer | Hikvision |
| Manufacturer Part Number | DS-2CD2543G2-IS 2.8MM |
| Brand Name | Hikvision |
| Product Line | AcuSense |
| Product Series | Pro |
| Product Model | DS-2CD2543G2-IS |
| Product Name | 4 MP AcuSense Built-in Mic Fixed Mini Dome Network Camera |
| Product Type | Network Camera |
| Technical Information | |
| HD Recording | Yes |
| Night Vision | Yes |
| Night Vision Distance | 98.43 ft (30 m) |
| Night Vision Type | Infrared |
| Display & Graphics | |
| Image Sensor Type | CMOS |
| Color Supported | Color |
| Field of View | horizontal FOV 104.3°, vertical FOV 55.9°, diagonal FOV 123.8° |
| Effective Camera Resolution | 4 Megapixel |
| Video | |
| Video Formats | H.265+,H.265,H.264+,H.264,MJPEG |
| Maximum Video Resolution | 2688 x 1520 |
| Maximum Frame Rate | 30 fps |
| Lens | |
| Lens Type | Fixed |
| Maximum Focal Length | 2.8 mm |
| Lens Included | Yes |
| Lens Mount Type | M12-mount |
| Maximum Aperture | f/1.6 |
| Exposure | |
| Shortest Shutter Speed | 1/100000 Second |
| Longest Shutter Speed | 1/30 Second |
| Network & Communication | |
| Connectivity Technology | Wired |
| Remote Management | Yes |
| Storage | |
| Storage Type | Memory Card |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Physical Characteristics | |
| Mount Type | Corner Mount,Pendant Mount,Pole Mount,Junction Box Mount,Wall Mount |
| Form Factor | Mini Dome |
| Durability | Water Resistant,Dust Resistant,Vandal Resistant |
| Diameter | 4.33" (110 mm) |
| Weight (Approximate) | 380 g |
| Environmental Conditions | |
| Minimum Operating Temperature | -22°F (-30°C) |
| Maximum Operating Temperature | 140°F (60°C) |
| Maximum Operating Humidity | 95% |
| Miscellaneous | |
| Features | Built-in Microphone,Audio Compression,Password Protection,HTTPS Encryption,Day/Night,Back Light Compensation (BLC),Highlight Compensation (HLC),3D Digital Noise Reduction,Wide Dynamic Range,Motion Detection,Tampering Alarm,Cross Line Detection,Face Detection,White Balance,Privacy Masking,SD Card Local Storage |
| Impact Protection Rating | IK08,IK8 |
| Ingress Protection Rating | IP67 |
User Manual
FAQ
What is the effective resolution of this Hikvision camera?
This Hikvision AcuSense camera delivers 4-megapixel resolution with a maximum video resolution of 2688 x 1520 pixels. This provides significantly more detail than standard 1080p cameras, allowing for clearer identification of subjects and better digital zoom capability while maintaining a 30 frames per second frame rate for smooth video playback.
How does the AcuSense technology improve surveillance effectiveness?
AcuSense utilizes deep learning algorithms to intelligently classify moving objects as either human or vehicle targets. This dramatically reduces false alarms caused by animals, foliage movement, or weather conditions, allowing security personnel to focus on genuine security events. The system sends more accurate alerts and improves overall monitoring efficiency by filtering out irrelevant motion detection triggers.
What is the night vision capability of this network camera?
The camera features infrared night vision with an effective range of 30 meters (approximately 98.43 feet). This allows for clear surveillance in complete darkness, with the infrared illuminators automatically activating when ambient light levels drop below a certain threshold. The camera maintains full 4MP resolution in night vision mode, ensuring detailed imaging around the clock.
What environmental protection ratings does this camera have?
This camera carries both IP67 and IK08 protection ratings. The IP67 rating indicates complete protection against dust ingress and protection against immersion in water up to 1 meter for 30 minutes. The IK08 rating signifies high resistance to physical impacts, making the camera suitable for environments where vandalism or accidental contact may occur.
What mounting options are available for this mini dome camera?
The camera supports five different mounting configurations: corner mounting for wall-ceiling junctions, pendant mounting for suspended ceiling installations, pole mounting for outdoor posts, junction box mounting for concealed wiring, and standard wall mounting. This flexibility allows installation in virtually any surveillance scenario, from indoor retail spaces to outdoor perimeter applications.
Does this camera support local storage without a network video recorder?
Yes, the camera includes an SD card slot that supports local storage independent of a network video recorder. This allows for onboard recording that can serve as a backup solution or primary storage for smaller installations. The camera also supports remote management capabilities, enabling configuration and monitoring without physical access to the unit.
