Elo 1502L 15.6" LCD Touchscreen Monitor - 16:9 - 10 ms - 16" (406.40 mm) Class - IntelliTouch Pro Projected Capacitive - 10 Point(s) - (E318746)
Marketing Information: The Elo M-Series 1502L widescreen LED touch monitor is a modern and stylish interactive solution for customer engagement and employee effectiveness at the point of sale. The sleek wide aspect ratio touchscreen features full HD edge-to-edge glass with display area real estate to showcase engaging, memorable and rewarding content. An HD display model is available for transactional and other applications not requiring 1920x1080 resolution. For environments where space is scarce, the 1502L is an ideal POS terminal screen or stylish interactive information display. Built to withstand the rigors of continuous public use, the 1502L is well suited for high use retail venues. The sleek, thin look pairs well with any modern store environment.
Screen Size Class: 16"
Viewable Screen Size: 15.6"
Screen Mode: HD
Panel Technology: Thin Film Transistor (TFT)
Response Time: 10 ms
Aspect Ratio: 16:9
Horizontal Viewing Angle: 90°
Vertical Viewing Angle: 65°
Mount Type: Wall Mountable,Pole Mount
Placement: Tabletop
Backlight Technology: LED
Features: Anti-glare,On-screen Display (OSD),Security Lock,Landscape/Portrait Viewable,Cable Lock Slot
Horizontal Frequency: 31.50 Hz to 60 Hz
Vertical Frequency: 60 Hz
Curved Screen: No
Stand Adjustments: Height
Maximum Resolution: 1366 x 768
Color Supported: 262,000 Colors
Contrast Ratio: 600:1
Native Contrast Ratio: 700:1
Brightness: 220 cd/m²
Speakers: Yes
Touchscreen Type: IntelliTouch Pro Projected Capacitive
Multi-touch Screen: Yes
Number of Simultaneous Touchpoints: 10
HDMI: Yes
USB: Yes
VGA: Yes
Number of HDMI Inputs: 1
Webcam: No
Microphone: No
Operating Power Consumption: 10.20 W
Color Family: Black
Product Color: Black
VESA Mount Compatible: Yes
VESA Mount Standard: 100 x 100
Height: 9.62" (244.35 mm)
Width: 15.24" (387.10 mm)
Depth: 1.29" (32.77 mm)
Weight (Approximate): 3 kg
Weight with Stand (Approximate): 3.05 kg
- Multi-touch activation can be performed with the IntelliTouch Pro Projected Capacitive touchscreen technology i.e. you can input from more than one finger.
- The 600:1 contrast ratio produces enhanced sharpness and shading accuracy in each picture
- LED backlight technology provides for industry-leading low power consumption and less hazardous materials
- The 220 cd/m² brightness gives an exceptionally visible display for clear and consistent on-screen pictures
- HDMI interface allows connectivity to a variety of HD devices including gaming consoles, laptop PCs, Blu-ray players, digital cameras and many others for the ultimate high-definition display
- VESA mount compatibility allows you to mount the touch screen on a wall or with a stand depending on your specific needs
[custom-specifications]
| Specifications | |
|---|---|
| Manufacturer | Elo Touch Solutions, Inc |
| Manufacturer Part Number | E318746 |
| Manufacturer Website Address | http://www.elotouch.com |
| Brand Name | Elo |
| Product Series | M |
| Product Model | 1502L |
| Product Name | M-Series 1502L 15-inch LED Touch Monitor |
| Packaged Quantity | 1 |
| Product Type | LCD Touchscreen Monitor | Technical Information |
| Screen Size Class | 16" |
| Viewable Screen Size | 15.6" |
| Screen Mode | HD |
| Panel Technology | Thin Film Transistor (TFT) |
| Response Time | 10 ms |
| Aspect Ratio | 16:9 |
| Horizontal Viewing Angle | 90° |
| Vertical Viewing Angle | 65° |
| Mount Type | Wall Mountable,Pole Mount |
| Placement | Tabletop |
| Backlight Technology | LED |
| Features | Anti-glare,On-screen Display (OSD),Security Lock,Landscape/Portrait Viewable,Cable Lock Slot |
| Horizontal Frequency | 31.50 Hz to 60 Hz |
| Vertical Frequency | 60 Hz |
| Curved Screen | No |
| Stand Adjustments | Height | Video |
| Maximum Resolution | 1366 x 768 |
| Color Supported | 262,000 Colors |
| Contrast Ratio | 600:1 |
| Native Contrast Ratio | 700:1 |
| Brightness | 220 cd/m² | Audio |
| Speakers | Yes | Touchscreen Information |
| Touchscreen Type | IntelliTouch Pro Projected Capacitive |
| Multi-touch Screen | Yes |
| Number of Simultaneous Touchpoints | 10 | Interfaces/Ports |
| HDMI | Yes |
| USB | Yes |
| VGA | Yes |
| Number of HDMI Inputs | 1 | Built-in Devices |
| Webcam | No |
| Microphone | No | Power Description |
| Operating Power Consumption | 10.20 W | Physical Characteristics |
| Color Family | Black |
| Product Color | Black |
| VESA Mount Compatible | Yes |
| VESA Mount Standard | 100 x 100 |
| Height | 9.62" (244.35 mm) |
| Width | 15.24" (387.10 mm) |
| Depth | 1.29" (32.77 mm) |
| Weight (Approximate) | 3 kg |
| Weight with Stand (Approximate) | 3.05 kg |
[/custom-specifications]
[custom-options]
| Product | Elo Tabletop Stand for 15" I-Series - Up to 15" Screen Support - Tabletop |
| SKU | E044162 |
| Sale Price | $83.34 |
| Product | Elo Magnetic Stripe Reader - Black |
| SKU | E001002 |
| Sale Price | $154.22 |
[/custom-options]
[custom-user-manual]
Available Documentation:
User-Manual
Manufacturer-Brochure
[/custom-user-manual]
