HP 1VD87A#B1K Designjet T1700 PostScript Inkjet Large Format Printer - 44" Print Width - Color - 6 Colors - 26 Second Speed
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Product Overview
The HP Designjet T1700 is a PostScript-enabled inkjet large format printer engineered for professional-grade color output across architectural, engineering, and graphic design workflows. With a 44-inch maximum print width, this floor-standing unit delivers precise, high-resolution prints on a comprehensive range of media types, from technical papers and bond sheets to photo papers, vinyl, and backlit films.
Designed for shared office or studio environments, the T1700 integrates USB and Ethernet connectivity for flexible network integration and resource sharing. Its six-color ink system supports vibrant color reproduction and detailed monochrome output, making it suitable for both presentation materials and technical documents. The printer arrives ready for deployment with included printheads, ink cartridges, a stand, spindle, and essential setup materials.
Technical Overview
This large format printer operates with a maximum color print speed of 26 seconds per page at a resolution of 2400 x 1200 dpi, ensuring sharp line work and smooth gradients. The PostScript emulation provides reliable compatibility with professional design and CAD software, maintaining accurate color matching and font rendering across applications.
Media handling is versatile, supporting roll paper up to 44 inches wide and cut sheets in standard sizes including A0, A1, A2, A3, A4, and ANSI sizes A through E. The printer's physical footprint measures 70.90 inches wide by 27.40 inches deep by 39.30 inches high, with an approximate weight of 159 pounds, requiring a dedicated floor space in a production environment.
Key Product Advantages
The Designjet T1700 combines high-speed color output with broad media compatibility, reducing the need for multiple specialized devices. Its Ethernet connectivity allows seamless integration into networked workflows, enabling team collaboration and centralized print management.
Professional Color Accuracy
Six-color ink technology delivers consistent, vibrant outputs for presentations, proofs, and final displays, with support for photo papers and high-gloss finishes.
- 6-color system
- 2400 x 1200 dpi resolution
- Photo printing capable
Office-Ready Deployment
Includes a printer stand, spindle, and all necessary components for immediate setup, with USB and Ethernet ports for flexible connection options.
- Floor standing form factor
- USB and Ethernet ports
- PC and Mac compatible
Deployment / Use Cases
Ideal for architectural firms, engineering departments, and graphic design studios, the T1700 handles large-format technical drawings, presentation boards, and marketing materials with consistent quality. Its ability to print on diverse media—including heavyweight coated papers, matte films, and adhesive substrates—makes it a versatile asset for both internal documentation and client-facing deliverables.
In educational or corporate settings, the printer supports shared use across teams, with Ethernet connectivity facilitating access from multiple workstations. The included software CD and label kits further streamline operational workflows, from initial setup to ongoing maintenance.
Architectural & Engineering Plans
Produce detailed blueprints, site plans, and technical schematics on roll paper or cut sheets, with precise line accuracy and scale fidelity.
Graphic Design & Presentation
Create high-impact posters, backlit displays, and photo-quality prints for exhibitions, trade shows, and client presentations.
Physical Profile
The T1700 is configured as a floor-standing unit with dimensions of 70.90 inches in width, 27.40 inches in depth, and 39.30 inches in height. Its robust construction supports continuous operation in professional environments, while the included printer stand provides stable media handling and ergonomic access. The 159-pound weight necessitates placement in a permanent location with adequate clearance for media loading and maintenance.
- Width
- 44" (1117.60 mm)
- Depth
- 27.40" (695.96 mm)
- Height
- 39.30" (998.22 mm)
- Weight
- 159 lb (72121.19 g)
What's in the Box
The package includes all components required for immediate operation and setup.
Highlights
- 44-inch maximum print width for large format documents
- Six-color ink system for vibrant, accurate color output
- 26-second maximum color print speed
- 2400 x 1200 dpi maximum print resolution
- Supports roll paper, cut sheets, and various media types
- USB and Ethernet connectivity for flexible integration
- PostScript emulation for professional software compatibility
- Floor-standing form factor with included stand
- Energy Star certified and EPEAT Silver environmental rating
- 1-year limited warranty
Specifications
| Specifications | |
|---|---|
| Manufacturer | HP Inc. |
| Manufacturer Part Number | 1VD87A#B1K |
| Manufacturer Website Address | http://www.hp.com |
| Brand Name | HP |
| Product Line | Designjet |
| Product Model | T1700 |
| Product Name | DesignJet T1700 Postscript Printer |
| Product Type | Inkjet Large Format Printer |
| Technical Information | |
| Number of Colors | 6 |
| Print Color Capability | Color |
| Maximum Color Print Speed (sec) | 26 Second |
| Maximum Print Resolution (dpi) | 2400 x 1200 |
| Maximum Print Width | 44" (1117.60 mm) |
| Photo Printing | Yes |
| Interfaces/Ports | |
| USB | Yes |
| Network & Communication | |
| Ethernet | Yes |
| Media Types & Handling | |
| Media Type | Roll Paper,Cut Sheet,Bond Paper,Coated Paper,Heavyweight Paper,Super Heavyweight Coated,Matte Film,Technical Paper,Tracing Paper,Translucent Bond,Clear Film,Photo Paper,High-gloss Paper,Satin Photo Paper,Semi-gloss Paper,Backlit,Adhesive Paper,Polypropylene,Vinyl |
| Media Size | 11" (279.40 mm) Width x 44" (1117.60 mm) Length - Roll Paper,8.30" (210.82 mm) Width x 11" (279.40 mm) Length,A0 - 33.10" (840.74 mm) Width x 46.80" (1188.72 mm) Length,A1 - 23.40" (594.36 mm) Width x 33.10" (840.74 mm) Length,A2 - 16.50" (419.10 mm) Width x 23.40" (594.36 mm) Length,A3 - 11.70" (297.18 mm) Width x 16.50" (419.10 mm) Length,A4 - 8.30" (210.82 mm) Width x 11.70" (297.18 mm) Length,A,B,C,D,E |
| Fonts & Emulation | |
| PostScript | Yes |
| Physical Characteristics | |
| Height | 39.30" (998.22 mm) |
| Width | 70.90" (1800.86 mm) |
| Depth | 27.40" (695.96 mm) |
| Weight (Approximate) | 159 lb (72121.19 g) |
| Miscellaneous | |
| Package Contents | DesignJet T1700 Postscript Printer Printheads Ink Cartridges Printer Stand Spindle Setup Poster Introductory Information Warranty Card Power Cords Label Kits Software CD |
| Form Factor | Floor Standing Supported |
| Platform Supported | PC,Mac |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | Electronic Product Environmental Assessment Tool Silver (EPEAT Silver) |
| Environmental Compliance | China Restriction of Hazardous Substances (China RoHS),Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE),Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Country of Origin | China |
| Warranty | |
| Limited Warranty | 1 Year |
User Manual
FAQ
What media sizes does the HP Designjet T1700 support?
The printer supports roll paper up to 44 inches wide and cut sheets in sizes including A0, A1, A2, A3, A4, and ANSI sizes A through E.
Does this printer include PostScript support?
Yes, the HP Designjet T1700 features PostScript emulation for reliable compatibility with professional design and CAD software.
What connectivity options are available?
The T1700 offers both USB and Ethernet ports, allowing direct connection or network integration for shared access.
Is the printer Energy Star certified?
Yes, it is Energy Star certified and holds an EPEAT Silver environmental assessment rating.
What is included in the package?
The package contains the DesignJet T1700 Postscript Printer, printheads, ink cartridges, printer stand, spindle, setup poster, introductory information, warranty card, power cords, label kits, and software CD.
What is the warranty period for this printer?
The HP Designjet T1700 comes with a 1-year limited warranty.
