Aruba JL682A Instant On 1930 24G 4SFP+ Switch - 24-Port Gigabit Managed Layer 2 with 4 x 10Gb SFP+ Uplinks
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This switch features 24 Gigabit Ethernet ports that support auto-negotiation and auto-MDI/MDIX for straightforward deployment. The four SFP+ expansion slots accept 10GbE transceivers for high-bandwidth uplinks to aggregation switches or servers, supporting both fiber and twisted pair media types through compatible modules.
The switch operates as a Layer 2 device with comprehensive support for IEEE 802.3 standards including 802.3ab for 1000BASE-T, 802.3u for Fast Ethernet, and 802.1x for network access control. Smart managed functionality provides web-based configuration, VLAN support, QoS prioritization, and security features like auto denial-of-service prevention.
Relevant factors for this section include Features, Total Number of Network Ports, Network (RJ-45), Uplink Port. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The Aruba Instant On 1930 switch offers several advantages for business networks seeking reliable performance without complex enterprise management overhead. Its combination of 24 Gigabit access ports and 10GbE uplink capacity provides a future-ready foundation that can scale with network demands.
Simplified Management
Smart managed capabilities through an intuitive web interface or mobile app make configuration accessible without requiring advanced networking expertise. The switch supports both standalone management and cloud-based orchestration through the Aruba Instant On portal.
- Web-based configuration
- Mobile app management
- Cloud-ready platform
Energy Efficiency
With a typical power consumption of just 22.60 watts, this switch operates efficiently while supporting energy-efficient Ethernet (EEE) standards. The switch automatically adjusts power usage based on port activity and cable length.
- 22.60W typical consumption
- EEE compliant
- Auto power adjustment
Reliable Connectivity
Built with enterprise-grade components and backed by Aruba's networking expertise, this switch delivers stable performance for business-critical applications. Features like broadcast storm control and loop protection help maintain network stability.
- Enterprise-grade components
- Broadcast storm control
- Loop protection
Deployment / Use Cases
The Aruba Instant On 1930 24G 4SFP+ switch is designed for small to medium business environments where reliable switching with growth capacity is essential. Its 24 Gigabit ports provide ample connectivity for office workstations, while the SFP+ uplinks enable high-speed connections to servers or network backbones.
This switch excels in office networks, retail environments, and small campus deployments where a balance of access ports and uplink capacity is needed. The compact 1U form factor makes it suitable for rack mounting in server rooms or network closets, while the smart managed features provide sufficient control for most business networking requirements.
Office Network Core
Serve as the central switch for small office networks, connecting workstations, printers, and wireless access points while providing 10GbE uplinks to servers or internet gateways.
- 24 workstation connections
- Printer and peripheral support
- 10GbE server uplinks
Retail or Branch Office
Deploy in retail environments or branch offices where reliable connectivity for point-of-sale systems, security cameras, and office devices is required with minimal management overhead.
- POS system support
- Security camera connectivity
- Simplified management
Physical Profile
The switch features a standard 1U rack-mountable design measuring 1.73 inches in height, 8.72 inches in width, and 17.42 inches in depth. With a weight of approximately 5.31 pounds, it's lightweight enough for wall mounting or placement on shelves while including rack ears for standard 19-inch rack installation.
Front-panel indicators provide at-a-glance status monitoring for power, system status, and port activity. The compact footprint makes efficient use of rack space while providing adequate ventilation for reliable operation in typical office environments.
- Width
- 8.72" (221.50 mm)
- Depth
- 17.42" (442.50 mm)
- Height
- 1.73" (43.90 mm)
- Weight
- 5.31 lb (2410 g)
Highlights
- 24 Gigabit Ethernet ports for connecting workstations, printers, and network devices
- 4 SFP+ slots supporting 10GbE fiber or copper uplinks for high-speed backbone connections
- Layer 2 smart managed switch with web-based configuration and essential switching features
- Supports both optical fiber and twisted pair media types for flexible deployment options
- Energy efficient design with typical power consumption of just 22.60 watts
- Plug and play deployment with auto-negotiation and auto-MDI/MDIX on all ports
- Auto denial-of-service prevention enhances network security without complex configuration
- Compact 1U form factor suitable for rack mounting in server rooms or network closets
- Supports IEEE 802.3 standards including 802.1x for network access control
- Dual voltage input (120V/230V AC) for deployment in various geographical regions
Specifications
| Specifications | |
|---|---|
| Manufacturer | Hewlett Packard Enterprise |
| Manufacturer Part Number | JL682A |
| Brand Name | HPE |
| Product Line | Instant On |
| Product Series | 1930 |
| Product Name | Networking Instant On Switch 24p Gigabit 4p SFP+ 1930 |
| Product Type | Ethernet Switch |
| Technical Information | |
| Features | Plug and Play,Energy Efficient,Auto Denial of Service (DoS) Prevention |
| Interfaces/Ports | |
| Total Number of Network Ports | 24 |
| Network (RJ-45) | Yes |
| Uplink Port | Yes |
| Modular | Yes |
| Port/Expansion Slot Details | 24 x Gigabit Ethernet Network,4 x 10 Gigabit Ethernet Expansion Slot |
| Media & Performance | |
| Media Type Supported | Optical Fiber,Twisted Pair |
| Ethernet Technology | Gigabit Ethernet,10 Gigabit Ethernet |
| Network Technology | 10/100/1000Base-T,10GBase-X |
| I/O Expansions | |
| Total Number of Expansion Slots | 4 |
| Expansion Slot Type | SFP+ |
| Number of SFP+ Slots | 4 |
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.3ab,IEEE 802.3u,IEEE 802.1x,IEEE 802.3 |
| Management & Protocols | |
| Manageable | Yes |
| Switch Management Type | Smart Managed |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Power Source | Power Supply |
| Power Consumption | 22.60 W |
| Physical Characteristics | |
| Height | 1.73" (43.90 mm) |
| Width | 8.72" (221.50 mm) |
| Depth | 17.42" (442.50 mm) |
| Weight (Approximate) | 5.31 lb (2410 g) |
User Manual
FAQ
What is the total number of ports on this Aruba Instant On switch?
This Aruba Instant On 1930 switch provides 24 Gigabit Ethernet ports for connecting network devices plus 4 SFP+ expansion slots for high-speed uplinks. The 24 RJ-45 ports support 10/100/1000 Mbps connections, while the SFP+ slots accept 10 Gigabit Ethernet transceivers for fiber or copper uplinks to core network infrastructure.
Does this switch support Power over Ethernet (PoE)?
No, this specific model (JL682A) does not provide Power over Ethernet capabilities. It is a non-PoE switch designed for data connectivity only. If you require PoE to power devices like wireless access points or IP cameras, you would need to consider a PoE-capable model from the Aruba Instant On 1930 series that includes PoE budgeting.
What type of management capabilities does this switch offer?
This is a smart managed Layer 2 switch that provides web-based configuration through an intuitive interface. Management features include VLAN support, QoS prioritization, port mirroring, IGMP snooping, spanning tree protocol, and security settings like 802.1x authentication. It can be managed standalone or through the Aruba Instant On cloud portal for centralized management of multiple switches.
Can I use fiber optic connections with this switch?
Yes, this switch supports fiber optic connections through the four SFP+ expansion slots. You can install compatible SFP+ transceivers to connect via fiber optic cables. The switch supports both multi-mode and single-mode fiber connections depending on the transceiver modules used, making it suitable for longer distance connections between buildings or to core network equipment.
What is the power consumption of this network switch?
The Aruba Instant On 1930 24G 4SFP+ switch has a typical power consumption of 22.60 watts. It supports dual voltage input (120V and 230V AC) for deployment in different regions and includes energy-efficient features that automatically adjust power usage based on port activity and cable length to minimize operational costs.
Is this switch suitable for rack mounting in a server room?
Yes, this switch features a standard 1U rack-mountable design with included rack ears for installation in 19-inch server racks. Its dimensions of 1.73" H x 8.72" W x 17.42" D (43.90 mm x 221.50 mm x 442.50 mm) make it compact enough for efficient use of rack space while providing adequate ventilation for reliable operation in server room environments.
