StarTech. com MCM110ST2 10/100 Fast Ethernet to Fiber Media Converter - Multi-mode ST - 2 km Distance
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This media converter operates at a fiber optic wavelength of 1310 nm and supports both 10Base-T and 100Base-FX network standards. It features Link Fault Pass-through (LFP) for network integrity and supports IEEE 802.1q Tag VLAN pass-through and Q in Q double-tagged frame transparency.
Flow control (Pause) is supported to manage data traffic effectively. The converter is compatible with networks from major vendors like 3Com, Cisco, Lucent, and Nortel, ensuring broad interoperability in diverse IT infrastructures.
Relevant factors for this section include Total Number of Ports, Network (RJ-45), Number of Network (RJ-45) Ports, Media Type Supported. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The MCM110ST2 extends network reach significantly by converting copper Ethernet to fiber optic, overcoming distance limitations of traditional cabling. Its support for multi-mode fiber with ST connectors makes it suitable for existing fiber infrastructure upgrades.
Distance Extension
Enables Ethernet connectivity up to 2 km, ideal for connecting buildings or remote network segments without signal degradation.
- Multi-mode fiber support
- ST duplex connectors
Network Compatibility
Works seamlessly with various network equipment brands and supports key Ethernet standards for reliable integration.
- Vendor interoperability
- IEEE 802.3 compliance
Deployment / Use Cases
Deploy this media converter to extend 10/100 Mbps Ethernet networks over fiber optic cabling in scenarios where copper distances are insufficient. It is commonly used in campus networks, industrial settings, and data centers to connect disparate network segments.
Typical applications include linking network switches between buildings, integrating fiber backbones with copper access layers, and upgrading legacy networks to leverage fiber's noise immunity and longer reach. Its external form factor allows for flexible placement near network equipment.
Building-to-Building Connectivity
Connect network equipment across separate structures using fiber optic runs, maintaining signal integrity over longer distances.
Industrial Network Extensions
Extend Ethernet to remote machinery or control systems in environments where electrical interference is a concern.
Physical Profile
The converter has a compact external design with dimensions of 3" (76.20 mm) width, 3.70" (93.98 mm) depth, and 0.80" (20.32 mm) height. Its small footprint and lightweight construction facilitate easy installation on desktops, shelves, or mounted near network racks.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 0.80" (20.32 mm), 3" (76.20 mm), 3.70" (93.98 mm), 2.90 oz (82.21 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 3" (76.20 mm)
- Depth
- 3.70" (93.98 mm)
- Height
- 0.80" (20.32 mm)
- Weight
- 2.90 oz (82.21 g)
- Length
- 1310 nm
What's in the Box
The package includes all necessary components for immediate deployment.
Highlights
- Converts 10/100 Mbps Ethernet to multi-mode fiber optic with ST connectors
- Supports distances up to 2 km (1.24 miles) over fiber
- Features 1 RJ-45 port and 1 ST duplex port
- Operates at 1310 nm wavelength for multi-mode fiber
- Supports full or half-duplex operation with LED link indicators
- Compatible with 3Com, Cisco, Lucent, and Nortel networks
- Includes Link Fault Pass-through (LFP) and flow control support
- External form factor with compact dimensions for flexible placement
- Powered by included AC adapter with Type M plug
- Backed by a 2-year limited warranty and RoHS/REACH/WEEE compliance
Specifications
| Specifications | |
|---|---|
| Manufacturer | StarTech.com |
| Manufacturer Part Number | MCM110ST2 |
| Brand Name | StarTech.com |
| Product Name | 10/100 Multi Mode Fiber Copper Fast Ethernet Media Converter ST 2 km |
| Packaged Quantity | 1 Each |
| Product Type | Transceiver/Media Converter |
| Interfaces/Ports | |
| Total Number of Ports | 2 |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 1 |
| Number of ST Ports | 1 |
| ST Port Type | Duplex |
| Media & Performance | |
| Media Type Supported | Optical Fiber,Twisted Pair |
| Fiber Mode Supported | Multi-mode |
| Fiber Optic Cable Wavelength | 1310 nm |
| Maximum Distance Supported | 2 km (1.24 Mile) |
| Network & Communication | |
| Ethernet Technology | Fast Ethernet |
| Network Technology | 10Base-T,100Base-FX |
| Power Description | |
| Power Source | AC Adapter |
| Power Consumption | 2.40 W |
| Plug/Connector Type | Type M |
| Physical Characteristics | |
| Form Factor | External |
| Height | 0.80" (20.32 mm) |
| Width | 3" (76.20 mm) |
| Depth | 3.70" (93.98 mm) |
| Weight (Approximate) | 2.90 oz (82.21 g) |
| Miscellaneous | |
| Package Contents | 10/100 Multi Mode Fiber Copper Fast Ethernet Media Converter ST 2 km 1 x Power Adapter 1 x Instruction Manual |
| Environmentally Friendly | Yes |
| Environmental Certification | EU RoHS |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) 2,Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
| Warranty | |
| Limited Warranty | 2 Year |
User Manual
FAQ
What does this media converter do?
This converter bridges copper and fiber optic networks by converting 10/100 Mbps Ethernet signals from an RJ-45 port to multi-mode fiber optic with ST connectors. It allows you to extend network connections up to 2 kilometers, overcoming the distance limitations of standard copper Ethernet cabling.
What type of fiber optic cable does it support?
It supports multi-mode fiber optic cable with a wavelength of 1310 nm. The converter uses ST duplex connectors, which are common in many existing fiber installations, making it suitable for upgrades or extensions in multi-mode fiber environments.
How far can it extend my network?
It supports a maximum distance of 2 kilometers (approximately 1.24 miles) over multi-mode fiber optic cable. This extended reach is ideal for connecting network segments between buildings or across large facilities where copper Ethernet would suffer signal loss.
What power source does it require?
The converter is powered by an included AC adapter with a Type M plug. It has a low power consumption of 2.40 watts, and its external power design ensures reliable operation without drawing power from network equipment.
Is it compatible with my existing network equipment?
Yes, it is compatible with networks from major vendors like 3Com, Cisco, Lucent, and Nortel. It supports IEEE 802.3 standards including 10Base-T and 100Base-FX, ensuring interoperability with most Fast Ethernet switches and routers.
What features support network management?
It includes Link Fault Pass-through (LFP) to maintain network integrity, LED indicators for easy link monitoring, and support for IEEE 802.1q Tag VLAN pass-through and Q in Q double-tagged frames. Flow control (Pause) is also supported to manage data traffic effectively.
