StarTech. com MDP2DPMF6IN Mini DisplayPort to DisplayPort Adapter - 6 Inch Cable - 4K x 2K 60Hz - DP 1. 2 - 21. 6 Gbps - MST Support - Black
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This video cable adapter implements DisplayPort 1.2 specifications with High Bit Rate 2 (HBR2) support, enabling 4K x 2K resolution at 60Hz refresh rates. The 32 AWG cable construction with gold-plated connectors ensures minimal signal degradation over the 6-inch distance, while backward compatibility with DisplayPort 1.1 maintains connectivity with older display equipment.
Advanced features include 8-channel audio support, GTC (Global Time Code) for precise audio synchronization, and 3D stereo capability at 2560x1600 resolution with 120Hz refresh rates. The adapter's electrical design incorporates comprehensive EMI shielding to prevent interference in electrically noisy environments.
This section brings together practical product details such as Cable Type, Cable Length, Connector Type on First End, Color Family, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
This adapter delivers professional-grade video connectivity with features designed for reliability in continuous operation environments. The combination of robust construction and advanced DisplayPort technology ensures consistent performance for graphics-intensive applications.
These strengths make the product easier to deploy and manage in real environments, especially where reliability, usability, and day-to-day operational continuity matter. Notable benefits include Durability Engineering, Signal Integrity.
Durability Engineering
ABS connector shells with flexible PVC strain relief prevent cable damage from repeated bending, while the metal substructure provides additional EMI shielding for cleaner signal transmission.
- Fray-resistant jacket
- Damage-resistant construction
- EMI protection
Signal Integrity
Gold-plated connectors maintain optimal electrical contact, while Al-Mylar foil with copper braid shielding minimizes electromagnetic interference for superior video and audio quality.
- Gold-plated contacts
- Dual-layer shielding
- 32 AWG wire gauge
Deployment / Use Cases
This Mini DisplayPort to DisplayPort adapter serves as an essential connectivity solution for modern computing setups where space constraints or specific port requirements exist. The 6-inch cable length provides just enough slack for clean cable management in desktop, workstation, and presentation environments.
Common applications include connecting laptops with Mini DisplayPort outputs to external monitors in office settings, linking professional workstations with AMD FirePro or NVIDIA NVS graphics cards to 4K displays, and extending Microsoft Surface Pro devices to larger screens for enhanced productivity. The adapter also supports projector connections in boardroom and classroom presentations.
Professional Workstations
Compatible with AMD FirePro W9100/8100 and NVIDIA NVS 810/510 graphics cards for CAD, video editing, and 3D rendering applications requiring high-resolution output.
Mobile Computing
Ideal for Microsoft Surface Pro 1-6 tablets and Ultrabooks with Mini DisplayPort, enabling external monitor connectivity for expanded workspace.
Physical Profile
The adapter features a compact 6-inch black PVC cable that minimizes desk clutter while providing sufficient length for flexible positioning. The black ABS connectors with nickel and gold plating offer both aesthetic appeal and corrosion resistance. At just 0.67 ounces, the lightweight design reduces strain on device ports during movement or adjustment.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 0.67 oz (19 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Weight
- 0.67 oz (19 g)
- Length
- 6" (152.40 mm)
Highlights
- Supports 4K x 2K resolution at 60Hz refresh rates
- DisplayPort 1.2 with 21.6 Gbps bandwidth
- 6-inch cable ideal for compact setups
- Multi-Stream Transport (MST) for daisy-chaining displays
- Gold-plated connectors for optimal signal integrity
- Backward compatible with DisplayPort 1.1 devices
- 8-channel audio support with GTC synchronization
- ABS connectors with PVC strain relief for durability
- EMI shielding with Al-Mylar foil and copper braid
- Lifetime warranty from StarTech.com
Specifications
| Specifications | |
|---|---|
| Manufacturer | StarTech.com |
| Manufacturer Part Number | MDP2DPMF6IN |
| Brand Name | StarTech.com |
| Product Name | 6in Mini DisplayPort to DisplayPort Video Cable Adapter - M/F |
| Packaged Quantity | 1 Each |
| Product Type | Video Cable Adapter |
| Technical Information | |
| Cable Type | DisplayPort/Mini DisplayPort |
| Cable Length | 6" (152.40 mm) |
| Connector Type on First End | Mini DisplayPort Digital Audio/Video - Male |
| Connector Gender on First End | Male |
| Connector on First End Details | 1 x 20-pin Mini DisplayPort Digital Audio/Video - Male |
| Connector Type on Second End | DisplayPort 1.2 Digital Audio/Video - Female |
| Connector Gender on Second End | Female |
| Connector on Second End Details | 1 x 20-pin DisplayPort 1.2 Digital Audio/Video - Female |
| Connector Plating | Nickel,Gold |
| Shielding | Yes |
| Device Supported | Monitor,Notebook,Video Device |
| American Wire Gauge | 32 AWG |
| Data Transfer Rate | 21.6 Gbit/s |
| Supported Resolution | 3840 x 2400 |
| Features | Multi-Stream Transport (MST) Support,Flexible,Strain Relief,Fray Resistant,Damage Resistant,EMI Protection |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Jacket Material | Polyvinyl Chloride (PVC) |
| Weight (Approximate) | 0.67 oz (19 g) |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Certification | EU RoHS |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) 2,Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Country of Origin | China |
| Warranty | |
| Limited Warranty | Lifetime |
User Manual
FAQ
What resolution does this Mini DisplayPort to DisplayPort adapter support?
This adapter supports up to 3840 x 2400 resolution (4K x 2K) at 60Hz refresh rates. It utilizes DisplayPort 1.2 technology with High Bit Rate 2 (HBR2) to deliver the bandwidth necessary for high-resolution video transmission while maintaining smooth performance for professional applications.
Is this adapter backward compatible with older DisplayPort versions?
Yes, the adapter maintains backward compatibility with DisplayPort 1.1 devices. This ensures connectivity with a wide range of existing display equipment while still providing the enhanced capabilities of DisplayPort 1.2 when connected to compatible sources and displays.
What is the cable length and why is 6 inches optimal?
The cable measures 6 inches (152.40 mm), providing just enough length for clean cable management in tight spaces while minimizing signal degradation. This compact design reduces desk clutter and is ideal for connecting devices in close proximity, such as laptops to external monitors or workstations to adjacent displays.
Does this adapter support Multi-Stream Transport (MST)?
Yes, the adapter fully supports Multi-Stream Transport, allowing you to daisy-chain multiple DisplayPort monitors from a single Mini DisplayPort output. This feature is particularly useful for multi-monitor workstation setups where you need to extend your desktop across several displays without requiring additional graphics card outputs.
What audio capabilities does this adapter provide?
The adapter supports 8-channel audio transmission with Global Time Code (GTC) synchronization for precise audio channel timing. This ensures that audio remains perfectly synchronized with video content, which is essential for professional multimedia applications, gaming, and home theater setups.
What devices are compatible with this Mini DisplayPort adapter?
The adapter works with monitors, notebooks, and video devices featuring Mini DisplayPort outputs. Specific compatible devices include Microsoft Surface Pro tablets (generations 1-6), laptops with Mini DisplayPort, and workstations equipped with AMD FirePro or NVIDIA NVS graphics cards. It also connects to 4K monitors, projectors, and standard DisplayPort displays.
What resolution or display format is specified?
It features a display specification of 3840 x 2400, giving you clear visuals for work and media use.
What refresh rate or brightness details are available?
Display-oriented products are best judged through screen, connectivity, and installation specifications. Those facts help buyers confirm visual fit, mounting flexibility, and deployment suitability more clearly than generic summary text.
