APC by Schneider Electric N252-024 24-Port Cat6 Patch Panel - 1U Rackmount - 110 Punch Down - TAA Compliant
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This patch panel features 24 ports with EIA/TIA 2/32 spacing, ensuring proper cable separation and reducing crosstalk for optimal Cat6 performance. The 110 punch-down blocks provide secure and efficient termination without requiring specialized tools, streamlining installation and maintenance workflows.
The panel's 1U height (1.75") and 19" rack width compatibility allow seamless integration into standard server racks and network cabinets, maximizing space efficiency in dense environments. Its RoHS compliance and environmentally friendly construction align with modern sustainability standards.
This section brings together practical product details such as Total Number of Ports, Number of Network (RJ-45) Ports, Number of RJ-11 Ports, Compatible Rack Unit, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The N252-024 delivers reliable performance and organizational efficiency for network infrastructure. Its design prioritizes ease of installation, durability, and compliance with industry standards.
Efficient Cable Management
The 110 punch-down termination system allows quick and secure cable connections, reducing installation time and minimizing errors. Labeling areas and clear port numbering simplify cable tracing and troubleshooting.
- 110-type termination blocks
- EIA/TIA 2/32 spacing
- Front-accessible ports
Rack-Optimized Design
With a 1U form factor and 19" rack width, this patch panel fits standard server racks without wasting space. The sturdy metal construction ensures stability in high-density environments.
- 1U height (1.75")
- 19" rack width compatible
- Durable metal housing
Deployment / Use Cases
This patch panel is ideal for organizations requiring organized and scalable network cabling. Its versatility supports both data and voice applications, making it a core component in modern IT infrastructure.
Common deployments include data center server racks, network closets in office buildings, educational institutions, and government facilities where TAA compliance is mandatory. The panel's Cat6 compatibility ensures support for Gigabit Ethernet and future network upgrades.
Data Center Installations
Integrate into server racks to manage connections between switches, servers, and other network devices. The high port density supports scalable growth in enterprise environments.
Office Network Closets
Use in wiring closets to terminate cables from workstations, VoIP phones, and wireless access points. The RJ-11 ports allow simultaneous telephony and data network management.
Highlights
- 24-port Cat6 patch panel with RJ-45 and RJ-11 compatibility
- 1U rackmount design for standard 19" server racks
- 110-type punch-down termination for secure cable connections
- EIA/TIA 2/32 spacing reduces crosstalk and improves organization
- TAA compliant for government and institutional procurement
- RoHS environmental compliance
- Lifetime limited warranty
- Made in Taiwan with quality construction
Specifications
| Specifications | |
|---|---|
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | N252024 |
| Brand Name | Tripp Lite series |
| Product Model | N252-024 |
| Product Name | 24 Port Cat6 Network Patch Panel |
| Product Type | Network Patch Panel |
| Interfaces/Ports | |
| Total Number of Ports | 24 |
| Number of Network (RJ-45) Ports | 24 |
| Number of RJ-11 Ports | 24 |
| Physical Characteristics | |
| Compatible Rack Unit | 1U |
| Compatible Rack Width | 19" |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
| Warranty | |
| Limited Warranty | Lifetime |
User Manual
FAQ
What types of cables can I terminate with this patch panel?
This patch panel supports Cat6 and Cat5e Ethernet cables for RJ-45 connections, as well as standard telephony cables for RJ-11 ports. The 110 punch-down blocks are designed for solid conductor cables commonly used in structured cabling installations.
Is this patch panel compatible with my existing server rack?
Yes, the N252-024 is designed for standard 19" wide server racks and occupies 1U of vertical space (1.75" height). It includes mounting hardware for easy installation in most data center and network cabinet environments.
What does TAA compliance mean for this product?
TAA (Trade Agreements Act) compliance indicates that this patch panel meets federal procurement requirements for government purchases, including GSA Schedule contracts. It ensures the product is manufactured in a designated country, making it suitable for public sector and institutional deployments.
How does the 110 punch-down termination work?
The 110 termination system uses insulation-displacement contacts that secure cable conductors when punched down with a tool. This method provides reliable connections without stripping insulation, reducing installation time and maintaining signal integrity for high-speed networks.
What warranty comes with this patch panel?
APC by Schneider Electric provides a lifetime limited warranty for the N252-024 patch panel. This warranty covers defects in materials and workmanship for the product's usable life, offering long-term reliability for your network infrastructure investment.
Can I use this patch panel for both data and voice networks?
Yes, the panel includes 24 RJ-45 ports for Ethernet data networks and 24 RJ-11 ports for telephony connections. This dual functionality allows you to manage both data and voice cabling in a single 1U space, simplifying infrastructure organization.
