Middle Atlantic Multi-Mount Rack Mounted Power Distribution Unit - 20 Amp, 16 Outlet PDU - NEMA 5-20P - 16 x NEMA L5-20R - 120 V AC - (PDS-1620R-NS)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Description
- Multi-mount Rackmount Power, 16 Outlet, 20A, 3-Step Sequencing
- 9' 12/3 SignalSAFE™ Power Cord
Plug/Connector Type: NEMA 5-20P
Receptacle Type: NEMA L5-20R
Receptacle Detail: 16 x NEMA L5-20R
Input Voltage: 120 V AC
Input Current: 20 A
Mounting Orientation: Horizontal/Vertical
Mount Type: Rack-mountable
Rack Height: 1U
Height: 1.75" (44.45 mm)
Width: 19" (482.60 mm)
Depth: 4.53" (115.06 mm)
Package Contents:
Environmentally Friendly: Yes
Environmental Certification: GREENGUARD
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Limited Warranty: 3 Year
[custom-specifications]
| Specifications | |
| Manufacturer | Legrand Group |
| Manufacturer Part Number | PDS-1620R-NS |
| Manufacturer Website Address | http://www.legrand.com |
| Brand Name | Middle Atlantic |
| Product Series | PDS |
| Product Model | PDS-1620R-NS |
| Product Name | Multi-Mount Rack Mounted Power Distribution Unit - 20 Amp, 16 Outlet PDU |
| Product Type | PDU |
| Technical Information | |
| Plug/Connector Type | NEMA 5-20P |
| Receptacle Type | NEMA L5-20R |
| Receptacle Detail | 16 x NEMA L5-20R |
| Power Description | |
| Input Voltage | 120 V AC |
| Input Current | 20 A |
| Physical Characteristics | |
| Mounting Orientation | Horizontal/Vertical |
| Mount Type | Rack-mountable |
| Rack Height | 1U |
| Height | 1.75" (44.45 mm) |
| Width | 19" (482.60 mm) |
| Depth | 4.53" (115.06 mm) |
| Miscellaneous | |
| Package Contents |
|
| Environmentally Friendly | Yes |
| Environmental Certification | GREENGUARD |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 3 Year |
