SDC Excel E300 Micro Cabinet Lock - 12 V DC, 24 V DC - 136.08 kg Holding Force - Anodized Aluminum (E300)

Marketing Information: Eliminate keys and expand the reach of access control systems to drawers, cabinets and lockers - any critical use - where the application of a compact, specialized electromagnetic lock provides a higher level of security. SDC's E300 is a connected access control solution that is virtually maintenance free and has a lock status output for remote monitoring and system application needs.

FEATURES

• Failsafe Operation
• Easy installation in small cabinets or restricted spaces. No special tools are required.
• No moving parts, virtually maintenance free.
• Spike and surge protection for solid-state devices on same line.
• Lock Status
• Interlocking Quick Mount Assembly
• Mounting Bracket with Sheet Metal Screws
• Wire Access Chamber with Terminal Block
• Dual Voltage 12/24VDC
• 628 Clear Anodized Aluminum housing

Holding Force: 136.08 kg

Armature Plate Height: 1.25" (31.75 mm)

Armature Plate Depth: 0.31" (7.94 mm)

Features: Fail Safe,Dual Voltage

Input Voltage: 12 V DC,24 V DC

Input Current: 360 mA,180 mA

Product Material: Anodized Aluminum

Finishing: Clear Anodized

Lock Height: 1.63" (41.28 mm)

Lock Depth: 0.88" (22.23 mm)

Lock Length: 7" (177.80 mm)

Application/Usage: Cabinet,Machine Equipment Housing,Display Case,Drawer,Gun Safe,Package Pass-through Door

Country of Origin: China
