Tripp Lite by Eaton SRW18USG SmartRack 18U Low-Profile Switch-Depth Wall-Mount Rack Enclosure Cabinet - 250 lb Capacity
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This SmartRack enclosure supports 19" rack-mount equipment up to 20.5" deep, making it compatible with most network switches, patch panels, and related hardware. The internal rack dimensions provide 18U of vertical mounting space with standard EIA-310-D hole patterns.
Ventilation is engineered through perforated steel panels at the sides, top, and bottom to promote adequate airflow for heat dissipation. The cabinet maintains a static weight capacity of 250 pounds, ensuring reliable support for fully loaded configurations.
This section brings together practical product details such as Application/Usage, Features, Form Factor, Color Family, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The SRW18USG combines secure equipment protection with practical accessibility features ideal for network closets, server rooms, and telecommunications installations.
These strengths make the product easier to deploy and manage in real environments, especially where reliability, usability, and day-to-day operational continuity matter. Notable benefits include Hinged Wall Mount, Locking Steel Cabinet, Clear Acrylic Window, Integrated Cable Management, RoHS Compliant.
For buyers comparing similar models, the strongest advantage is usually the balance between dependable day-to-day operation and a simpler rollout experience. That means less time spent troubleshooting fit, compatibility, or user adoption after installation, which is especially important for shared business environments and repeat purchasing decisions.
Deployment / Use Cases
This wall-mount rack enclosure is purpose-built for networking infrastructure where floor space is limited or wall mounting is preferred. Its switch-depth design makes it particularly suitable for housing Ethernet switches, fiber patch panels, and network management hardware in commercial offices, educational facilities, and retail environments.
The hinged mounting system allows technicians to swing the entire cabinet away from the wall for unobstructed access to cable connections and equipment ports. This eliminates the need for awkward side access or complete unmounting during routine maintenance, reducing downtime and installation complexity.
Network Closet Installation
Ideal for consolidating patch panels, switches, and power distribution units in telecommunications rooms where floor-standing racks are impractical.
- Maximizes vertical space utilization
- Keeps cables organized and protected
- Provides secure locking storage
Shallow-Depth Equipment Housing
Specifically accommodates network switches and patch panels that don't require full-depth server rack dimensions.
- Optimized for 10.42" rack depth
- Supports equipment up to 20.5" deep
- Reduces overall wall projection
Physical Profile
The enclosure features a professional black powder coat finish that resists scratches and corrosion. Steel construction provides structural integrity while the acrylic window maintains equipment visibility without compromising security. Four-point locking mechanism secures the front door, and the unit includes pre-installed mounting brackets for straightforward wall attachment.
- Width
- 23.62" (599.95 mm)
- Depth
- 21.60" (548.64 mm)
- Height
- 35.60" (904.24 mm)
- Weight
- 200 lb (90718.47 g)
What's in the Box
The SRW18USG ships with all necessary hardware for assembly and mounting.
Highlights
- 18U wall-mount rack enclosure with 10.42" rack depth for switch and patch panel applications
- Hinged design swings away from wall for full front and rear equipment access
- Locking steel cabinet with shatter-resistant clear acrylic front door window
- Vented construction at sides, top, and bottom for optimal airflow
- 250 lb static weight capacity supports fully loaded configurations
- Black powder coat finish on durable steel construction
- Includes comprehensive mounting hardware package
- RoHS compliant and backed by 5-year limited warranty
Specifications
| Specifications | |
|---|---|
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | SRW18USG |
| Brand Name | Tripp Lite series |
| Product Line | SmartRack |
| Product Model | SRW18USG |
| Product Name | SRW18USG SmartRack 18U Low-Profile Switch-Depth WallMount Rack Enclosure Cabinet |
| Product Type | Rack Cabinet |
| Technical Information | |
| Application/Usage | LAN Switch,Patch Panel |
| Features | Cable Management |
| Physical Characteristics | |
| Form Factor | Wall Mountable |
| Color Family | Black |
| Product Color | Black Powder Coat |
| Product Material | Acrylic,Steel |
| Maximum Weight Capacity | 200 lb (90718.47 g) |
| Static/Stationary Weight Capacity | 250 lb (113398.09 g) |
| Height | 35.60" (904.24 mm) |
| Width | 23.62" (599.95 mm) |
| Depth | 21.60" (548.64 mm) |
| Rack Height | 18U |
| Rack Width | 19" (482.60 mm) |
| Rack Depth | 10.42" (264.67 mm) |
| Weight (Approximate) | 96 lb (43544.87 g) |
| Miscellaneous | |
| Package Contents | SRW18USG SmartRack 18U Low-Profile Switch-Depth WallMount Rack Enclosure Cabinet 42 x M6 Screws 42 x M6 Cage Nuts 42 x M6 Washers 42 x 12-24 Screws 2 x Keys Owner's Manual |
| Assembly Required | No |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 5 Year |
User Manual
FAQ
What is the maximum equipment depth this rack enclosure can accommodate?
The SRW18USG is designed to support standard 19" rack-mount equipment up to 20.5" deep. The internal rack depth measures 10.42", making it ideal for network switches, patch panels, and other shallow-depth networking hardware typically found in telecommunications closets and network distribution points.
How does the hinged wall mount system work?
This enclosure features a hinged mounting bracket that allows the entire cabinet to swing away from the wall. This provides complete front and rear access to all installed equipment without requiring technicians to unmount the unit. The hinge mechanism is robust enough to support the fully loaded 250 lb capacity while maintaining smooth operation.
What type of locking mechanism does the cabinet include?
The SRW18USG features a four-point locking system on the front door with two included keys. The locking steel cabinet provides physical security for valuable networking equipment while the shatter-resistant clear acrylic window maintains visibility of installed devices without compromising protection.
What ventilation features are included for heat management?
The enclosure incorporates perforated steel panels at the sides, top, and bottom to promote natural convection airflow. This ventilation design helps dissipate heat generated by installed networking equipment while maintaining the structural integrity and security of the cabinet. The design balances airflow requirements with physical protection needs.
What hardware is included for mounting equipment inside the rack?
The package includes 42 M6 screws, 42 M6 cage nuts, 42 M6 washers, and 42 12-24 screws to accommodate various rack-mount equipment configurations. This comprehensive hardware kit supports standard EIA-310-D hole patterns and provides flexibility for mounting different types of networking devices within the 18U of available space.
What is the weight capacity difference between static and maximum load ratings?
The SRW18USG has a static weight capacity of 250 pounds for stationary equipment loads and a maximum weight capacity of 200 pounds for dynamic loading situations. The static rating applies to equipment that remains in place once installed, while the maximum rating accounts for movement during installation or maintenance procedures.
