StarTech. com MCM110SC2P 10/100 Multi Mode Fiber to Ethernet Media Converter with PoE - SC 2km
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This media converter implements Fast Ethernet technology with support for 10Base-T, 100Base-FX, and 100Base-TX network standards. The RJ-45 port features auto-negotiation and auto-crossover functionality, automatically detecting half or full duplex transfer modes for seamless integration with existing network infrastructure.
Network performance features include support for IEEE 802.1q VLAN tagging pass-through, Q in Q double tagged frame transparency, and flow control with pause functionality. The device can forward packets up to 1600 bytes maximum and includes Link Fault Pass-Through (LFP) capability for network monitoring and troubleshooting.
This section brings together practical product details such as Total Number of Ports, Network (RJ-45), Number of PoE (RJ-45) Ports, Media Type Supported, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The MCM110SC2P combines fiber extension with Power over Ethernet delivery in a single compact device, reducing equipment requirements for network deployments that need both connectivity types. The PoE PD port can power compatible devices such as wireless access points, IP cameras, or VoIP phones while extending their network connection over fiber.
Extended Network Reach
Convert copper Ethernet to multimode fiber optic connections to overcome distance limitations of twisted pair cabling. Support up to 2 km distances with SC connectors for campus, industrial, or outdoor deployments.
- 2 km maximum distance
- SC duplex connectors
- Multimode fiber support
PoE Integration
Deliver both data and power over the same connection with the integrated PoE PD port. Simplify deployments by eliminating separate power sources for compatible endpoints.
- PoE PD port type
- Single power source
- Device compatibility
Deployment / Use Cases
This media converter is ideal for extending network segments beyond the 100-meter limitation of standard Ethernet cabling. Common applications include connecting buildings across a campus, linking network equipment in industrial environments, or establishing connections in environments with electromagnetic interference where fiber provides superior signal integrity.
The PoE capability makes this converter particularly useful for powering remote network devices such as outdoor wireless access points, security cameras, or network sensors that require both data connectivity and power delivery. The compact external design allows for flexible placement on desks, shelves, or mounted surfaces without requiring rack space.
Building-to-Building Connectivity
Connect network equipment between separate buildings using existing multimode fiber infrastructure. Maintain network performance over distances up to 2 km while avoiding ground potential differences and lightning risks associated with copper connections.
Industrial Network Extensions
Deploy in manufacturing facilities, warehouses, or outdoor environments where electromagnetic interference affects copper cable performance. Fiber optic immunity to EMI ensures reliable network connectivity in challenging conditions.
Physical Profile
The external form factor measures 3" wide × 3.70" deep × 0.80" high (76.20 mm × 93.98 mm × 20.32 mm) and weighs approximately 3 ounces (85.05 g). This compact and lightweight design enables flexible placement options without requiring dedicated rack space. The unit operates with an included AC adapter featuring a Type M plug connector.
- Width
- 3" (76.20 mm)
- Depth
- 3.70" (93.98 mm)
- Height
- 0.80" (20.32 mm)
- Weight
- 3 oz (85.05 g)
- Length
- 1310 nm
What's in the Box
The package includes all necessary components for immediate deployment of the media converter in your network environment.
Highlights
- Converts Fast Ethernet between twisted pair and multimode fiber optic cable
- Extends network connections up to 2 km using SC duplex connectors
- Includes one PoE PD port for powering compatible network devices
- Supports 10/100 Mbps auto-negotiation and auto-crossover on RJ-45 port
- Compact external design measures 3" × 3.70" × 0.80" (76.20 mm × 93.98 mm × 20.32 mm)
- Operates at 1310 nm wavelength with multimode fiber support
- Compatible with 62.5/125 µm and 50/125 µm fiber optic cables
- Features VLAN tagging pass-through and flow control capabilities
- Includes AC power adapter with Type M connector
- Backed by 2-year limited warranty and TAA compliance
Specifications
| Specifications | |
|---|---|
| Manufacturer | StarTech.com |
| Manufacturer Part Number | MCM110SC2P |
| Brand Name | StarTech.com |
| Product Name | 10/100 Multi Mode Fiber to Ethernet Media Converter SC 2km with PoE |
| Packaged Quantity | 1 Each |
| Product Type | Transceiver/Media Converter |
| Interfaces/Ports | |
| Total Number of Ports | 2 |
| Network (RJ-45) | Yes |
| Number of PoE (RJ-45) Ports | 1 |
| PoE Port Type | PD |
| Number of SC Ports | 1 |
| SC Port Type | Duplex |
| Media & Performance | |
| Media Type Supported | Optical Fiber,Twisted Pair |
| Fiber Mode Supported | Multi-mode |
| Fiber Optic Cable Wavelength | 1310 nm |
| Maximum Distance Supported | 2 km (1.24 Mile) |
| Fiber Optic Cable Core/Cladding Specification | 62.5/125 µm,50/125 µm |
| Network & Communication | |
| Ethernet Technology | Fast Ethernet |
| Network Technology | 10Base-T,100Base-FX,100Base-TX |
| Power Description | |
| Power Source | AC Adapter |
| Power Consumption | 4.80 W |
| Plug/Connector Type | Type M |
| Physical Characteristics | |
| Form Factor | External |
| Height | 0.80" (20.32 mm) |
| Width | 3" (76.20 mm) |
| Depth | 3.70" (93.98 mm) |
| Weight (Approximate) | 3 oz (85.05 g) |
| Miscellaneous | |
| Package Contents | 10/100 Multi Mode Fiber to Ethernet Media Converter SC 2km with PoE 1 x Power Adapter 1 x Instruction Sheet |
| Environmentally Friendly | Yes |
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
| Warranty | |
| Limited Warranty | 2 Year |
User Manual
FAQ
What type of fiber optic cable does this media converter support?
The MCM110SC2P supports multimode fiber optic cables with either 62.5/125 µm or 50/125 µm core/cladding specifications. It uses SC duplex connectors and operates at 1310 nm wavelength for optimal performance with standard multimode fiber installations.
What is the maximum distance supported by this fiber to Ethernet converter?
This media converter supports distances up to 2 kilometers (1.24 miles) when using multimode fiber optic cable. This extended reach allows network connections far beyond the 100-meter limitation of standard twisted pair Ethernet cabling.
How does the PoE functionality work on this device?
The converter includes one PoE PD (Powered Device) port that can receive both data and power over a single Ethernet connection. This allows you to power compatible devices such as wireless access points or IP cameras while extending their network connection over fiber optic cable.
What network standards does this media converter support?
The device supports IEEE 802.3 10Base-T, 802.3u 100Base-TX, and 100Base-FX standards for Fast Ethernet connectivity. It features auto-negotiation and auto-crossover on the RJ-45 port, automatically detecting half or full duplex transfer modes for seamless network integration.
What are the physical dimensions of this media converter?
The external unit measures 3 inches wide × 3.70 inches deep × 0.80 inches high (76.20 mm × 93.98 mm × 20.32 mm) and weighs approximately 3 ounces (85.05 g). This compact form factor allows flexible placement without requiring rack space.
What is included in the package with this media converter?
The package contains the 10/100 Multi Mode Fiber to Ethernet Media Converter SC 2km with PoE unit, one AC power adapter with Type M connector, and an instruction sheet. All necessary components are included for immediate deployment in your network environment.
