Product Features
Technical Overview
This CAT6 patch cable operates at 250 MHz and uses 4-pair UTP (Unshielded Twisted Pair) construction with 24 AWG stranded copper wiring. It supports Multi-Gigabit Ethernet speeds including 1, 2.5, 5, and 10 Gbps, with backward compatibility to CAT5e and earlier standards. The cable features UL certified wiring (E132276-A) and complies with IEEE 802.3bt for PoE applications up to 100W.
The RJ45 connectors have gold plating to prevent oxidation and maintain signal integrity. The CMG-rated PVC jacket meets plenum requirements for safe installation in air handling spaces. Environmental compliance includes RoHS, REACH, and WEEE directives, making it suitable for environmentally conscious deployments.
Key Product Advantages
This cable combines high-speed performance with robust construction for reliable network operations. The 100% copper conductors and gold-plated connectors minimize signal loss and prevent corrosion, reducing network downtime. The snagless molded boots and strain relief design make installation and maintenance easier in congested wiring environments.
PoE Ready
Supports up to 100W Power over Ethernet for devices like VoIP phones, wireless access points, and security cameras, reducing cable clutter and installation costs.
- IEEE 802.3bt compliant
- UL rated wiring
- Reduces cable heating
Durable Construction
Features a high-quality PVC jacket that resists bending, fraying, and damage, with stranded copper conductors for flexibility and longevity.
- CMG rated jacket
- Strain relief design
- Corrosion resistant
Deployment / Use Cases
This 125-foot CAT6 patch cable is ideal for extending network connections in office environments, data centers, and industrial settings. Its length makes it suitable for connecting workstations to distribution panels, wall outlets to hubs, or network devices across large rooms.
Common applications include connecting VoIP phones with PoE support, linking security cameras to network video recorders, and extending connections for wireless access points. The cable's compatibility with earlier standards allows seamless integration into existing CAT5e infrastructure, while its 10 Gbps capability future-proofs network upgrades.
Office Networking
Connect computers, printers, and IP phones across large office spaces with reliable gigabit speeds and PoE support.
Security Systems
Power and connect IP cameras, access control systems, and other security devices with a single cable solution.
Physical Profile
The cable features a black PVC jacket that blends with most office and data center environments. With a weight of 3.50 pounds, it manages easily during installation while providing substantial length for flexible routing. The snagless molded boots protect connectors from damage and prevent accidental disconnection in cable management systems.
- Weight
- 3.50 lb (1587.57 g)
- Length
- 125 ft (38.10 m)
Highlights
- 125-foot CAT6 Ethernet patch cable with 10 Gbps speed support
- 100W Power over Ethernet (PoE) compliant with IEEE 802.3bt
- Gold-plated RJ45 connectors prevent corrosion and ensure reliable connections
- Snagless molded boots for easy installation and disconnection
- 24 AWG stranded copper conductors with 250 MHz rating
- Black PVC CMG-rated jacket resists bending and damage
- Backward compatible with CAT5e and earlier Ethernet standards
- Individually tested to ANSI/TIA-568-2.D Category 6 specifications
- UL certified wiring with lifetime warranty
- Environmentally compliant with RoHS, REACH, and WEEE directives
Specifications
| Specifications | |
|---|---|
| Manufacturer | StarTech.com |
| Manufacturer Part Number | N6PATCH125BK |
| Brand Name | StarTech.com |
| Product Name | Cat.6 UTP Patch Network Cable |
| Packaged Quantity | 1 Each |
| Product Type | Network Cable |
| Technical Information | |
| Cable Type | Category 6 |
| Cable Characteristic | Patch Cable |
| Cable Length | 125 ft (38.10 m) |
| Connector Type on First End | RJ-45 Network - Male |
| Connector on First End Details | 1 x RJ-45 Network - Male |
| Connector Type on Second End | RJ-45 Network - Male |
| Connector on Second End Details | 1 x RJ-45 Network - Male |
| Connector Plating | Gold |
| Shielding | No |
| Jacket Type | CMG |
| Device Supported | Network Device,Workstation,Hub,Distribution Panel,Wall Outlet |
| American Wire Gauge | 24 AWG |
| Data Transfer Rate | 10 Gbit/s |
| Boot Type | Snagless,Molded |
| Features | Stranded,Strain Relief,Damage Resistant,Bend Resistant,PoE,Corrosion Resistant |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Jacket Material | Polyvinyl Chloride (PVC) |
| Weight (Approximate) | 3.50 lb (1587.57 g) |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Country of Origin | China |
| Warranty | |
| Limited Warranty | Lifetime |
User Manual
FAQ
What is the maximum data speed supported by this CAT6 cable?
This cable supports data transfer rates up to 10 Gbps at distances up to 160 feet. It is also compatible with Multi-Gigabit Ethernet speeds including 1, 2.5, and 5 Gbps, making it suitable for both current network infrastructure and future upgrades.
Does this cable support Power over Ethernet (PoE)?
Yes, this cable supports up to 100W Power over Ethernet (PoE) and complies with IEEE 802.3bt standards. The 24 AWG stranded copper conductors and UL rated wiring ensure safe power delivery to devices like VoIP phones, wireless access points, and security cameras.
What type of connectors does this cable have?
Both ends feature RJ-45 male connectors with 50-micron gold plating to prevent corrosion and maintain signal integrity. The connectors have snagless molded boots that protect against accidental disconnection and make installation easier in tight spaces.
Is this cable shielded or unshielded?
This is an unshielded twisted pair (UTP) cable with no additional shielding. The 4-pair UTP construction provides reliable performance for most office and data center environments without the need for grounding that shielded cables require.
What is the jacket rating and material?
The cable has a CMG-rated jacket made of polyvinyl chloride (PVC). This rating indicates suitability for installation in plenum spaces (air handling areas), while the PVC material provides durability against bending, fraying, and environmental damage.
What warranty comes with this Ethernet cable?
StarTech provides a lifetime limited warranty for this cable, covering defects in materials and workmanship. The cable is individually tested to comply with ANSI/TIA-568-2.D Category 6 specifications, ensuring consistent performance and reliability.
