StarTech. com SFP10GSRXST Cisco SFP-10G-SR-X Compatible SFP+ Module - 10GBASE-SR - 10GbE Multimode Fiber LC - Hot-Swappable
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This SFP+ module operates at 10 Gbps using 850nm wavelength over multimode fiber, supporting distances up to 300 meters. The single LC duplex port provides a straightforward connection for fiber optic cabling, while the hot-pluggable design allows for installation and replacement without network downtime.
Digital Diagnostic Monitoring (DDM) support enables real-time reporting of transceiver status through SNMP network management tools, giving administrators visibility into temperature, voltage, optical power, and other key parameters. The module's environmental compliance includes RoHS, REACH, and WEEE directives, ensuring responsible manufacturing practices.
Relevant factors for this section include Application/Usage, Total Number of Ports, Connector Type, Interfaces/Ports Details. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
This transceiver combines certified compatibility with practical deployment features that benefit network administrators and IT teams.
Verified Cisco Compatibility
Tested to work with Cisco switches including Firepower, ASR9000, C9300, C3850, and C9500 series, ensuring reliable performance without voiding OEM support agreements.
- 100% Cisco SFP-10G-SR-X compatible
- Works with MSA compliant switches from multiple vendors
Network Management Ready
Digital Diagnostic Monitoring provides detailed status reporting to SNMP management tools, while hot-swappable installation minimizes disruption during maintenance.
- DDM support for real-time monitoring
- Hot-pluggable for easy deployment
Deployment / Use Cases
This SFP+ module serves as a cost-effective alternative to OEM transceivers in enterprise and data center environments where 10 Gigabit Ethernet over fiber is required.
Typical applications include connecting switches to servers in data centers, extending network segments across buildings, and upgrading existing infrastructure to 10GbE speeds. The compatibility with Cisco switches makes it particularly suitable for organizations with mixed-vendor environments or those seeking to expand network capacity without replacing entire systems.
Physical Profile
Measuring 0.50" x 0.50" x 2.30" (12.70 mm x 12.70 mm x 58.42 mm) and weighing just 0.80 ounces, this compact transceiver fits standard SFP+ slots without occupying excessive space. The small footprint allows for high-density deployments in switch chassis and network equipment where rack space is at a premium.
- Width
- 0.50" (12.70 mm)
- Depth
- 2.30" (58.42 mm)
- Height
- 0.50" (12.70 mm)
- Weight
- 0.80 oz (22.68 g)
Highlights
- 100% Cisco SFP-10G-SR-X compatible for reliable performance
- 10GBASE-SR 10 Gbps over multimode fiber with LC connectors
- Hot-swappable design for installation without network downtime
- Digital Diagnostic Monitoring (DDM) for SNMP management
- Works with Cisco Firepower, ASR9000, C9300, C3850, C9500 switches
- MSA compliant for broad switch compatibility
- Compact dimensions: 0.50" H x 0.50" W x 2.30" D
- Lifetime warranty backed by StarTech.com support
Specifications
| Specifications | |
|---|---|
| Manufacturer | StarTech.com |
| Manufacturer Part Number | SFP10GSRXST |
| Brand Name | StarTech.com |
| Product Name | Cisco SFP-10G-SR-X Compatible SFP+ Transceiver Module - 10GBASE-SR |
| Product Type | SFP+ |
| Packaged Quantity | 1 Each |
| Technical Information | |
| Application/Usage | Data Networking,Optical Network |
| Interfaces/Ports | |
| Total Number of Ports | 1 |
| Connector Type | LC |
| Interfaces/Ports Details | 1 x LC Duplex 10GBase-SR Network |
| Media & Performance | |
| Media Type Supported | Optical Fiber |
| Fiber Mode Supported | Multi-mode |
| Ethernet Technology | 10 Gigabit Ethernet |
| Network Technology | 10GBase-SR |
| Physical Characteristics | |
| Form Factor | Hot-pluggable,Hot-swappable |
| Height | 0.50" (12.70 mm) |
| Width | 0.50" (12.70 mm) |
| Depth | 2.30" (58.42 mm) |
| Weight (Approximate) | 0.80 oz (22.68 g) |
| Miscellaneous | |
| Compatibility | MSA Compliant Cisco Firepower Switches: ASR9000 C9300 C3850 C9500 |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Warranty | |
| Limited Warranty | Lifetime |
User Manual
FAQ
What Cisco switches is this SFP+ module compatible with?
This StarTech.com SFP10GSRXST module is 100% compatible with Cisco SFP-10G-SR-X and works with Cisco switches including Firepower series, ASR9000, C9300, C3850, and C9500 models. It has been tested for OEM host compatibility and won't void your Cisco support agreements.
What type of fiber and connectors does this transceiver use?
This SFP+ module supports multimode fiber with LC connectors. It operates at 850nm wavelength for 10GBASE-SR networks, providing 10 Gbps connectivity over distances up to 300 meters (984 feet) using standard multimode fiber optic cabling.
Does this module support hot-swapping during operation?
Yes, this transceiver features a hot-pluggable, hot-swappable form factor that allows installation and replacement without powering down the network switch. This enables maintenance and upgrades with minimal disruption to network operations.
What management features does this SFP+ module include?
The module includes Digital Diagnostic Monitoring (DDM) support that reports the transceiver's operational status to most SNMP network management tools. This provides visibility into temperature, voltage, optical power, and other parameters for proactive network monitoring.
Will this module work with non-Cisco network equipment?
Yes, this MSA compliant transceiver also works with switch models from Ubiquiti, D-Link, Netgear, Supermicro, TP-Link, and other vendors that accept uncoded SFP+ modules. The broad compatibility makes it suitable for mixed-vendor network environments.
What warranty and support does StarTech.com provide for this product?
StarTech.com backs this SFP+ module with a lifetime warranty for the life of the module itself. Their support includes access to technical advisors and ensures the module won't void your OEM equipment support agreements.
