StarTech.com Long Range 1000 ft USB VGA KVM Over CAT5/5e CAT6 UTP Extender - KVM Console Over Ethernet for multiple servers/PC's IT - (SV565UTPUL)

(No reviews) Write a Review
$546.84
SKU: SV565UTPUL
UPC: 65030839259
Availability: Toronto
Weight: 3.00 LBS
Adding to cart… The item has been added
  • High resolution support: Up to 1920x1200(WUXGA)/ 1600x1200(UXGA)
  • Kit includes both local and remote units
  • Compatibility mode enables hotkey commands to be passed to connected StarView KVMs
  • Max Resolution Limit feature caps the resolution to prevent the resolution setting from exceeding the capability of the connected display
  • USB computers are supported at the host and remote locations (USB keyboard and mouse required for remote console)
  • Supports auto-switching between host and remote users or dedicated control
    Marketing Information:

    The SV565UTPUL Long Range USB VGA KVM Console Extender over Cat5 UTP (1000 ft) lets you control a server, computer or multiple computers (connected through KVM Switch) over a standard Cat5 or Cat6 UTP network cable connection, at distances of up to 1000ft (300m) away.

    You can use your existing USB keyboard, USB mouse, and monitor to access both the server room and your office computer, saving space and avoiding the need for a dedicated remote console by allowing you to switch between workstation view and KVM view at the remote location.

    This product is TAA compliant and backed by a Startech.com 3-year warranty with free lifetime technical support.

    More from the Manufacturer


    Connectivity Technology: Wired
    KVM Technology: Analog
    Number of Computers Supported: 2
    Number of Local Users Supported: 1
    Number of Remote Users Supported: 1
    Maximum Operating Distance: 984.25 ft (300000 mm)
    Graphic Mode: WUXGA
    Maximum Video Resolution: 1920 x 1200
    Network (RJ-45): Yes
    USB: Yes
    VGA: Yes
    Number of VGA Ports: 2
    Number of Network (RJ-45) Ports: 2
    Number of USB Ports: 4
    Input Voltage:
    • 120 V AC
    • 230 V AC

    Input Voltage Range: 110 V AC - 240 V AC
    Form Factor:
    • Rack-mountable
    • Desktop

    Package Contents:
    • 2 x KVM Extenders (1x Local, 1x Remote)
    • 2 x 2n1 USB VGA KVM Cables
    • 1 x Rubber Feet
    • 1 x Universal power adapter: comes ready for NA/EU/UK only when you buy in NA/EU/UK; comes ready for Australia and New Zealand only when you buy in Australia and New Zealand
    • 1 x User Manual

    Environmentally Friendly: Yes
    Environmental Certification:
    • RoHS
    • WEEE
    • REACH

    TAA Compliant: Yes
    Limited Warranty: 3 Year

[custom-specifications]

Specifications
Manufacturer: StarTech.com
Manufacturer Part Number: SV565UTPUL
Manufacturer Website Address: http://www.startech.com
Brand Name: StarTech.com
Product Name: USB VGA KVM Console Extender over Cat5 UTP 1000 ft
Product Type: KVM Console/Extender
Technical Information
Connectivity Technology: Wired
KVM Technology: Analog
Number of Computers Supported: 2
Number of Local Users Supported: 1
Number of Remote Users Supported: 1
Maximum Operating Distance: 984.25 ft (300000 mm)
Video
Graphic Mode: WUXGA
Maximum Video Resolution: 1920 x 1200
Interfaces/Ports
Network (RJ-45): Yes
USB: Yes
VGA: Yes
Number of VGA Ports: 2
Number of Network (RJ-45) Ports: 2
Number of USB Ports: 4
Power Description
Input Voltage:
  • 120 V AC
  • 230 V AC

Input Voltage Range: 110 V AC - 240 V AC
Physical Characteristics
Form Factor:
  • Rack-mountable
  • Desktop

Miscellaneous
Package Contents:
  • 2 x KVM Extenders (1x Local, 1x Remote)
  • 2 x 2n1 USB VGA KVM Cables
  • 1 x Rubber Feet
  • 1 x Universal power adapter: comes ready for NA/EU/UK only when you buy in NA/EU/UK; comes ready for Australia and New Zealand only when you buy in Australia and New Zealand
  • 1 x User Manual

Environmentally Friendly: Yes
Environmental Certification:
  • RoHS
  • WEEE
  • REACH

TAA Compliant: Yes
Warranty
Limited Warranty: 3 Year
