Supermicro AS -1013S-MTR A+ Server 1013S-MTR Barebone System - 1U Rackmount - Socket SP3 - EPYC Support - 1TB DDR4
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This barebone system is built around an AMD chipset and supports a single EPYC processor, enabling 64-bit processing for demanding computational tasks. The memory architecture uses DDR4 SDRAM technology with a maximum capacity of 1TB, reducing processor idle time and improving multitasking efficiency.
Storage connectivity is handled by a Serial ATA/600 controller, which supports four SATA interfaces for fast data transfer. Expansion capabilities include one PCI Express x16 slot for adding dedicated graphics, networking, or storage cards.
Relevant factors for this section include Number of Processors Supported, Processor Socket, Processor Supported, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
The 1013S-MTR combines a compact 1U rackmount design with robust expansion options, making it ideal for environments where space efficiency and performance are both priorities. The system's support for EPYC processors and high memory capacity enables it to handle intensive workloads reliably.
High-Density Design
The 1U form factor maximizes rack space utilization while providing four 3.5" drive bays and eight memory slots for substantial storage and memory configurations.
- 1U rack height
- 4 x 3.5" bays
- 8 memory slots
Enterprise Connectivity
With nine USB ports (including five USB 3.0 ports) and Gigabit Ethernet, the system offers flexible peripheral and network connectivity for server environments.
- 9 USB ports total
- 5 x USB 3.0
- Gigabit Ethernet
Deployment / Use Cases
This barebone system is well-suited for building custom servers for small to medium business infrastructure, virtualization hosts, or dedicated application servers. Its balance of compute support, memory capacity, and storage expansion makes it adaptable to various IT roles.
Typical deployments include file servers, network-attached storage (NAS) solutions, or light-duty virtualization platforms where the EPYC processor and DDR4 memory can deliver smooth performance. The rack-mountable design ensures organized, clutter-free setups in server rooms or data centers.
Infrastructure Servers
Use the 1013S-MTR to build file servers, domain controllers, or backup servers that benefit from its storage bays and reliable Gigabit Ethernet connectivity.
Virtualization & Storage
The system's memory capacity and SATA/600 controller support virtual machine hosts or NAS deployments requiring fast data throughput and expandable storage.
Physical Profile
The server barebone measures 1.70 inches in height, 17.20 inches in width, and 19.85 inches in depth, fitting standard 19-inch rack enclosures. With an approximate weight of 20.06 pounds, it is designed for stable rack mounting in data center or server room environments. The 1U form factor optimizes vertical space while providing accessible front and rear connectivity for maintenance and cable management.
- Width
- 17.20" (436.88 mm)
- Depth
- 19.85" (504.19 mm)
- Height
- 1U
- Weight
- 20.06 lb (9100 g)
Highlights
- Supports AMD EPYC processors via Socket SP3 for enterprise compute performance
- 1U rackmount form factor maximizes rack space efficiency in data centers
- Up to 1TB of DDR4-2666 memory across eight slots for intensive workloads
- Four 3.5" drive bays provide flexible storage expansion options
- Serial ATA/600 controller ensures fast data transfer for storage devices
- Gigabit Ethernet delivers high-speed network connectivity for server uplinks
- Nine USB ports (five USB 3.0) support peripherals and external devices
- 400W power supply with 120V/230V input for reliable operation
Specifications
| Specifications | |
|---|---|
| Manufacturer | Supermicro Computer, Inc |
| Manufacturer Part Number | AS -1013S-MTR |
| Brand Name | Supermicro |
| Product Line | A+ Server |
| Product Model | 1013S-MTR |
| Product Name | A+ Server 1013S-MTR |
| Product Type | Server Barebone System |
| Processor | |
| Number of Processors Supported | 1 |
| Processor Socket | Socket SP3 |
| Processor Supported | EPYC |
| 64-bit Processing | Yes |
| Chipset | |
| Chipset Manufacturer | AMD |
| Memory | |
| Maximum Memory Supported | 1 TB |
| Memory Technology | DDR4 SDRAM |
| Memory Standard | DDR4-2666/PC4-21300 |
| Total Number of Memory Slots | 8 |
| Controllers | |
| Controller Type | Serial ATA/600 |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| I/O Expansions | |
| Number of Total Expansion Bays | 4 |
| Number of 3.5" Bays | 4 |
| Total Number of Expansion Slots | 1 |
| Number of PCI Express x16 Slots | 1 |
| Interfaces/Ports | |
| Total Number of USB Ports | 9 |
| Number of USB 3.0 Ports | 5 |
| Number of SATA Interfaces | 4 |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Maximum Power Supply Wattage | 400 W |
| Physical Characteristics | |
| Form Factor | Rack-mountable |
| Rack Height | 1U |
| Height | 1.70" (43.18 mm) |
| Width | 17.20" (436.88 mm) |
| Depth | 19.85" (504.19 mm) |
| Weight (Approximate) | 20.06 lb (9100 g) |
FAQ
What processors are compatible with this barebone system?
The Supermicro 1013S-MTR supports AMD EPYC processors using the Socket SP3 interface. It is designed for a single processor configuration, enabling 64-bit processing for demanding server applications.
How much memory can this system support?
This barebone system supports up to 1TB of DDR4 SDRAM memory across eight memory slots. The memory standard is DDR4-2666/PC4-21300, which helps reduce processor idle time and improve multitasking performance.
What storage expansion options are available?
The system includes four 3.5" drive bays and four SATA interfaces, controlled by a Serial ATA/600 controller for fast data transfer. This allows for substantial storage capacity using hard drives or SSDs in a compact 1U form factor.
What networking capabilities does this server have?
The 1013S-MTR features Gigabit Ethernet technology, providing network speeds up to ten times faster than standard Ethernet. This ensures high-performance uplinks and reliable connectivity for server deployments.
What expansion slots are included for add-on cards?
The barebone system has one PCI Express x16 expansion slot, allowing for the installation of dedicated graphics cards, network adapters, or storage controllers to extend the system's functionality.
Is this system suitable for rack mounting?
Yes, the 1013S-MTR is designed as a 1U rack-mountable server barebone. It measures 1.70" H x 17.20" W x 19.85" D and weighs approximately 20.06 pounds, making it ideal for standard 19-inch rack enclosures in data centers or server rooms.
