Supermicro SBI-6119P-T3N SuperBlade Server Barebone System - Blade Form Factor - Socket P LGA-3647 - Intel C622 Chipset - 3 TB Memory Support - 10GbE
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This barebone system features a comprehensive memory architecture with support for up to 3 TB of DDR4 SDRAM across 12 memory slots, operating at DDR4-2933/PC4-23466 speeds. The memory subsystem is designed to handle demanding applications with high throughput and low latency, essential for virtualization, database, and high-performance computing workloads.
Storage and I/O capabilities include a Serial ATA/600 controller with RAID support, enabling flexible storage configurations and data protection. Three total expansion bays provide room for NVMe or SATA drives, with included NVMe drive trays for quick installation. Network connectivity is handled by integrated 10 Gigabit Ethernet, ensuring high-speed data transfer for clustered and networked environments.
Relevant factors for this section include Number of Processors Supported, Processor Socket, Processor Supported, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The SBI-6119P-T3N excels in environments where density, scalability, and performance are critical. Its blade design allows multiple units to be consolidated within a shared chassis, reducing physical footprint and simplifying power and cooling infrastructure. This architecture supports vertical clustering for maximum scalability, making it ideal for expanding compute resources without proportionally increasing rack space.
High-Density Design
The blade form factor enables deployment of multiple compute nodes within a single chassis, optimizing rack space utilization and improving thermal management through shared cooling resources.
- Reduced cabling complexity
- Centralized management
- Efficient power distribution
Enterprise-Grade Connectivity
Integrated 10 Gigabit Ethernet provides the bandwidth necessary for modern data center networking, supporting high-throughput applications and reducing network bottlenecks in virtualized environments.
Deployment / Use Cases
This SuperBlade barebone system is particularly well-suited for virtualization hosts, where its memory capacity and network bandwidth support multiple virtual machines efficiently. The blade architecture allows for easy scaling of virtual infrastructure by adding additional blades to the chassis as demand grows.
In high-performance computing clusters, the system's processor support and memory bandwidth enable parallel processing tasks across multiple nodes. The compact blade design facilitates dense packing of compute resources, maximizing performance per rack unit while maintaining manageable thermal characteristics.
Virtualization Host
Deploy as a virtualization platform supporting multiple VMs with dedicated resources, leveraging the high memory capacity and fast network connectivity for efficient virtual infrastructure.
HPC Node
Utilize in computational clusters for scientific computing, financial modeling, or rendering workloads where parallel processing across multiple blades accelerates time-to-results.
Physical Profile
The system features a sleek metallic silver and black finish that complements modern data center aesthetics. With dimensions of 9.75 inches in height, 1.75 inches in width, and 23.50 inches in depth, the blade form factor is designed for vertical mounting within Supermicro's SuperBlade chassis. The approximate weight of 10.50 pounds ensures manageable handling during installation and maintenance operations.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 9.75" (247.65 mm), 1.75" (44.45 mm), 23.50" (596.90 mm), 10.50 lb (4762.72 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 1.75" (44.45 mm)
- Depth
- 23.50" (596.90 mm)
- Height
- 9.75" (247.65 mm)
- Weight
- 10.50 lb (4762.72 g)
What's in the Box
This barebone system ships with all necessary components for initial setup and integration into a SuperBlade chassis environment.
Highlights
- Single-socket blade server barebone system for modular data center deployment
- Supports Intel Xeon Scalable processors (Gold, Platinum, Silver, Bronze) on Socket P LGA-3647
- Intel C622 chipset provides platform stability and feature support
- Up to 3 TB DDR4 SDRAM across 12 memory slots at DDR4-2933 speeds
- Serial ATA/600 controller with RAID support for flexible storage configurations
- Integrated 10 Gigabit Ethernet for high-speed network connectivity
- Three expansion bays with included NVMe drive trays
- Blade form factor enables high-density deployment in SuperBlade chassis
- Metallic silver and black finish with dimensions of 9.75" H × 1.75" W × 23.50" D
- Includes comprehensive package with motherboard, chassis, I/O module, and installation components
Specifications
| Specifications | |
|---|---|
| Manufacturer | Supermicro Computer, Inc |
| Manufacturer Part Number | SBI-6119P-T3N |
| Brand Name | Supermicro |
| Product Line | SuperBlade |
| Product Model | SBI-6119P-T3N |
| Product Name | Single-Socket Blade SBI-6119P-T3N |
| Product Type | Server Barebone System |
| Processor | |
| Number of Processors Supported | 1 |
| Processor Socket | Socket P LGA-3647 |
| Processor Supported | Xeon Gold,Xeon Platinum,Xeon Silver,Xeon Bronze |
| 64-bit Processing | Yes |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | C622 |
| Memory | |
| Maximum Memory Supported | 3 TB |
| Memory Technology | DDR4 SDRAM |
| Memory Standard | DDR4-2933/PC4-23466 |
| Total Number of Memory Slots | 12 |
| Controllers | |
| Controller Type | Serial ATA/600 |
| RAID Supported | Yes |
| Network & Communication | |
| Ethernet Technology | 10 Gigabit Ethernet |
| I/O Expansions | |
| Number of Total Expansion Bays | 3 |
| Physical Characteristics | |
| Product Color | Metallic Silver,Black |
| Form Factor | Blade |
| Height | 9.75" (247.65 mm) |
| Width | 1.75" (44.45 mm) |
| Depth | 23.50" (596.90 mm) |
| Weight (Approximate) | 10.50 lb (4762.72 g) |
| Miscellaneous | |
| Package Contents | Single-Socket Blade SBI-6119P-T3N 1 x Super B11SPE-CPU-TF Motherboard 1 x 6U 10 SuperBlade UP Blade chassis 1 x AOM-BPNIO-SC, I/O module for uBlade,RoHS 2 x Black 2.5" NVMe Hard Drive Tray, orange button 1 x 6U 10 SuperBlade B11SPE Processor Tray Air Shroud, Wide 1 x 6U 10 SuperBlade B11SPE Processor Tray Air Shroud, Narrow |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 3 Year |
FAQ
What processors are compatible with this SuperBlade barebone system?
The SBI-6119P-T3N supports Intel Xeon Scalable processors including the Gold, Platinum, Silver, and Bronze series. These processors utilize the Socket P LGA-3647 interface and provide 64-bit processing capabilities for enterprise workloads. The system is designed to accommodate the thermal and power requirements of these server-grade CPUs within the blade form factor.
How much memory can this system support and what type is required?
This barebone system supports up to 3 terabytes of DDR4 SDRAM memory across 12 memory slots. The memory operates at DDR4-2933/PC4-23466 speeds, providing high bandwidth for memory-intensive applications. The substantial memory capacity makes this system suitable for virtualization, database servers, and other workloads that benefit from large memory pools.
What storage connectivity and expansion options are available?
The system includes a Serial ATA/600 controller with RAID support, enabling configuration of redundant storage arrays. There are three total expansion bays that can accommodate 2.5" drives, with included NVMe drive trays for fast storage installation. This flexibility allows for various storage configurations based on performance, capacity, and redundancy requirements.
What networking capabilities does this blade server provide?
Integrated 10 Gigabit Ethernet provides high-speed network connectivity essential for modern data center environments. This bandwidth supports rapid data transfer between servers, storage systems, and network infrastructure, reducing bottlenecks in virtualized and clustered deployments. The networking is optimized for enterprise applications requiring low latency and high throughput.
How does the blade form factor benefit deployment in data centers?
The blade design allows multiple SBI-6119P-T3N units to be mounted vertically within a shared SuperBlade chassis, creating a high-density computing cluster. This approach reduces physical footprint, simplifies cabling through backplane connections, centralizes power and cooling management, and enables scalable expansion by adding more blades to the chassis as compute needs grow.
What is included in the package and what additional components are needed?
The package includes the single-socket blade unit, Super B11SPE-CPU-TF motherboard, 6U 10 SuperBlade UP chassis, AOM-BPNIO-SC I/O module, two NVMe drive trays, and processor tray air shrouds. To complete the system, you will need to add a compatible Intel Xeon Scalable processor, DDR4 memory modules, storage drives, and appropriate power supplies for the chassis environment.
