Brainboxes SW-514 Compact Industrial 4-Port Gigabit Ethernet Switch - Layer 2 - DIN Rail Mountable - 10/100/1000Base-T
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This industrial Ethernet switch operates at Layer 2 of the OSI model, providing basic switching functionality without complex management features. The four Gigabit Ethernet ports support twisted pair cabling and deliver full wire-speed performance for industrial automation and control applications.
The SW-514 is designed for low power consumption at just 3.60 watts, making it suitable for energy-conscious deployments. Its wide voltage input range allows operation from various DC power sources commonly found in industrial settings.
Relevant factors for this section include Total Number of Network Ports, Uplink Port, Modular, Media Type Supported. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
The Brainboxes SW-514 stands out in industrial networking applications through its combination of compact design, industrial-grade construction, and reliable performance. Its DIN rail mounting capability simplifies installation in control panels and industrial cabinets, while the wide operating temperature range ensures functionality in extreme environmental conditions.
Industrial Durability
Built to withstand harsh industrial environments with extended temperature tolerance and robust construction.
- Operating temperature: -40°C to +80°C
- Industrial-grade components
- Vibration and shock resistant
Power Flexibility
Supports a wide input voltage range and features redundant power inputs for increased reliability in industrial power systems.
- Input voltage: 5-30V DC
- Redundant power inputs
- Low power consumption
Deployment / Use Cases
The SW-514 industrial Ethernet switch is specifically designed for deployment in industrial automation, manufacturing, and process control environments. Its compact form factor and DIN rail mounting make it ideal for space-constrained installations where reliable network connectivity is essential for operational continuity.
Common applications include connecting PLCs, HMIs, sensors, and other industrial devices in manufacturing facilities, water treatment plants, transportation systems, and energy production sites. The switch's industrial temperature range and rugged design ensure reliable operation in environments with temperature extremes, vibration, and electrical noise.
Relevant factors for this section include Total Number of Network Ports, Uplink Port, Modular, Media Type Supported. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Industrial Automation
Connect PLCs, HMIs, and industrial controllers in manufacturing and process control systems.
Building Automation
Network HVAC controls, lighting systems, and security devices in commercial and industrial buildings.
Physical Profile
The SW-514 features a compact industrial design measuring just 3.90" (99 mm) in height, 0.91" (23 mm) in width, and 3.70" (94 mm) in depth, with a weight of approximately 3.95 oz (112 g). Its DIN rail mounting capability allows for secure installation in standard industrial control cabinets, while the small footprint conserves valuable panel space. The switch's industrial-grade enclosure provides protection against dust, moisture, and mechanical stress commonly encountered in industrial environments.
- Width
- 0.91" (23 mm)
- Depth
- 3.70" (94 mm)
- Height
- 3.90" (99 mm)
- Weight
- 3.95 oz (112 g)
What's in the Box
The package includes everything needed for immediate deployment of the industrial Ethernet switch.
Highlights
- 4 Gigabit Ethernet ports with auto-negotiation
- Layer 2 switching for basic network segmentation
- DIN rail mountable for industrial cabinet installation
- Wide operating temperature range: -40°C to +80°C
- Redundant power inputs for increased reliability
- Low power consumption at 3.60 watts
- Jumbo Frame support up to 9K frames
- Industrial-grade construction for harsh environments
- TAA compliant for government deployments
- Lifetime limited warranty
Specifications
| Specifications | |
|---|---|
| Manufacturer | Brainboxes Limited |
| Manufacturer Part Number | SW-514 |
| Brand Name | Brainboxes |
| Product Model | SW-514 |
| Product Name | Compact Industrial 4 Port Gigabit Ethernet Switch |
| Product Type | Ethernet Switch |
| Interfaces/Ports | |
| Total Number of Network Ports | 4 |
| Uplink Port | No |
| Modular | No |
| Stack Port | No |
| Port/Expansion Slot Details | 4 x Gigabit Ethernet Network |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 10/100/1000Base-T |
| Network & Communication | |
| Layer Supported | 2 |
| Management & Protocols | |
| Manageable | No |
| Power Description | |
| Input Voltage | 30 V DC |
| Power Source | Power Supply |
| Power Consumption | 3.60 W |
| Physical Characteristics | |
| Form Factor | DIN Rail Mountable |
| Height | 3.90" (99 mm) |
| Width | 0.91" (23 mm) |
| Depth | 3.70" (94 mm) |
| Weight (Approximate) | 3.95 oz (112 g) |
| Miscellaneous | |
| Package Contents | Compact Industrial 4 Port Gigabit Ethernet Switch Quick Start Guide |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| TAA Compliant | Yes |
| Warranty | |
| Limited Warranty | Lifetime |
User Manual
FAQ
How many network ports does the Brainboxes SW-514 switch have?
The Brainboxes SW-514 industrial Ethernet switch provides four Gigabit Ethernet ports. These ports support 10/100/1000Base-T connections with auto-negotiation, allowing connectivity to a variety of industrial devices and equipment in automation and control applications.
What type of switching does this industrial Ethernet switch support?
This switch operates at Layer 2 of the OSI model, providing basic switching functionality for industrial networks. It supports store-and-forward switching with auto-MDI/MDIX on all ports, making it suitable for connecting industrial devices without requiring complex network management or configuration.
Can this switch be mounted in industrial control cabinets?
Yes, the SW-514 is specifically designed for DIN rail mounting, making it ideal for installation in industrial control cabinets and panels. Its compact dimensions of 3.90" x 0.91" x 3.70" (99 mm x 23 mm x 94 mm) allow it to fit in space-constrained environments commonly found in manufacturing and process control facilities.
What power requirements does this industrial switch have?
The switch operates on 30V DC input with a power consumption of 3.60 watts. It features a wide voltage input range and includes redundant power inputs, providing flexibility in industrial power systems and increasing reliability in applications where power stability is critical for continuous operation.
What environmental conditions can this switch withstand?
The SW-514 is designed for industrial environments with an operating temperature range of -40°C to +80°C (-40°F to 176°F). This extended temperature tolerance, combined with its rugged construction, ensures reliable performance in harsh conditions including manufacturing floors, outdoor installations, and other challenging industrial settings.
What connectivity or interface options are available?
Connectivity options include Gigabit Ethernet, helping the product integrate into common office or home setups.
