QNAP TS-264-8G-US Turbo NAS 2-Bay SAN/NAS Storage System - Intel Celeron N5095 Quad-core - 8GB DDR4 - 2.5GbE - RAID 0/1/JBOD - Tower
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This storage system features a comprehensive technical specification designed for reliable operation. The Intel Celeron N5095 processor provides efficient compute performance for storage management tasks, while the 8GB DDR4 memory ensures smooth multitasking across applications and user connections.
Storage management includes support for RAID 0, 1, and JBOD configurations through the Serial ATA/600 controller, giving administrators flexibility in balancing performance, redundancy, and capacity. The system's 2.5 Gigabit Ethernet ports deliver network throughput that exceeds traditional Gigabit connections, reducing transfer bottlenecks for large files and multimedia content.
Relevant factors for this section include Number of Hard Drives Supported, Number of Hard Drives Installed, Number of Solid State Drive Supported, Number of Processors Installed. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The TS-264-8G-US combines enterprise-grade features with approachable management through QNAP's QTS operating system. This balance makes it suitable for both IT professionals and small business owners who need reliable network storage without complex infrastructure requirements.
High-Speed Networking
Dual 2.5 Gigabit Ethernet ports provide network performance that surpasses standard Gigabit connections, enabling faster file transfers and smoother multimedia streaming across your network.
Storage Flexibility
Two drive bays accept both 2.5-inch and 3.5-inch drives, allowing you to choose between high-capacity hard drives or faster solid-state drives based on your performance and capacity requirements.
Expansion Capability
A PCI Express 3.0 x2 expansion slot enables future upgrades with additional network cards, storage controllers, or other compatible expansion cards to extend system functionality.
Deployment / Use Cases
This NAS system adapts to various business environments, from professional offices requiring centralized storage to creative studios needing fast access to multimedia assets. The combination of processing power, memory, and network connectivity supports concurrent access from multiple users while maintaining system responsiveness.
Small Business File Server
Centralize document storage, user home directories, and shared resources with RAID protection for business continuity. The compact tower design fits easily in office environments without dedicated server rooms.
Backup and Recovery Target
Serve as a network backup destination for multiple workstations and servers. Support for multiple protocols including CIFS/SMB, NFS, and iSCSI allows integration with various backup software solutions.
Media Streaming and Sharing
Store and stream multimedia content to compatible devices on your network. HDMI output enables direct connection to displays for media playback without requiring additional streaming devices.
Localization and Operating System
The QNAP TS-264-8G-US Turbo NAS runs the QTS 5.0.1 operating system, which provides a comprehensive management interface for storage configuration, user management, application installation, and system monitoring. QTS is designed for intuitive operation while offering enterprise-grade features, making it accessible for both IT professionals and small business owners who need reliable network storage without complex infrastructure requirements.
The operating system supports numerous network protocols including CIFS/SMB, NFS, FTP, and iSCSI, ensuring compatibility with various client operating systems and backup solutions. This broad protocol support allows seamless integration into diverse IT environments, from Windows-based office networks to mixed-platform creative studios or Linux server backup targets.
QTS 5.0.1 includes built-in localization for multiple languages and regions, with the interface adapting to your preferred language settings during initial setup. The system's management tools are designed for global deployment, with support for international time zones, currency formats, and regional network configurations that help streamline administration across distributed business locations.
QTS 5.0.1 Operating System
Provides a unified management interface for storage configuration, user permissions, application deployment, and system monitoring with support for multiple languages and regional settings.
Protocol Compatibility
Supports CIFS/SMB for Windows environments, NFS for Unix/Linux systems, FTP for file transfers, and iSCSI for block-level storage access, ensuring integration with diverse IT infrastructures.
Physical Profile
The tower chassis measures 6.61 inches in height, 4.13 inches in width, and 8.90 inches in depth, creating a compact footprint suitable for desktop placement or small server enclosures. Weighing just 3.42 pounds, the system remains portable enough for relocation between locations while maintaining a professional appearance with clean lines and minimal visual intrusion.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 6.61" (167.89 mm), 4.13" (104.90 mm), 8.90" (226.06 mm), 3.42 lb (1551.29 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 4.13" (104.90 mm)
- Depth
- 8.90" (226.06 mm)
- Height
- 6.61" (167.89 mm)
- Weight
- 3.42 lb (1551.29 g)
What's in the Box
The package includes all essential components for immediate deployment of your storage system.
Highlights
- 2-bay tower NAS with support for 2.5" and 3.5" drives
- Intel Celeron N5095 quad-core processor for efficient performance
- 8GB DDR4 memory for smooth multitasking
- Dual 2.5 Gigabit Ethernet ports for high-speed networking
- RAID 0, 1, and JBOD support for data protection
- PCI Express 3.0 x2 expansion slot for future upgrades
- QTS 5.0.1 operating system with comprehensive management tools
- HDMI output for direct display connection
- Compact dimensions: 6.61" H × 4.13" W × 8.90" D
- 3-year manufacturer warranty for peace of mind
Specifications
| Specifications | |
|---|---|
| Manufacturer | QNAP Systems |
| Manufacturer Part Number | TS-264-8G-US |
| Brand Name | QNAP |
| Product Line | Turbo NAS |
| Product Series | TS-x62 |
| Product Model | TS-264-8G |
| Product Name | Turbo NAS TS-264-8G SAN/NAS Storage System |
| Product Type | SAN/NAS Storage System |
| Storage | |
| Number of Hard Drives Supported | 2 |
| Number of Hard Drives Installed | 0 |
| Number of Solid State Drive Supported | 2 |
| Number of Solid State Drive Installed | 0 |
| Flash Memory Capacity | 4 GB |
| Processor & Chipset | |
| Number of Processors Installed | 1 |
| Processor Manufacturer | Intel |
| Processor Type | Celeron |
| Processor Model | N5095 |
| Processor Core | Quad-core (4 Core) |
| Memory | |
| Standard Memory | 8 GB |
| Memory Technology | DDR4 SDRAM |
| Network & Communication | |
| Ethernet Technology | 2.5 Gigabit Ethernet |
| I/O Expansions | |
| Number of Total Expansion Bays | 2 |
| Number of 2.5"/3.5" Bays | 2 |
| Total Number of Expansion Slots | 1.0 |
| Expansion Slot Type | PCI Express 3.0 x2 |
| Controllers | |
| Controller Type | Serial ATA/600 |
| RAID Supported | Yes |
| RAID Levels | 0, 1, JBOD |
| Interfaces/Ports | |
| HDMI | Yes |
| Total Number of USB Ports | 4 |
| Number of USB 2.0 Ports | 2 |
| Number of USB 3.2 Gen 2 Ports | 2 |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 2 |
| Software | |
| Operating System | QTS 5.0.1 |
| Management & Protocols | |
| Protocols | IPv4,IPv6,DHCP,CIFS/SMB,AFP,NFSv3,FTP,FTPS,SFTP,TFTP,HTTP,HTTPS,Telnet,SSH,iSCSI,SNMP,SSL/TLS,FXP,WEBDAV,LDAP,DDNS,DNS,SNMPv2,SNMPv3,PPTP,L2TP,NFSv4 |
| Power Description | |
| Maximum Power Supply Wattage | 65 W |
| Physical Characteristics | |
| Height | 6.61" (167.89 mm) |
| Width | 4.13" (104.90 mm) |
| Depth | 8.90" (226.06 mm) |
| Form Factor | Tower |
| Weight (Approximate) | 3.42 lb (1551.29 g) |
| Miscellaneous | |
| Package Contents | Turbo NAS TS-264-8G SAN/NAS Storage System 1 x Ethernet Cable 1 x Power Cord 36 x Flat head screw (for 3.5" HDD) 36 x Flat head screw (for 2.5" HDD) AC Adapter |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | The TS-264 is backed by a 3-year warranty at no additional cost. |
User Manual
FAQ
What processor does this product use?
This product uses the 1 processor for everyday performance and multitasking.
How much memory is installed?
It includes 4 GB of memory to support responsive multitasking and daily workloads.
What storage is included?
The system includes 0 of storage for applications, files, and everyday business data.
What graphics or display support is listed?
Display-related specifications help position QNAP Turbo NAS TS-264-8G SAN/NAS Storage System - 1 x Intel Celeron N5095 Quad-core (4 Core) - 2 x HDD Supported - 0 x HDD Installed - (TS-264-8G-US) for the kind of viewing experience, readability, and workspace fit buyers may expect in business it/storage arrays & nas/nas storage system deployments.
What connectivity options are available?
Connectivity options include 2.5 Gigabit Ethernet, helping the product integrate into common office or home setups.
What operating system or platform is included?
The included operating environment is QTS 5.0.1, which helps position the product for software compatibility, deployment planning, and day-to-day business use.
