QNAP TS-462-4G-US Turbo NAS 4-Bay SAN/NAS Storage System - Intel Celeron N4505 Dual-core 2 GHz - 4 GB DDR4 - 2.5GbE - Tower
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the core of the TS-462-4G is Intel's Celeron N4505 processor, a dual-core CPU operating at 2 GHz that provides sufficient processing power for file serving, backup tasks, and light virtualization workloads. The 4 GB of DDR4 SDRAM ensures smooth operation of QNAP's QTS 5.0.1 operating system and installed applications, while the 4 GB flash memory module stores the firmware for reliable boot operations.
Storage management is handled through a Serial ATA/600 controller that supports both traditional hard drives and modern solid-state drives. The system offers comprehensive RAID functionality with support for RAID levels 0, 1, 5, 6, and 10, plus JBOD configurations for maximum flexibility. An integrated cooling fan maintains optimal operating temperatures during sustained workloads.
Relevant factors for this section include Number of Hard Drives Supported, Number of Hard Drives Installed, Number of Solid State Drive Supported, Number of Processors Installed. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The TS-462-4G combines enterprise storage features with desktop convenience, offering professional-grade data protection in a compact tower form factor that fits easily into office environments. Its balanced specification provides reliable performance for collaborative file sharing, centralized backups, and media streaming without requiring specialized infrastructure.
Flexible Storage Architecture
Support for both HDDs and SSDs across four bays enables mixed storage configurations that balance capacity, performance, and cost. Administrators can implement RAID protection or configure individual volumes based on specific application requirements.
- Mixed HDD/SSD support
- Six RAID level options
- Hot-swappable bay design
Enhanced Network Performance
2.5 Gigabit Ethernet connectivity provides up to 2.5× the throughput of standard Gigabit Ethernet, reducing transfer times for large files and improving responsiveness for multiple simultaneous users.
- Backward compatible with 1GbE
- Reduced network bottlenecks
- Better multi-user performance
Expansion Ready Design
The PCI Express 3.0 x2 expansion slot allows for adding 10GbE network cards, storage controllers, or other compatible expansion cards to extend functionality as needs evolve.
- Future-proof connectivity
- Storage expansion options
- Customizable configuration
Deployment / Use Cases
The TS-462-4G excels as a primary storage repository for small to medium-sized businesses that need centralized, accessible storage without the complexity of server administration. Its tower form factor and comprehensive feature set make it suitable for office environments where rack space is unavailable or impractical.
Common deployment scenarios include serving as a file server for departmental document sharing, acting as a backup target for workstation and server backups, functioning as a media server for streaming content to network devices, and providing iSCSI storage for virtualization environments. The system's protocol support ensures compatibility with Windows, macOS, and Linux clients through SMB/CIFS, AFP, and NFS protocols.
Office File Server
Centralize documents, spreadsheets, and presentations with controlled access permissions and version history. The 2.5GbE networking ensures quick file access for multiple simultaneous users.
Backup Repository
Serve as a destination for automated backups from workstations and servers using built-in support for rsync, FTP, and cloud synchronization protocols. RAID protection safeguards backup integrity.
Localization and Operating System
The QNAP TS-462-4G runs the QTS 5.0.1 operating system, a Linux-based NAS platform designed for intuitive management and extensive application support through the QNAP App Center. This operating system provides a web-based interface that simplifies setup, file sharing, backup configuration, and media streaming tasks, making it accessible for administrators with varying technical expertise.
QTS 5.0.1 includes comprehensive protocol support for seamless integration into diverse network environments. It handles file sharing across Windows, macOS, and Linux clients using SMB/CIFS, AFP, and NFS protocols, while also supporting iSCSI for block-level storage provisioning to virtualization hosts. The system's management capabilities extend to backup synchronization, surveillance station applications, and containerized software deployment via Container Station.
From a localization standpoint, the TS-462-4G is configured for North American markets with English-language interfaces and documentation. The operating system supports multiple language packs for administrative interfaces, allowing customization to match regional preferences. This flexibility ensures the NAS can be deployed in multilingual office environments or international branch locations without compatibility hurdles.
Operating System Features
QTS 5.0.1 delivers a robust feature set including real-time resource monitoring, snapshot replication for data protection, and hybrid backup sync for local and cloud backups. The system's app ecosystem enables additional functionality such as virtualization station, mail server, and collaboration tools.
- Web-based management interface
- Multi-protocol file sharing
- App Center for extended functionality
Physical Profile
The tower chassis measures 6.69 inches wide by 6.61 inches high by 8.90 inches deep, occupying minimal desk or shelf space while providing four drive bays for storage expansion. Weighing approximately 4.98 pounds without drives installed, the unit remains portable enough for relocation between offices or departments. The compact dimensions and tower orientation make it suitable for placement alongside desktop workstations or in network closets where vertical space is available.
- Width
- 6.69" (170 mm)
- Depth
- 8.90" (226 mm)
- Height
- 6.61" (168 mm)
- Weight
- 4.98 lb (2260 g)
What's in the Box
The TS-462-4G ships with all necessary components for initial setup and drive installation.
Highlights
- Four-bay tower NAS supporting both 2.5" and 3.5" HDDs/SSDs
- Intel Celeron N4505 dual-core processor at 2 GHz
- 4 GB DDR4 memory with 4 GB flash storage
- 2.5 Gigabit Ethernet port for enhanced network performance
- Comprehensive RAID support including 0,1,5,6,10 and JBOD
- PCI Express 3.0 x2 expansion slot for future upgrades
- Four USB ports (2x USB 2.0, 2x USB 3.2 Gen 2)
- HDMI output for direct display connectivity
- QTS 5.0.1 operating system with extensive protocol support
- Two-year manufacturer warranty included
Specifications
| Specifications | |
|---|---|
| Manufacturer | QNAP Systems |
| Manufacturer Part Number | TS-462-4G-US |
| Brand Name | QNAP |
| Product Line | Turbo NAS |
| Product Series | TS-x62 |
| Product Model | TS-462-4G |
| Product Name | Turbo NAS TS-462-4G SAN/NAS Storage System |
| Product Type | SAN/NAS Storage System |
| Storage | |
| Number of Hard Drives Supported | 4 |
| Number of Hard Drives Installed | 0 |
| Number of Solid State Drive Supported | 4 |
| Number of Solid State Drive Installed | 0 |
| Flash Memory Capacity | 4 GB |
| Processor & Chipset | |
| Number of Processors Installed | 1 |
| Processor Manufacturer | Intel |
| Processor Type | Celeron |
| Processor Model | N4505 |
| Processor Core | Dual-core (2 Core) |
| Processor Speed | 2 GHz |
| Memory | |
| Standard Memory | 4 GB |
| Memory Technology | DDR4 SDRAM |
| Network & Communication | |
| Ethernet Technology | 2.5 Gigabit Ethernet |
| I/O Expansions | |
| Number of Total Expansion Bays | 4 |
| Number of 2.5"/3.5" Bays | 4 |
| Total Number of Expansion Slots | 1 |
| Expansion Slot Type | PCI Express 3.0 x2 |
| Controllers | |
| Controller Type | Serial ATA/600 |
| Non-RAID Mode | JBOD |
| RAID Supported | Yes |
| RAID Levels | 0, 1, 5, 6, 10, JBOD |
| Interfaces/Ports | |
| HDMI | Yes |
| Total Number of USB Ports | 4 |
| Number of USB 2.0 Ports | 2 |
| Number of USB 3.2 Gen 2 Ports | 2 |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 1 |
| Software | |
| Operating System | QTS 5.0.1 |
| Management & Protocols | |
| Protocols | IPv4,IPv6,DHCP,CIFS/SMB,AFP,NFSv3,FTP,FTPS,SFTP,TFTP,HTTP,HTTPS,Telnet,SSH,iSCSI,SNMP,SSL/TLS,FXP,WEBDAV,LDAP,DDNS,DNS,SNMPv2,SNMPv3,PPTP,L2TP,NFSv4 |
| Power Description | |
| Maximum Power Supply Wattage | 90 W |
| Physical Characteristics | |
| Cooling Fan | Yes |
| Height | 6.61" (168 mm) |
| Width | 6.69" (170 mm) |
| Depth | 8.90" (226 mm) |
| Form Factor | Tower |
| Weight (Approximate) | 4.98 lb (2260 g) |
| Miscellaneous | |
| Package Contents | Turbo NAS TS-462-4G SAN/NAS Storage System 1 x Ethernet Cable 1 x Power Cord AC Adapter 16 x Flat Head Screw (for 3.5" HDD) 12 x Flat Head Screw (for 2.5" HDD) Quick Installation Guide (QIG) |
| Warranty | |
| Limited Warranty | 2 Year |
| Additional Warranty Information | The TS-462 is backed by a 2-year warranty at no additional cost |
User Manual
FAQ
What processor does this product use?
This product uses the 1 processor for everyday performance and multitasking.
How much memory is installed?
It includes 4 GB of memory to support responsive multitasking and daily workloads.
What storage is included?
The system includes 0 of storage for applications, files, and everyday business data.
What graphics or display support is listed?
Display-related specifications help position QNAP Turbo NAS TS-462-4G SAN/NAS Storage System - 1 x Intel Celeron N4505 Dual-core (2 Core) 2 GHz - 4 x HDD Supported - 0 x HDD - 4 x (TS-462-4G-US) for the kind of viewing experience, readability, and workspace fit buyers may expect in business it/storage arrays & nas/nas storage system deployments.
What connectivity options are available?
Connectivity options include 2.5 Gigabit Ethernet, helping the product integrate into common office or home setups.
What operating system or platform is included?
The included operating environment is QTS 5.0.1, which helps position the product for software compatibility, deployment planning, and day-to-day business use.
