StarTech. com UNIRAILS1UB 1U Server Rack Rails - 24-36" Adjustable Depth - 200 lb Capacity - 4-Post Universal Mounting Kit
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
These rack rails are engineered with cold-rolled steel (CRS) for exceptional durability and strength, supporting devices up to 200 pounds. The universal design ensures compatibility with 19-inch equipment including servers, UPS units, LAN switches, and patch panels, adhering to the EIA/ECA-310 standard for 4-post rack mounting.
The rails feature a precise 1U rack height profile with dimensions of 1.60 inches in height, 2.30 inches in width, and a default length of 24.70 inches, adjustable to fit depths between 24 and 36 inches. The matte black finish provides a professional appearance while the included M6-12 screws, cage nuts, and plastic cup washers facilitate secure installation without requiring additional hardware.
Key Product Advantages
Universal Compatibility
Designed to mount any 19-inch device in 4-post racks, these rails serve as ideal replacements for HPE ProLiant, Dell PowerEdge, Lenovo ThinkSystem, and APC UPS systems, eliminating the need for brand-specific mounting kits.
High Weight Capacity
With a 200-pound load rating, the rails securely support heavy servers, UPS units, and network equipment, ensuring stable operation in demanding environments.
Complete Installation Kit
The package includes all necessary hardware—rails, screws, cage nuts, washers, and a quick start guide—for a hassle-free installation process that reduces setup time and complexity.
Deployment / Use Cases
These universal rack rails are deployed in data centers, server rooms, and network closets where standardized 19-inch equipment requires secure and organized mounting. They are particularly valuable for IT teams managing heterogeneous hardware environments, as they provide a single mounting solution that works across multiple device brands and types.
Common use cases include mounting replacement rails for servers where original rails are missing, installing new UPS systems in existing racks, organizing patch panels and network switches in structured cabling setups, and expanding rack capacity with additional equipment. The adjustable depth allows flexibility when integrating devices of varying sizes, while the robust construction ensures long-term reliability in continuous operation environments.
Physical Profile
The rails feature a compact 1U rack height profile with a matte black finish that blends seamlessly with professional rack equipment. With dimensions of 1.60 inches in height, 2.30 inches in width, and a default length of 24.70 inches (adjustable to 36 inches), they provide a low-profile mounting solution that maximizes rack space efficiency. The cold-rolled steel construction offers both strength and corrosion resistance, while the approximate weight of 7.72 pounds ensures manageable installation without compromising durability.
- Width
- 2.30" (58.42 mm)
- Height
- 1.60" (40.64 mm)
- Weight
- 7.72 lb (3500 g)
- Length
- 24.70" (627.38 mm)
What's in the Box
The package includes all components needed for immediate installation:
Highlights
- Universal 1U rack rails for 19-inch equipment in 4-post EIA/ECA-310 compliant racks
- Adjustable depth from 24 to 36 inches to accommodate various device sizes
- 200-pound weight capacity for secure mounting of servers, UPS, and network gear
- Cold-rolled steel construction with matte black finish for durability and aesthetics
- Complete kit includes rails, screws, cage nuts, washers, and quick start guide
- Ideal replacement for lost rails on HPE, Dell, Lenovo, and APC systems
- Lifetime limited warranty for long-term peace of mind
- Environmentally compliant with EU RoHS and REACH standards
Specifications
| Specifications | |
|---|---|
| Manufacturer | StarTech.com |
| Manufacturer Part Number | UNIRAILS1UB |
| Brand Name | StarTech.com |
| Product Name | 1U Server Rack Rails With Adjustable Mounting Depth |
| Packaged Quantity | 1 Each |
| Product Type | Rack Rail |
| Technical Information | |
| Application/Usage | LAN Switch,Patch Panel,Server,UPS |
| Physical Characteristics | |
| Form Factor | Rack-mountable |
| Color Family | Black |
| Product Color | Black |
| Product Material | Cold-rolled Steel (CRS) |
| Height | 1.60" (40.64 mm) |
| Width | 2.30" (58.42 mm) |
| Length | 24.70" (627.38 mm) |
| Rack Height | 1U |
| Weight (Approximate) | 7.72 lb (3500 g) |
| Miscellaneous | |
| Package Contents | 1U Server Rack Rails with Adjustable Mounting Depth 8 x M6-12 Screws 8 x M6 Cage Nuts 8 x M6 Plastic Cup Washers 1 x Quick Start Guide |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Certification | EU RoHS |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) 2,Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Warranty | |
| Limited Warranty | Lifetime |
User Manual
FAQ
What types of equipment can I mount with these rack rails?
These universal 1U rack rails are designed to mount any standard 19-inch equipment in 4-post EIA/ECA-310 compliant racks. They are compatible with servers, UPS systems, LAN switches, patch panels, and other rack-mountable devices. The rails serve as ideal replacements for lost or damaged rails on popular brands including HPE ProLiant, Dell PowerEdge, Lenovo ThinkSystem, and APC UPS units.
How adjustable are these rack rails for different equipment depths?
The rails feature an adjustable depth range from 24 to 36 inches, allowing them to accommodate various device sizes within standard rack configurations. This flexibility makes them suitable for mounting equipment with different chassis depths, from compact network switches to deeper server and UPS units, without requiring custom mounting solutions.
What is the weight capacity of these server rack rails?
These rails support a maximum weight capacity of 200 pounds (90 kilograms), making them capable of securely mounting heavy servers, UPS systems, and other substantial rack equipment. The cold-rolled steel construction provides the structural strength needed for reliable performance in data center and server room environments where equipment stability is critical.
What mounting hardware is included with the rack rails?
The package includes all necessary hardware for installation: the 1U server rack rails with adjustable mounting depth, 8 M6-12 screws, 8 M6 cage nuts, 8 M6 plastic cup washers, and a quick start guide. This complete kit ensures you have everything required for a straightforward installation without needing to source additional components.
Are these rack rails compatible with all standard server racks?
Yes, these rails are designed for universal compatibility with 4-post EIA/ECA-310 compliant racks, which represent the industry standard for server rack mounting. They work with any rack that adheres to this specification, providing a reliable mounting solution for 19-inch equipment across different rack brands and models commonly used in data centers and IT environments.
What warranty coverage do these rack rails include?
StarTech.com provides a lifetime limited warranty for these rack rails, offering long-term protection against manufacturing defects and material failures. This warranty reflects the product's durable construction and reliability, giving IT professionals confidence in their investment for critical rack mounting applications.
