Aten VC882 True 4K HDMI Repeater with Audio Embedder/De-Embedder - 4096 x 2160 - 16. 4 ft (5m) Max Distance - 1 x 1 HDMI I/O
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
Engineered for reliable performance, the VC882 operates with a 5 V DC input and extends HDMI signals up to 16.4 feet (5 meters). It features one HDMI input and one HDMI output, making it ideal for point-to-point signal boosting in AV setups.
The device maintains signal quality over its maximum operating distance, preventing degradation that can occur with long HDMI cables. Its compact form factor, measuring 0.98" x 3.24" x 4.81", allows for discreet installation in various environments.
This section brings together practical product details such as Maximum Video Resolution, HDMI In, HDMI Out, USB, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
The VC882 eliminates signal loss over extended HDMI runs, ensuring consistent video and audio quality in professional and home theater applications. Its audio embedding and de-embedding functions provide greater control over audio streams without requiring separate audio equipment.
Extended Reach
Boosts HDMI signals up to 16.4 feet, overcoming distance limitations of standard cables while maintaining 4K resolution.
- Prevents signal degradation
- Supports long cable runs
Audio Flexibility
Embed or de-embed audio from HDMI signals, enabling integration with external audio systems or extraction for separate processing.
- Simplifies audio routing
- Reduces equipment needs
Additional Connectivity
Includes a USB port for rapid data transfers between devices, adding functionality beyond basic signal repetition.
- Enhances device interoperability
- Supports quick file moves
Deployment / Use Cases
This repeater is ideal for scenarios where HDMI source and display are separated beyond typical cable limits, such as in conference rooms, digital signage installations, or home theater setups with distant components.
Use it to connect media players to projectors in large venues, extend signals from computers to monitors in office environments, or integrate AV systems in educational facilities where cable runs exceed standard lengths.
This section brings together practical product details such as Maximum Video Resolution, HDMI In, HDMI Out, USB, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Conference & Meeting Rooms
Extend laptop or media player signals to wall-mounted displays or projectors without quality loss, ensuring clear presentations.
Digital Signage & Retail
Maintain high-resolution video over long distances for digital menu boards, advertising displays, or informational screens.
Physical Profile
The VC882 features a slim, lightweight design at 240 grams, with dimensions of 0.98" x 3.24" x 4.81". Its compact size allows for easy placement behind displays, within AV racks, or in tight spaces without obstructing other equipment.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 0.98" (25 mm), 3.24" (82.20 mm), 240 g. This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 3.24" (82.20 mm)
- Height
- 0.98" (25 mm)
- Weight
- 240 g
- Length
- 4.81" (122.20 mm)
What's in the Box
The package includes all necessary components for immediate setup and operation.
Highlights
- Extends HDMI signals up to 16.4 feet (5 meters) with no quality loss
- Supports True 4K resolution at 4096 x 2160 for ultra-high-definition video
- Features audio embedding and de-embedding for flexible audio management
- Includes a USB port for fast data transfers between connected devices
- Compact and lightweight design for easy installation in various environments
- Simple point-to-point connectivity with one HDMI input and one output
- Operates on 5 V DC power for low-energy consumption
- Comes with power adapter and user instructions for quick setup
Specifications
| Specifications | |
|---|---|
| Manufacturer | ATEN Technology, Inc |
| Manufacturer Part Number | VC882 |
| Brand Name | ATEN |
| Product Model | VC882 |
| Product Name | True 4K HDMI Repeater with Audio Embedder and De-Embedder |
| Packaged Quantity | 1 |
| Product Type | Signal Repeater |
| Video | |
| Maximum Video Resolution | 4096 x 2160 |
| Interfaces/Ports | |
| HDMI In | Yes |
| HDMI Out | Yes |
| USB | Yes |
| Number of HDMI Inputs | 1 |
| Number of HDMI Outputs | 1 |
| Media & Performance | |
| Maximum Operating Distance | 16.40 ft (5000 mm) |
| Power Description | |
| Input Voltage | 5 V DC |
| Physical Characteristics | |
| Height | 0.98" (25 mm) |
| Width | 3.24" (82.20 mm) |
| Length | 4.81" (122.20 mm) |
| Weight (Approximate) | 240 g |
| Miscellaneous | |
| Package Contents | True 4K HDMI Repeater with Audio Embedder and De-Embedder 1 x Power Adapter 1 x User Instructions |
User Manual
FAQ
What is the maximum resolution supported by the ATEN VC882 HDMI Repeater?
The ATEN VC882 supports a maximum video resolution of 4096 x 2160, which is True 4K. This ensures high-quality video delivery without compression or downscaling over extended distances.
How far can this repeater extend an HDMI signal?
It extends HDMI signals up to a maximum operating distance of 16.4 feet (5000 mm). This helps overcome limitations of standard HDMI cables, maintaining signal integrity for longer runs in setups like home theaters or conference rooms.
What audio features does the VC882 offer?
The VC882 includes audio embedding and de-embedding capabilities. This allows you to embed audio into the HDMI signal or extract audio from it, providing flexibility for integrating with external audio systems or managing audio streams separately.
How many HDMI inputs and outputs does this device have?
It has one HDMI input and one HDMI output, making it a point-to-point signal repeater. This configuration is ideal for extending a single source to a single display, such as connecting a computer to a monitor or a media player to a projector.
What is the purpose of the USB port on the VC882?
The USB port enables data transfer between connected devices, allowing quick file moves or device synchronization. This adds utility beyond signal repetition, making it useful for environments where both AV extension and data sharing are needed.
What power source does the VC882 require?
The repeater operates on 5 V DC input, provided by the included power adapter. This low-voltage design ensures energy efficiency and compatibility with standard power outlets, making it easy to deploy in various settings.
What resolution or display format is specified?
It features a display specification of 4096 x 2160, giving you clear visuals for work and media use.
What refresh rate or brightness details are available?
Display-oriented products are best judged through screen, connectivity, and installation specifications. Those facts help buyers confirm visual fit, mounting flexibility, and deployment suitability more clearly than generic summary text.
