QNAP QSW-M804-4C Ethernet Switch - 4 Ports - Manageable - Gigabit Ethernet - 1000Base-T, 2.5GBase-T, 5GBase-T, 10GBase-T, 10GBase-X - (QSW-M804-4C-US)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
- QSW-M804-4C Ethernet Switch
- Power Cord
- Rackmount kit
- Rubber feet
- Quick Installation Guide (QIG)
Features: Reset Button
Total Number of Network Ports: 4
Network (RJ-45): Yes
Uplink Port: Yes
Port/Expansion Slot Details: 4 x 1/2.5/5/10 Gigabit Ethernet RJ-45 Combo Network Port,4 x 10 Gigabit Ethernet SFP+ Expansion Slot,4 x 10 Gigabit Ethernet SFP+ Fiber Expansion Slot,1 x Gigabit Ethernet RJ-45 Management Port
Media Type Supported: Twisted Pair,Optical Fiber
Ethernet Technology: Gigabit Ethernet
Network Technology: 1000Base-T,2.5GBase-T,5GBase-T,10GBase-T,10GBase-X
Maximum Data Transfer Rate: 1.25 GB/s
Total Number of Expansion Slots: 8
Expansion Slot Type: SFP+
Number of SFP+ Slots: 8
Layer Supported: 2
Networking Standards: IEEE 802.3,IEEE 802.3u,IEEE 802.3ab,IEEE 802.3bz,IEEE 802.3an,IEEE 802.3z,IEEE 802.3ae,IEEE 802.3x,IEEE 802.1Q,IEEE 802.1w,IEEE 802.3ad,IEEE 802.1ab,IEEE 802.1p
Manageable: Yes
Input Voltage: 120 V AC,230 V AC
Power Source: AC,Power Supply
Power Consumption: 70 W
Compatible Rack Unit: 1U
Form Factor: Rack-mountable
Height: 1.84" (46.65 mm)
Width: 11.22" (285 mm)
Depth: 9.31" (236.60 mm)
Weight (Approximate): 4.67 lb (2120 g)
Package Contents:
Environmental Compliance: Waste Electrical and Electronic Equipment Directive (WEEE)
Country of Origin: Taiwan
TAA Compliant: Yes
Limited Warranty: 2 Year
- Cascade to other network devices through the uplink port to expand your local area network
- Quickly and easily set up a wired network with 4 networking ports
- Built-in power supply to ensure all components are being supplied with accurate voltage
- Layer 2 switch provides a complete lineup of features including IGMP snooping, port mirroring, and spanning tree
- Rack mounting enables you to organize wires & secure cables for professional installation
- Managed switch provides a reliable foundation for your network
- Gigabit Ethernet port for ultra-fast network speeds
[custom-specifications]
| Specifications | |
| Manufacturer | QNAP Systems |
| Manufacturer Part Number | QSW-M804-4C-US |
| Manufacturer Website Address | http://www.qnap.com |
| Brand Name | QNAP |
| Product Series | QSW |
| Product Model | M804-4C |
| Product Name | QSW-M804-4C Ethernet Switch |
| Product Type | Ethernet Switch |
| Technical Information | |
| Features | Reset Button |
| Interfaces/Ports | |
| Total Number of Network Ports | 4 |
| Network (RJ-45) | Yes |
| Uplink Port | Yes |
| Port/Expansion Slot Details | 4 x 1/2.5/5/10 Gigabit Ethernet RJ-45 Combo Network Port,4 x 10 Gigabit Ethernet SFP+ Expansion Slot,4 x 10 Gigabit Ethernet SFP+ Fiber Expansion Slot,1 x Gigabit Ethernet RJ-45 Management Port |
| Media & Performance | |
| Media Type Supported | Twisted Pair,Optical Fiber |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 1000Base-T,2.5GBase-T,5GBase-T,10GBase-T,10GBase-X |
| Maximum Data Transfer Rate | 1.25 GB/s |
| I/O Expansions | |
| Total Number of Expansion Slots | 8 |
| Expansion Slot Type | SFP+ |
| Number of SFP+ Slots | 8 |
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.3,IEEE 802.3u,IEEE 802.3ab,IEEE 802.3bz,IEEE 802.3an,IEEE 802.3z,IEEE 802.3ae,IEEE 802.3x,IEEE 802.1Q,IEEE 802.1w,IEEE 802.3ad,IEEE 802.1ab,IEEE 802.1p |
| Management & Protocols | |
| Manageable | Yes |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Power Source | AC,Power Supply |
| Power Consumption | 70 W |
| Physical Characteristics | |
| Compatible Rack Unit | 1U |
| Form Factor | Rack-mountable |
| Height | 1.84" (46.65 mm) |
| Width | 11.22" (285 mm) |
| Depth | 9.31" (236.60 mm) |
| Weight (Approximate) | 4.67 lb (2120 g) |
| Miscellaneous | |
| Package Contents |
|
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
| Warranty | |
| Limited Warranty | 2 Year |
[/custom-specifications]
[custom-options]
| Product | QNAP Rack Ear - For Switch - 1U Rack Height - Rack-mountable |
| SKU | SP-EAR-QSWSTANDARDRACK-01 |
| Sale Price | $34.95 |
| Product | QNAP 1.5m SFP+ 10GbE Direct Attach Cable - 4.9 ft Twinaxial Network Cable for Network Device - First End: 1 x SFP+ Network - Second End: 1 x SFP+ Network - 10 Gbit/s |
| SKU | CAB-DAC15M-SFPP |
| Sale Price | $105.95 |
[/custom-options]
