Samsung LH46OHBESGBXGO OH46B-S 46" Outdoor Digital Signage Display - Full HD 1080p - 4000 cd/m² Brightness - IP56 IK10 - 24/7 Operation - Tizen 6.5
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Product Overview
The Samsung OH46B-S is a professional-grade outdoor digital signage display engineered for demanding commercial environments where visibility, durability, and continuous operation are non-negotiable. With its 46-inch VA panel delivering Full HD 1080p resolution and exceptional 4000 cd/m² brightness, this display ensures content remains vivid and readable even under direct sunlight or harsh lighting conditions.
Built to withstand outdoor elements, it features robust IP56 dust and water resistance alongside IK10 impact protection, making it suitable for transportation hubs, retail storefronts, stadiums, and public information displays. The integrated Tizen 6.5 smart platform provides reliable content management and connectivity options, while the 24/7 operation rating guarantees uninterrupted performance for mission-critical signage applications.
Relevant factors for this section include Bezel Width (Top), Bezel Width (Bottom), Bezel Width (Left), Number of Screens. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Technical Overview
This display utilizes a Vertical Alignment (VA) LCD panel that offers wide viewing angles and consistent color performance across its 46-inch diagonal screen. The 1920 x 1080 Full HD resolution provides sharp image quality for detailed graphics and text, supported by a 6,000:1 dynamic contrast ratio and 72% NTSC color gamut for vibrant visual presentation.
Connectivity is comprehensive with dual HDMI inputs for flexible source switching, plus USB, serial, and Ethernet ports for control and content updates. The display accepts both 120V and 230V AC input voltages, accommodating various regional power standards without requiring external transformers.
Relevant factors for this section include Bezel Width (Top), Bezel Width (Bottom), Bezel Width (Left), Number of Screens. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The OH46B-S distinguishes itself through exceptional outdoor performance characteristics that go beyond typical commercial displays. Its 4000 cd/m² brightness level substantially exceeds indoor display specifications, ensuring content remains visible in bright outdoor settings where standard displays would appear washed out.
Environmental Hardening
IP56 certification provides protection against dust ingress and powerful water jets, while IK10 impact resistance safeguards against vandalism and accidental impacts common in public installations.
Continuous Operation Design
Engineered specifically for 24/7 operation with thermal management and component selection optimized for extended runtime without degradation in performance or reliability.
Installation Flexibility
Standard 995 x 500 mm VESA mounting compatibility allows integration with a wide range of commercial mounting solutions, from wall brackets to specialized outdoor enclosures.
Deployment / Use Cases
This outdoor digital signage display is purpose-built for environments where standard indoor displays would fail. Its combination of high brightness, environmental protection, and continuous operation capability makes it ideal for applications requiring reliable outdoor visual communication.
Typical deployments include transportation hubs for schedule and wayfinding displays, retail storefronts for promotional content visible from parking areas, stadiums and arenas for concession menus and event information, corporate campuses for outdoor directories, and municipal installations for public information and emergency alerts.
Transportation & Wayfinding
Airports, train stations, and bus terminals benefit from the display's readability in various lighting conditions and its ability to withstand temperature fluctuations and environmental exposure.
Retail & Hospitality
Restaurants, hotels, and shopping centers use these displays for outdoor menus, promotional content, and branding that remains visible day and night, attracting customer attention regardless of weather conditions.
Localization and Operating System
The Samsung OH46B-S outdoor digital signage display runs on the Tizen 6.5 operating system, a robust and widely adopted platform in the commercial display market. Tizen 6.5 provides a stable, secure environment for content management, remote monitoring, and application deployment, supporting various digital signage software solutions and media players commonly used in business and public installations.
This operating system enables seamless integration with network-based content delivery systems, allowing for scheduled updates, real-time data feeds, and interactive content without requiring external media players. The display's Ethernet connectivity, combined with Tizen's networking capabilities, facilitates centralized management across multiple displays, making it suitable for large-scale deployments where consistency and control are critical.
While the display does not include specific localization features like multilingual menus or regional content presets, its wide voltage input (120V/230V AC) accommodates global power standards, supporting installations in diverse geographic regions. The Tizen platform's flexibility allows for customization to meet local content requirements, ensuring the display can be adapted for various cultural and regulatory environments in outdoor commercial settings.
Tizen 6.5 Platform
This smart TV operating system offers reliable performance for digital signage, with support for app-based content, remote management tools, and compatibility with major content management systems used in commercial displays.
Global Power Compatibility
With dual voltage input (120V/230V AC), the display can be deployed internationally without needing external transformers, simplifying installation in regions with different electrical standards.
Physical Profile
The display measures 42.09" (1069 mm) wide by 24.55" (623.60 mm) high with a depth of 3.35" (85 mm), presenting a substantial presence suitable for outdoor installations. Its uniform 0.98" (24.90 mm) bezel on all sides enables seamless multi-display configurations for video walls when precise alignment is required. At 79.37 pounds (36000 grams), the unit has substantial weight that contributes to stability in outdoor mounting scenarios while remaining manageable for professional installation teams.
- Width
- 0.98" (24.90 mm)
- Depth
- 3.35" (85 mm)
- Height
- 24.55" (623.60 mm)
- Weight
- 79.37 lb (36000 g)
Highlights
- 46-inch Full HD outdoor digital signage display with 4000 cd/m² brightness
- IP56 certified for dust and water resistance in outdoor environments
- IK10 impact protection rating for vandalism and impact resistance
- 24/7 continuous operation capability for mission-critical applications
- Tizen 6.5 smart platform for content management and connectivity
- Uniform 0.98" bezel on all sides for seamless video wall configurations
- Dual HDMI inputs plus USB, serial, and Ethernet connectivity
- 995 x 500 mm VESA mount compatibility for flexible installation
- Wide voltage input (120V/230V AC) for global deployment
- 36-month limited warranty for commercial peace of mind
Specifications
| Specifications | |
|---|---|
| Manufacturer | Samsung |
| Manufacturer Part Number | LH46OHBESGBXGO |
| Brand Name | Samsung |
| Product Model | OH46B-S |
| Product Name | Outdoor Signage OH46B-S |
| Product Type | Digital Signage Display |
| Technical Information | |
| Bezel Width (Top) | 0.98" (24.90 mm) |
| Bezel Width (Bottom) | 0.98" (24.90 mm) |
| Bezel Width (Left) | 0.98" (24.90 mm) |
| Bezel Width (Right) | 0.98" (24.90 mm) |
| Ingress Protection (IP) Rating | IP56 |
| Impact Protection (IK) Rating | IK10 |
| Panel Technology | Vertical Alignment (VA) |
| Operation Hours | 24 Hours/7 Days |
| Display & Graphics | |
| Number of Screens | 1 |
| Viewable Screen Size | 46" (1168.40 mm) |
| Display Screen Type | LCD |
| Display Resolution | 1920 x 1080 |
| Video | |
| Scan Format | 1080p |
| Dynamic Contrast Ratio | 6,000:1 |
| Brightness | 4000 cd/m² |
| Color Gamut | 72% NTSC |
| Network & Communication | |
| Ethernet | Yes |
| Interfaces/Ports | |
| USB | Yes |
| HDMI | Yes |
| Serial | Yes |
| Number of HDMI Inputs | 2 |
| Software | |
| Operating System | Tizen 6.5 |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Physical Characteristics | |
| VESA Mount Standard | 995 x 500 |
| Height | 24.55" (623.60 mm) |
| Width | 42.09" (1069 mm) |
| Depth | 3.35" (85 mm) |
| Weight (Approximate) | 79.37 lb (36000 g) |
| Miscellaneous | |
| Application/Usage | Outdoor,Business |
| Warranty | |
| Limited Warranty | 36 Month |
User Manual
FAQ
What screen size is listed?
It features a display specification of 46" (1168.40 mm), giving you clear visuals for work and media use.
What resolution or display format is specified?
It features a display specification of 1920 x 1080, giving you clear visuals for work and media use.
What refresh rate or brightness details are available?
The listed power specification is 4000 cd/m², which helps position the unit for the right load level and installation role.
What input or connectivity options are listed?
Connectivity support is listed in the product specifications, including the relevant wireless or port options when available.
Does the display support VESA mounting or adjustment features?
It features a display specification of 995 x 500, giving you clear visuals for work and media use.
What panel or display technology is mentioned?
It features a display specification of Vertical Alignment (VA), giving you clear visuals for work and media use.
