StarTech.com 1-Port Serial to Ethernet Adapter, IP Serial Device Server For Remote RS232 Devices, Wall/DIN Rail Mount, LAN To DB9 - to (I13-SERIAL-ETHERNET)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
- Device Server
- 1 x Din Rail Kit
- 1 x Mounting Bracket
- 4 x Mounting Bracket Screws
- 1 x Universal Power Adapter
- 1 x Quick-Start Guide
Connectivity Technology: Wired
Media Type Supported: Twisted Pair
Ethernet Technology: Fast Ethernet
Network Standard: 10/100Base-T
Network (RJ-45): Yes
Serial Port: Yes
Total Number of Network Ports: 1
Number of Network (RJ-45) Ports: 1
Number of Serial Ports: 1
Input Voltage: 120 V AC,230 V AC
Input Voltage Range: 100V AC to 240V AC
Power Consumption: 15 W
Plug/Connector Type: Type M
Color Family: Black
Product Color: Black
Form Factor: DIN Rail Mountable,Wall Mountable
Height: 1" (25.40 mm)
Width: 3.20" (81.28 mm)
Depth: 1.80" (45.72 mm)
Weight (Approximate): 5.50 oz (155.92 g)
Package Contents:
TAA Compliant: Yes
Limited Warranty: 2 Year
- SINGLE PORT SERIAL TO IP CONVERTER: Connect different RS232 serial devices remotely over an IP-based network; Use for POS systems, barcode readers, sensors, weighing systems, CNC controllers & PLCs; DB9 serial port supports up to 921.6Kbps; TAA Compliant
- UNIFIED ECOSYSTEM EXPERIENCE: All our device servers share the same management software and Web UI; View/manage individual devices with a common UI on any OS; Windows software to set up virtual com ports and view/manage all device servers on the network
- VERSATILE CONFIGURATIONS: RJ45 LAN to RS232 converter support TCP client/server mode to enable serial tunneling between two device servers over a LAN; Export/import settings, custom naming / location, admin password protection, and upgradeable firmware
- ETHERNET AND POWER OPTIONS: Single 10/100Mbps RJ45 port w/auto-negotiation; Serial device server operates over Telnet (RFC2217)/UDP/TCP; Serial to LAN converter includes a power adapter & supports 5V over pin 9 for serial devices
- RUGGED AND MOUNTABLE ENCLOSURE: All-metal housing ensures durability in harsh conditions; Supports Level-4 ESD protection (15kV air/8kV contact); Includes the necessary wall and DIN rail mounting hardware; Dimensions 1.8x1x3.2in (46.1x 25x 81.9mm)
- SERIAL TO IP CONVERTER OPTIONS: Our family of device servers includes the following options: I13-SERIAL-ETHERNET (1 Port), I13P-SERIAL-ETHERNET (1 Port w/ PoE), I23-SERIAL-ETHERNET (2 Port), and I43-SERIAL-ETHERNET (4 Port)
[custom-specifications]
| Specifications | |
| Manufacturer | StarTech.com |
| Manufacturer Part Number | I13-SERIAL-ETHERNET |
| Manufacturer Website Address | http://www.startech.com |
| Brand Name | StarTech.com |
| Product Name | Device Server |
| Product Type | Device Server |
| Technical Information | |
| Connectivity Technology | Wired |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Network & Communication | |
| Ethernet Technology | Fast Ethernet |
| Network Standard | 10/100Base-T |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Serial Port | Yes |
| Total Number of Network Ports | 1 |
| Number of Network (RJ-45) Ports | 1 |
| Number of Serial Ports | 1 |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Input Voltage Range | 100V AC to 240V AC |
| Power Consumption | 15 W |
| Plug/Connector Type | Type M |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Form Factor | DIN Rail Mountable,Wall Mountable |
| Height | 1" (25.40 mm) |
| Width | 3.20" (81.28 mm) |
| Depth | 1.80" (45.72 mm) |
| Weight (Approximate) | 5.50 oz (155.92 g) |
| Miscellaneous | |
| Package Contents |
|
| TAA Compliant | Yes |
| Warranty | |
| Limited Warranty | 2 Year |
[/custom-specifications]
[custom-user-manual]
Available Documentation:
User-Manual
Manufacturer-Brochure
[/custom-user-manual]
