StarTech. com NLAQ-3F-CAT6A-PATCH CAT6a Ethernet Patch Cable - 3ft Aqua LSZH S/FTP Shielded 10GbE 100W PoE++ Snagless RJ45
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This CAT6a cable operates at a 500 MHz bandwidth and supports data transfer rates up to 10 Gbps over its 3-foot length. The S/FTP shielding configuration combines individual foil-wrapped twisted pairs with an overall braided shield, effectively minimizing electromagnetic interference (EMI) and near-end crosstalk (NEXT) for error-free multi-gigabit connections.
The 27 AWG stranded copper construction ensures flexibility and durability, while the LSZH jacket material reduces smoke density and halogen emissions in the event of a fire, meeting stringent safety standards for enclosed spaces. ETL verification confirms compliance with ANSI/TIA-568.2-D specifications, guaranteeing interoperability with existing Cat6 and earlier network infrastructure.
This section brings together practical product details such as Cable Type, Cable Characteristic, Cable Length, Product Color, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
This patch cable combines advanced shielding, premium materials, and rigorous testing to deliver consistent performance in high-density network environments. The LSZH jacket and full copper construction provide long-term reliability, while the snagless design simplifies cable management.
Superior Shielding
S/FTP shielding with foil and braid layers protects against EMI/RFI interference, ensuring stable 10GbE and PoE++ performance even in electrically noisy environments.
- Individual pair foil shielding
- Overall braided shield
- Gold-plated shielded connectors
Enhanced Safety
The LSZH jacket produces less toxic smoke than PVC alternatives, making this cable ideal for plenum spaces, data centers, and areas with strict fire safety requirements.
- PVC-free construction
- Low smoke emission
- Halogen-free materials
Durable Design
Stranded copper conductors and reinforced boots resist bending damage, while corrosion-resistant materials ensure reliable connections over the cable's lifetime.
- Strain relief boots
- Bend-resistant jacket
- Corrosion-resistant contacts
Deployment / Use Cases
This CAT6a patch cable is engineered for scenarios requiring high-speed data transfer and reliable power delivery. Its 3-foot length makes it ideal for connecting network equipment in rack-mounted configurations, while the shielding and construction ensure performance in enterprise environments.
Common applications include connecting switches to servers in data centers, linking PoE++ devices like access points and security cameras, and providing backbone connections in office networks. The aqua color allows for easy identification in cable management systems, and the LSZH jacket makes it suitable for installations where fire safety regulations restrict PVC use.
Physical Profile
The cable features a distinctive aqua-colored LSZH jacket that provides both visual identification and enhanced safety characteristics. With a weight of approximately 1.37 oz (38.90 g), this lightweight yet durable patch cord maintains flexibility for easy routing in tight spaces while the snagless boots prevent accidental disconnection in crowded patch panels.
- Weight
- 1.37 oz (38.90 g)
- Length
- 3 ft (0.91 m)
Highlights
- Category 6a Ethernet patch cable supporting 10GbE speeds up to 3 feet
- S/FTP shielding with foil and braid for maximum EMI/RFI protection
- LSZH (Low Smoke Zero Halogen) jacket for enhanced fire safety
- 100W PoE++ support compliant with IEEE 802.3bt standard
- Gold-plated RJ45 connectors with snagless molded boots
- 100% stranded copper conductors (27 AWG) for reliable performance
- ETL verified to meet ANSI/TIA-568.2-D standards
- Lifetime warranty backed by StarTech.com
Specifications
| Specifications | |
|---|---|
| Manufacturer | StarTech.com |
| Manufacturer Part Number | NLAQ-3F-CAT6A-PATCH |
| Brand Name | StarTech.com |
| Product Name | CAT6A LSZH Ethernet Cable |
| Packaged Quantity | 1 |
| Product Type | Network Cable |
| Technical Information | |
| Cable Type | Category 6a |
| Cable Characteristic | Patch Cable |
| Cable Length | 3 ft (0.91 m) |
| Connector Type on First End | RJ-45 Network - Male |
| Connector Gender on First End | Male |
| Connector on First End Details | 1 x RJ-45 Network - Male |
| Connector Type on Second End | RJ-45 Network - Male |
| Connector Gender on Second End | Male |
| Connector on Second End Details | 1 x RJ-45 Network - Male |
| Contact Plating | Gold |
| Shielding | Yes |
| Jacket Type | LSZH |
| Device Supported | Network Device |
| American Wire Gauge | 27 AWG |
| Data Transfer Rate | 10 Gbit/s |
| Boot Type | Snagless,Molded |
| Number of Pairs | 4 |
| Features | PoE,PoE++,Stranded,EMI/RF Protection,Noise Protection,Corrosion Resistant,Fire Resistant,Latch Protection,Snag Resistant,Strain Relief,Minimized Near-End Crosstalk (NEXT),PVC Free,Damage Resistant,Bend Resistant |
| Physical Characteristics | |
| Product Color | Aqua |
| Product Material | Copper |
| Shielding Material | Foil |
| Weight (Approximate) | 1.37 oz (38.90 g) |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE),Restriction of Hazardous Substances (RoHS) |
| Country of Origin | China |
| Warranty | |
| Limited Warranty | Lifetime |
User Manual
FAQ
What is the maximum data speed this CAT6a cable supports?
This StarTech.com CAT6a patch cable supports data transfer rates up to 10 Gbps (10GbE) at its full 3-foot length. It operates at a 500 MHz bandwidth and is backward compatible with Cat6, Cat5e, and earlier standards, making it suitable for multi-gigabit network connections in both current and legacy environments.
Does this cable support Power over Ethernet (PoE)?
Yes, this cable fully supports Power over Ethernet up to 100W, compliant with the IEEE 802.3bt (PoE++) standard. The 100% stranded copper construction ensures stable power delivery to PoE devices such as access points, security cameras, and VoIP phones, unlike lower-quality copper-clad aluminum alternatives.
What does S/FTP shielding mean for this Ethernet cable?
S/FTP shielding indicates this cable has both overall braided shielding (S) and individual foil shielding around each twisted pair (FTP). This dual-layer protection minimizes electromagnetic interference (EMI) and near-end crosstalk (NEXT), ensuring signal integrity for 10GbE connections even in electrically noisy environments like data centers.
Why is the LSZH jacket important for network installations?
The Low Smoke Zero Halogen (LSZH) jacket produces less dense and less corrosive smoke than traditional PVC jackets in the event of a fire. This makes the cable suitable for plenum spaces, data centers, and other environments with strict fire safety regulations where reduced smoke toxicity and halogen emissions are required.
What are the benefits of the snagless RJ45 connectors?
The snagless molded boots on the RJ45 connectors provide strain relief and latch protection, preventing the connector tabs from catching on other cables or equipment during installation and removal. This design reduces the risk of damage to both the cable and network ports, extending the lifespan of your connectivity infrastructure.
Is this cable tested and certified for performance?
Yes, each cable is individually tested and ETL verified to meet ANSI/TIA-568.2-D standards for Category 6a performance. This certification ensures reliable 10GbE operation, proper shielding effectiveness, and backward compatibility with existing network equipment, giving you confidence in its interoperability and performance.
