StarTech.com CK4-HP104C Secure 4-Port KVM Switch - HDMI or DisplayPort - 4K 60Hz - NIAP 4.0 - CAC - Made in USA
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This analog KVM switch uses wired connectivity to support four computers simultaneously. It features 5 HDMI ports and 5 DisplayPort ports for flexible video connections, plus 11 USB 2.0 ports for peripheral management. The switch delivers 3840 x 2160 resolution at 60Hz refresh rates, ensuring high-definition visual performance.
Security features include LED indicators for port status and CAC connectivity, anti-tamper switches that disable functionality upon intrusion detection, and visual/audible alerts for security breaches. The unit has no internal memory or storage, preventing data retention between sessions.
Relevant factors for this section include KVM Technology, Connectivity Technology, Number of Computers Supported, Graphic Mode. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
This secure KVM switch combines high-performance video switching with military-grade security features. The NIAP PSD 4.0 certification ensures compliance with stringent data protection standards, while the tamper protection system provides physical security against unauthorized access.
CAC Integration
The dedicated CAC port passes smart card signals through the KVM, enabling secure login to connected systems without requiring individual card readers. This simplifies authentication management in multi-system environments.
- Eliminates need for separate CAC readers
- Centralizes smart card authentication
- Maintains security chain of custody
Tamper Protection
Anti-tamper switches detect physical intrusion attempts and immediately disable all KVM functionality. The tamper-evident seal provides visual confirmation if the unit has been previously opened.
- Intrusion detection system
- Visual and audible alerts
- Tamper-evident sealing
Enterprise Reliability
Built in the USA with industrial-grade components, this KVM is designed for continuous operation in demanding environments. The 3-year warranty and TAA compliance ensure long-term reliability and procurement suitability.
- Made in USA construction
- 3-year limited warranty
- TAA compliant for government use
Deployment / Use Cases
This secure KVM switch is ideal for environments requiring both multi-system control and stringent security protocols. Government agencies, military installations, financial institutions, and research facilities benefit from its NIAP certification and tamper protection features.
The switch efficiently manages server rooms with mixed HDMI and DisplayPort systems, allowing administrators to control multiple machines from a single secure location. Data centers handling classified information can use the CAC integration for centralized authentication while maintaining complete system isolation.
Secure Control Rooms
Monitor and manage multiple secure workstations or servers from a single console while maintaining data isolation between systems. The 4K video support ensures clear visibility of all connected machines.
Government IT Infrastructure
Deploy in environments requiring NIAP compliance and TAA-approved equipment. The tamper protection and CAC integration meet strict government security standards for sensitive data handling.
Physical Profile
The desktop form factor measures 12.60" (320 mm) in length, 6.70" (170.18 mm) in width, and 1.70" (43.18 mm) in height, with a weight of approximately 4.19 lb (1900 g). This compact design fits easily on desks or in server racks while providing substantial connectivity options. The unit operates on 12VDC power and includes status LEDs for at-a-glance monitoring of connection status and security indicators.
- Width
- 6.70" (170.18 mm)
- Height
- 1.70" (43.18 mm)
- Weight
- 4.19 lb (1900 g)
- Length
- 12.60" (320 mm)
What's in the Box
The package includes everything needed for immediate deployment of the secure KVM switch.
Package contents include Secure KVM Switch, 1x Universal Power Adapter, 1x Product Documentation. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- Controls 4 HDMI or DisplayPort computers from one console
- NIAP PSD 4.0 certified for secure data isolation
- Dedicated CAC port for smart card authentication
- Tamper protection with anti-tamper switches and seals
- 4K resolution at 60Hz refresh rate
- 5 HDMI and 5 DisplayPort video ports
- 11 USB 2.0 ports for peripheral management
- Built in the USA with TAA compliance
- 3-year limited warranty
- Desktop form factor with compact dimensions
Specifications
| Specifications | |
|---|---|
| Manufacturer | StarTech.com |
| Manufacturer Part Number | CK4-HP104C |
| Brand Name | StarTech.com |
| Product Name | Secure KVM Switch |
| Packaged Quantity | 1 |
| Product Type | KVM Switchbox |
| Technical Information | |
| KVM Technology | Analog |
| Connectivity Technology | Wired |
| Number of Computers Supported | 4 |
| Features | LED Indicator,Intrusion Detection,Anti-tamper Switch,Tamper Resistant |
| Video | |
| Graphic Mode | 4K |
| Maximum Video Resolution | 3840 x 2160 |
| Interfaces/Ports | |
| USB | Yes |
| USB Standard | USB 2.0 |
| USB 2.0 | Yes |
| HDMI | Yes |
| DisplayPort | Yes |
| Number of USB Ports | 11 |
| Number of HDMI Ports | 5 |
| Number of DisplayPorts | 5 |
| Power Description | |
| Input Voltage Range | 12VDC |
| Physical Characteristics | |
| Form Factor | Desktop |
| Height | 1.70" (43.18 mm) |
| Width | 6.70" (170.18 mm) |
| Length | 12.60" (320 mm) |
| Weight (Approximate) | 4.19 lb (1900 g) |
| Miscellaneous | |
| Package Contents | Secure KVM Switch 1x Universal Power Adapter 1x Product Documentation |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Country of Origin | United States |
| TAA Compliant | Yes |
| Warranty | |
| Limited Warranty | 3 Year |
FAQ
What video resolutions does this KVM switch support?
The StarTech.com CK4-HP104C supports 4K resolution at 3840 x 2160 pixels with a 60Hz refresh rate. This ensures high-definition video quality across all connected systems, making it suitable for detailed graphical work and monitoring applications where visual clarity is essential.
How many computers can I connect to this KVM switch?
This secure KVM switch supports up to four computers simultaneously. You can connect a mix of HDMI and DisplayPort systems, with the switch providing dedicated ports for each interface type. The analog technology ensures reliable switching between all connected machines from a single console.
What security certifications does this KVM have?
This KVM switch is NIAP PSD 4.0 certified, meeting stringent security standards for data isolation and protection. It also features TAA compliance for government procurement and includes tamper protection with anti-tamper switches that disable functionality upon intrusion detection, along with tamper-evident seals for physical security verification.
How does the CAC port work with this KVM?
The dedicated Common Access Card (CAC) port passes smart card signals through the KVM to connected systems, enabling secure authentication without requiring individual card readers on each machine. This centralizes smart card management for IT administrators while maintaining the security chain required for sensitive environments.
What type of USB connectivity does this switch provide?
The switch includes 11 USB 2.0 ports for connecting peripherals such as keyboards, mice, and other input devices. USB 2.0 provides sufficient bandwidth for standard peripheral operation while maintaining compatibility with a wide range of enterprise hardware commonly used in secure computing environments.
What is included in the package with this KVM switch?
The package contains the secure KVM switch unit, one universal power adapter (12VDC input), and product documentation. This complete set allows for immediate deployment without requiring additional components for basic operation in desktop or rack-mounted configurations.
