StarTech.com PCIUSB7 7-Port PCI USB 2.0 Card Adapter - 480 Mbps Data Transfer - Plug-in Card
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This PCI USB card operates on the PCI 2.2 specification and is fully compliant with USB 2.0 standards, including EHCI revision 0.95 and UHCI 1.1 specifications. It delivers consistent 480 Mbps transfer speeds across all seven ports while maintaining backward compatibility with USB 1.1 and 1.0 devices.
The card features robust power delivery with up to 500mA per port, ensuring stable operation for power-hungry peripherals. Its plug-and-play design allows for easy installation without complex configuration, and hot-swap compatibility enables safe connection and disconnection of devices while the system is running.
Relevant factors for this section include Host Interface, Data Transfer Rate. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The PCIUSB7 stands out for its balanced combination of port density, performance, and compatibility. It transforms a single PCI slot into a versatile USB hub that can handle multiple simultaneous connections without compromising speed or stability.
Expanded Connectivity
Adds seven USB 2.0 ports to systems with limited built-in USB connectivity, supporting both external devices and internal connections through header ports.
- 4 external Type-A ports
- 3 internal port headers
- Single PCI slot installation
Reliable Performance
Delivers consistent 480 Mbps transfer speeds with full USB 2.0 compliance, ensuring fast data transfers for storage devices, printers, scanners, and other peripherals.
- 480 Mbps maximum transfer rate
- USB EHCI and UHCI compliant
- 500mA power per port
Deployment / Use Cases
This PCI USB card adapter is ideal for desktop computers that require additional USB ports beyond what the motherboard provides. It serves as a cost-effective upgrade path for older systems with limited USB connectivity or for workstations that need to connect multiple USB devices simultaneously.
Common deployment scenarios include point-of-sale systems, legacy industrial PCs, home office workstations, and testing environments where multiple USB devices need to be connected and disconnected frequently. The card's compatibility with PC, Linux, and Mac systems makes it suitable for mixed-IT environments and cross-platform deployments.
Legacy System Upgrade
Add modern USB 2.0 connectivity to older desktop computers that only have USB 1.1 ports or insufficient USB port count.
Peripheral Expansion
Connect multiple USB devices such as external hard drives, printers, scanners, keyboards, mice, and audio interfaces without requiring separate hubs.
Physical Profile
The PCIUSB7 features a standard plug-in card design measuring 4.80 inches in length, 4.72 inches in width, and 0.80 inches in height. This compact form factor ensures compatibility with most desktop computer cases and PCI slots. The card's lightweight construction at approximately 2.60 ounces minimizes strain on the PCI slot while providing durable connectivity.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 0.80" (20.32 mm), 4.72" (119.89 mm), 2.60 oz (73.71 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 4.72" (119.89 mm)
- Height
- 0.80" (20.32 mm)
- Weight
- 2.60 oz (73.71 g)
- Length
- 4.80" (121.92 mm)
What's in the Box
The package includes everything needed for installation and operation of the PCI USB card adapter.
Highlights
- Adds 7 USB 2.0 ports via a single PCI slot
- 480 Mbps maximum data transfer rate
- 4 external ports and 3 internal port headers
- Backward compatible with USB 1.1/1.0 devices
- 500mA power delivery per port
- Plug-and-play and hot-swap compatible
- Supports PC, Linux, and Mac systems
- 2-year limited warranty
- TAA compliant and environmentally friendly
- Compact plug-in card form factor
Specifications
| Specifications | |
|---|---|
| Manufacturer | StarTech.com |
| Manufacturer Part Number | PCIUSB7 |
| Brand Name | StarTech.com |
| Product Name | 7 Port PCI USB Card Adapter |
| Packaged Quantity | 1 Each |
| Product Type | USB Adapter |
| Technical Information | |
| Host Interface | PCI |
| Media & Performance | |
| Data Transfer Rate | 480 MB/s |
| Interfaces/Ports | |
| Total Number of USB Ports | 7 |
| Number of USB 2.0 Ports | 7 |
| Physical Characteristics | |
| Form Factor | Plug-in Card |
| Height | 0.80" (20.32 mm) |
| Width | 4.72" (119.89 mm) |
| Length | 4.80" (121.92 mm) |
| Weight (Approximate) | 2.60 oz (73.71 g) |
| Miscellaneous | |
| Package Contents | 1 x PCI USB 2.0 Card 1 x Driver CD 1 x Instruction Manual |
| Platform Supported | PC,Linux,Mac |
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
| Environmentally Friendly | Yes |
| Warranty | |
| Limited Warranty | 2 Year |
User Manual
FAQ
How many USB ports does this PCI card add to my computer?
The StarTech.com PCIUSB7 adds seven USB 2.0 ports total. This includes four external Type-A ports accessible from the back of your computer and three internal port headers that can be used with additional USB connectors inside the case. All ports support the full USB 2.0 specification with data transfer rates up to 480 Mbps.
What type of PCI slot does this card require?
This card requires a standard PCI slot that complies with PCI revision 2.2 specification. It is not compatible with PCI Express (PCIe) slots. The card uses the traditional 32-bit PCI interface commonly found on older desktop motherboards and some industrial PCs. Ensure your system has an available PCI slot before purchasing.
Is this card compatible with USB 3.0 or newer devices?
No, this is a USB 2.0 card that operates at maximum speeds of 480 Mbps. While it is backward compatible with USB 1.1 and 1.0 devices, it does not support USB 3.0, 3.1, or USB-C specifications. USB 3.0 devices connected to this card will function but will be limited to USB 2.0 speeds of 480 Mbps.
What operating systems are supported by this PCI USB card?
The PCIUSB7 supports PC (Windows), Linux, and Mac operating systems. The card features plug-and-play functionality that typically works with built-in operating system drivers, though a driver CD is included for systems that require additional software. Specific driver requirements may vary by OS version, so consult the included documentation for compatibility details.
Can I connect USB hubs to expand beyond seven devices?
Yes, you can connect USB hubs to any of the seven ports to expand connectivity further. The card supports up to 127 USB devices total when used with additional USB hubs, as per the USB specification. Each port provides up to 500mA of power, so ensure connected hubs and devices do not exceed the available power budget for stable operation.
What is included in the package with this PCI USB card?
The package includes the PCI USB 2.0 card itself, a driver CD with installation software for systems that require it, and a comprehensive instruction manual with setup guidance. The card is ready for installation into any compatible PCI slot, and the documentation provides details on physical installation, driver setup, and troubleshooting if needed.
