TP-LINK VIGI C540 4MM 4MP Outdoor Dome Network Camera - White - 30m Infrared Night Vision - 2560 x 1440 - H. 265+ - IP66 - PoE/DC
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This camera utilizes a CMOS image sensor that captures 4-megapixel footage with efficient power consumption. The lens system includes an M12-mount fixed lens with an f/1.6 aperture, optimizing light intake for better low-light performance. Video compression leverages H.265+ and H.265 codecs, reducing bandwidth and storage requirements without compromising quality.
Network connectivity is wired via RJ-45, supporting remote management for real-time monitoring and configuration. Storage options include local SD card support, allowing for on-device recording. The camera operates within a wide temperature range from -301°C to 60°C, ensuring functionality in extreme climates.
Relevant factors for this section include HD Recording, Night Vision, Night Vision Distance, Image Sensor Type. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The VIGI C540 4MM combines high-resolution imaging with robust construction for dependable outdoor surveillance. Its intelligent features and flexible power options make it a versatile choice for security professionals.
Enhanced Night Vision
Infrared illumination reaches 30 meters, providing reliable monitoring in complete darkness without additional lighting.
- Infrared night vision
- 98.43 ft (30 m) range
- Full-color day mode
Advanced Video Processing
Supports H.265+ compression for efficient bandwidth use and includes features like Digital WDR and 3D noise reduction.
- H.265+, H.265, H.264+
- Digital Wide Dynamic Range
- 3D Digital Noise Reduction
Durable Outdoor Design
IP66-rated dome housing protects against dust and water jets, suitable for all-weather outdoor installation.
- IP66 ingress protection
- White dome form factor
- Ceiling, wall, pole mount
Deployment / Use Cases
This camera is ideal for commercial and industrial surveillance applications where clear, continuous footage is essential. Its outdoor durability and night vision capabilities make it perfect for monitoring entrances, perimeters, and high-traffic areas after dark.
Common deployments include retail storefronts, warehouse exteriors, school campuses, and residential complexes. The PoE support allows for streamlined installation in networked security systems, while local SD storage provides a backup recording option. Integration with VIGI NVRs or compatible third-party systems enables centralized management for multi-camera setups.
Relevant factors for this section include HD Recording, Night Vision, Night Vision Distance, Image Sensor Type. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Perimeter Security
Monitor fences, gates, and building edges with its wide field of view and tamper detection.
Parking Lot Surveillance
Capture license plates and vehicle movements in low-light conditions using its infrared night vision.
Physical Profile
The camera features a compact white dome design measuring 4.72 inches in height, 6.77 inches in width, and 7.80 inches in depth. Weighing only 195 grams, it is lightweight yet sturdy, with mounting options for ceiling, wall, or pole installations. The dome form factor provides a discreet appearance while offering 360-degree rotation flexibility for optimal positioning.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 4.72" (120 mm), 6.77" (172 mm), 7.80" (198 mm), 6.88 oz (195 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 6.77" (172 mm)
- Depth
- 7.80" (198 mm)
- Height
- 4.72" (120 mm)
- Weight
- 6.88 oz (195 g)
- Length
- 4 mm (0.16")
Highlights
- 4MP resolution for detailed 2560x1440 video recording
- 30-meter infrared night vision for 24/7 monitoring
- IP66-rated weatherproof dome housing for outdoor use
- Supports Power over Ethernet (PoE) and 12V DC power
- H.265+ compression reduces bandwidth and storage needs
- Wide 93° diagonal field of view covers large areas
- Includes human detection, motion detection, and tamper detection
- Local SD card storage for on-device recording
- Fixed 4mm lens with f/1.6 aperture for low-light performance
- Remote management capability for easy configuration
Specifications
| Specifications | |
|---|---|
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Manufacturer Part Number | VIGI C540(4MM) |
| Brand Name | TP-Link |
| Product Line | VIGI |
| Product Model | C540 |
| Product Name | VIGI 4MP Outdoor Full-Color Pan Tilt Network Camera |
| Product Type | Network Camera |
| Technical Information | |
| HD Recording | Yes |
| Night Vision | Yes |
| Night Vision Distance | 98.43 ft (30 m) |
| Night Vision Type | Infrared |
| Display & Graphics | |
| Image Sensor Type | CMOS |
| Color Supported | Color |
| Field of View | Horizontal FOV: 79°, Vertical FOV: 43°, Diagonal FOV: 93° |
| Effective Camera Resolution | 4 Megapixel |
| Video | |
| Video Formats | H.265+,H.265,H.264+,H.264 |
| Maximum Video Resolution | 2560 x 1440 |
| Maximum Frame Rate | 30 fps |
| Lens | |
| Lens Type | Fixed |
| Maximum Focal Length | 4 mm (0.16") |
| Lens Included | Yes |
| Lens Mount Type | M12-mount |
| Maximum Aperture | f/1.6 |
| Network & Communication | |
| Connectivity Technology | Wired |
| Remote Management | Yes |
| Storage | |
| Storage Type | Memory Card |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Power Description | |
| Input Voltage | 12 V DC |
| Power Source Type | DC,PoE |
| Physical Characteristics | |
| Color Family | White |
| Product Color | White |
| Mount Type | Ceiling Mount,Wall Mount,Pole Mount |
| Form Factor | Dome |
| Durability | Water Proof |
| Height | 4.72" (120 mm) |
| Width | 6.77" (172 mm) |
| Depth | 7.80" (198 mm) |
| Weight (Approximate) | 6.88 oz (195 g) |
| Environmental Conditions | |
| Minimum Operating Temperature | -509.8°F (-301°C) |
| Maximum Operating Temperature | 140°F (60°C) |
| Miscellaneous | |
| Features | Human Detection,Motion Detection,Cross Line Detection,Tamper Detection,SD Card Local Storage,Digital Wide Dynamic Range (D-WDR),3D Digital Noise Reduction,Password Protection,White Balance,Back Light Compensation (BLC) |
| Indoor/Outdoor | Outdoor |
| Ingress Protection Rating | IP66 |
FAQ
What is the maximum video resolution of the TP-LINK VIGI C540 4MM?
The camera records at a maximum resolution of 2560 x 1440 pixels, which is 4 megapixels. This provides clear, detailed footage suitable for identifying faces, license plates, and other critical details in surveillance scenarios.
How far does the night vision reach on this camera?
The infrared night vision effectively covers distances up to 98.43 feet (30 meters). This allows for reliable monitoring in complete darkness, making it ideal for outdoor areas like parking lots, building perimeters, and alleyways during nighttime hours.
Can this camera be used outdoors in all weather conditions?
Yes, the camera is designed for outdoor use with an IP66 ingress protection rating. This means it is dust-tight and protected against powerful water jets, ensuring reliable operation in rain, snow, and other harsh weather conditions.
What power options does the VIGI C540 4MM support?
It supports both Power over Ethernet (PoE) and 12V DC power. PoE simplifies installation by delivering power and data through a single Ethernet cable, while the DC option provides flexibility for locations without PoE switches or injectors.
Does this camera include local storage capabilities?
Yes, it supports local storage via a memory card (SD card). This allows for on-device recording without requiring a network video recorder (NVR), useful for standalone deployments or as a backup storage solution in networked systems.
What mounting options are available for this dome camera?
The camera can be mounted on ceilings, walls, or poles, offering flexibility for various installation scenarios. Its dome design allows for adjustable positioning to achieve the optimal viewing angle for your surveillance needs.
