Product Features
Technical Overview
The TPE-TG51g operates as an unmanaged Layer 2 switch with five 10/100/1000BASE-T RJ-45 ports, four of which provide PoE+ power per IEEE 802.3af (15.4W per port) and IEEE 802.3at (30W per port) standards. The switch supports a 60W total PoE budget, allowing simultaneous power delivery to multiple devices while maintaining a 64.30W power consumption from the included 55V DC, 1.3A adapter.
Network performance is driven by a non-blocking switching architecture with 10Gbps aggregate throughput, auto-negotiation and auto-MDI/MDIX on all ports, and compliance with IEEE 802.3, 802.3u, 802.3ab, 802.3x, and 802.3p standards for reliable Gigabit Ethernet operation. The integrated DIP switch enables port-based VLAN isolation to segment traffic and basic QoS to prioritize voice or video traffic across connected devices.
Relevant factors for this section include Total Number of Network Ports, Network (RJ-45), Port/Expansion Slot Details, Media Type Supported. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
This switch combines PoE+ power delivery, compact design, and essential management features in a cost-effective package suitable for deployments where simplicity and reliability are key. The metal construction ensures durability and heat dissipation, while the wall-mount capability allows for discreet installation in tight spaces such as retail counters, office ceilings, or network closets.
PoE+ Flexibility
Four PoE+ ports deliver up to 30W per port to power IP cameras, access points, and other PDs without separate power adapters, reducing cable clutter and installation complexity.
- 60W total budget
- IEEE 802.3af/at compliant
- Extended 200m range at 10Mbps
Compact Deployment
The small footprint and wall-mount design make this switch ideal for space-constrained environments, with a metal housing that provides robust physical protection and thermal management.
- 4.76" × 2.95" × 1.02" dimensions
- 8.68 oz weight
- No rack space required
Basic Traffic Management
DIP switches enable straightforward VLAN port isolation and QoS settings, allowing network segmentation and traffic prioritization without complex configuration interfaces.
- Port-based VLAN isolation
- QoS for voice/video
- Plug-and-play operation
Deployment / Use Cases
The TPE-TG51g is engineered for small-scale networking scenarios where PoE power and compact form factor are critical. Its four PoE+ ports and 60W budget support simultaneous operation of multiple powered devices, making it a practical choice for environments with limited power outlets or cable runs.
Typical applications include small office networks where IP phones and wireless access points need centralized PoE power, retail POS systems connecting IP cameras and digital signage, and light commercial installations such as hotel rooms or classrooms deploying VoIP phones and thin clients. The extended 200-meter PoE+ range at 10Mbps also facilitates device placement in warehouses, parking lots, or outdoor areas where power sources are distant.
Small Office / Retail
Power up to four IP cameras, access points, or VoIP phones from a single switch, reducing AC adapter needs and simplifying network cabling in compact retail counters or office workstations.
Light Commercial / IoT
Deploy in hotel rooms, classrooms, or small branches to connect PoE-powered devices like digital signage, sensors, or thin clients, leveraging the wall-mount design for discreet installation.
Physical Profile
The switch features a compact metal enclosure measuring 4.76 inches wide, 2.95 inches deep, and 1.02 inches high (121 × 75 × 26 mm), with a weight of 8.68 ounces (246 grams). This slim profile supports wall mounting via included hardware or can be placed on a desktop, making it adaptable to various installation environments without consuming rack space. The metal construction enhances durability and heat dissipation, ensuring stable operation in typical office temperatures.
- Width
- 4.76" (121 mm)
- Depth
- 2.95" (75 mm)
- Height
- 1.02" (26 mm)
- Weight
- 8.68 oz (246 g)
What's in the Box
The package includes all necessary components for immediate deployment.
Highlights
- 4 Gigabit PoE+ ports with 60W total budget
- 1 additional Gigabit Ethernet port for uplink or non-PoE devices
- Layer 2 switching with 10Gbps switching capacity
- Extended PoE+ range up to 200 meters at 10Mbps
- DIP switch for VLAN port isolation and QoS prioritization
- Compact metal housing with wall-mountable design
- TAA compliant for U.S. and Canadian government procurement
- Lifetime warranty for long-term reliability
Specifications
| Specifications | |
|---|---|
| Manufacturer | TRENDnet |
| Manufacturer Part Number | TPE-TG51g |
| Brand Name | TRENDnet |
| Product Model | TPE-TG51g |
| Product Name | 5-Port Gigabit PoE+ Switch |
| Product Type | Ethernet Switch |
| Interfaces/Ports | |
| Total Number of Network Ports | 5 |
| Network (RJ-45) | Yes |
| Port/Expansion Slot Details | 4 x Gigabit Ethernet PoE+,1 x Gigabit Ethernet Network |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 1000Base-T |
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.3af,IEEE 802.3at,IEEE 802.3,IEEE 802.3u,IEEE 802.3ab,IEEE 802.3x,IEEE 802.3p |
| Power Description | |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 60 W |
| Power Source | Power Adapter |
| Power Consumption | 64.30 W |
| Physical Characteristics | |
| Form Factor | Wall Mountable |
| Height | 1.02" (26 mm) |
| Width | 4.76" (121 mm) |
| Depth | 2.95" (75 mm) |
| Weight (Approximate) | 8.68 oz (246 g) |
| Miscellaneous | |
| Package Contents | 5-Port Gigabit PoE+ Switch Quick Installation Guide Power Adapter (55V DC, 1.3A) |
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
User Manual
FAQ
How many PoE+ ports does this switch have, and what is the total PoE budget?
The TRENDnet TPE-TG51g includes four Gigabit PoE+ ports that support IEEE 802.3af and 802.3at standards, delivering up to 30W per port. The total PoE budget is 60W, allowing simultaneous power to multiple devices like IP cameras, wireless access points, or VoIP phones without exceeding the switch's capacity.
What is the switching capacity and layer support of this switch?
This switch offers a 10Gbps non-blocking switching capacity, ensuring full Gigabit throughput across all five ports. It operates at Layer 2, providing basic switching functions such as MAC address learning and forwarding, with support for IEEE 802.3 standards including 802.3af/at for PoE, 802.3u for Fast Ethernet, and 802.3ab for Gigabit Ethernet.
Can this switch be wall-mounted, and what are its dimensions?
Yes, the TPE-TG51g is designed for wall mounting with a compact form factor. Its dimensions are 4.76 inches wide, 2.95 inches deep, and 1.02 inches high (121 × 75 × 26 mm), and it weighs 8.68 ounces (246 grams). The metal housing includes mounting points for easy installation in tight spaces like network closets or behind desks.
Does this switch support VLAN or QoS features?
The switch includes a DIP switch that enables basic port-based VLAN isolation and QoS prioritization. VLAN isolation segments traffic between ports for improved security, while QoS prioritizes voice or video traffic to reduce latency. These features are configured manually via the DIP switch without a web interface.
What is the extended PoE range capability of this switch?
The TPE-TG51g can extend PoE+ signals up to 200 meters (656 feet) when operating at 10Mbps, allowing flexible placement of powered devices in large areas like warehouses or outdoor settings. This extended range is useful for deployments where power sources are distant, though note that speed reduces to 10Mbps at maximum distance.
Is this switch TAA compliant, and what warranty does it include?
Yes, the TPE-TG51g is TAA compliant, meeting U.S. and Canadian government procurement requirements for products manufactured in designated countries (Taiwan in this case). It comes with a lifetime warranty from TRENDnet, covering defects in materials and workmanship for the product's lifespan, providing long-term reliability for commercial deployments.
