Viewsonic CDE4312 43" 4K UHD Digital Signage Display - Android 9.0 - Quad-Core Cortex A53 - 2GB DDR4230 cd/m² - Wall Mountable
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Product Overview
The ViewSonic CDE4312 is a 43-inch 4K UHD digital signage display engineered for commercial environments where visual impact and reliable operation are critical. This all-in-one signage solution combines a high-resolution LCD panel with an integrated Android 9.0 computing platform, eliminating the need for external media players in many deployment scenarios.
Designed for 24/7 operation in retail stores, corporate lobbies, hospitality venues, and public information displays, the CDE4312 delivers sharp 3840 x 2160 resolution content with 230 cd/m² brightness. The Direct LED backlight ensures consistent illumination across the screen, while the 8 ms response time maintains clarity for dynamic content. With built-in Wi-Fi, Ethernet, and Bluetooth connectivity, this display supports both local and network-based content management.
Relevant factors for this section include Processor Model, Processor Speed, Processor Core, Standard Memory. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Technical Overview
At the core of the CDE4312 is a quad-core ARM Cortex A53 processor running at 1.50 GHz, paired with 2 GB of DDR4 SDRAM. This compute platform handles the Android 9.0 operating system smoothly, enabling app-based content playback, web browsing, and interactive applications without external hardware.
The display utilizes a 43-inch LCD panel with 3840 x 2160 4K UHD resolution at a 16:9 aspect ratio, delivering 2160p scan format content. The 230 cd/m² brightness rating ensures visibility in typical indoor commercial lighting conditions, while the 5,000:1 dynamic contrast ratio enhances depth in imagery. Connectivity includes two HDMI inputs for external sources, one USB 2.0 port for media playback, and serial RS232 for control system integration.
Key Product Advantages
This display eliminates complexity by combining high-resolution visual output with onboard computing in a single unit. The Direct LED backlight technology provides uniform brightness across the entire screen surface, while the 8 ms response time ensures smooth motion in video content and animations.
Integrated Android Platform
The built-in Android 9.0 operating system transforms this display into a standalone digital signage player. Install signage apps directly, stream content over Wi-Fi or Ethernet, and manage playback schedules without additional hardware.
Commercial-Grade Durability
Engineered for continuous operation in business environments, the CDE4312 supports 24/7 usage with reliable thermal management and component quality. The 3-year limited warranty provides long-term deployment confidence.
Deployment / Use Cases
The CDE4312 excels in environments where space efficiency and visual quality intersect. Its 43-inch screen size provides substantial presence without overwhelming smaller retail spaces or office areas, while the 4K resolution ensures text remains legible and images appear crisp even at close viewing distances.
With dual HDMI inputs, this display can switch between the integrated Android content and external sources like PCs, media players, or cameras. The serial RS232 port enables integration with control systems for scheduled power management or content switching in multi-display installations. The wall-mountable design with VESA compatibility allows for flush mounting against walls or on mounting arms in high-traffic areas.
Retail Digital Signage
Deploy in storefront windows, endcaps, or point-of-sale areas to showcase promotions, product demonstrations, and brand messaging with 4K clarity that captures customer attention.
Corporate Communications
Install in office lobbies, conference rooms, or employee common areas to display company announcements, meeting schedules, performance metrics, and welcome messages.
Localization and Operating System
The ViewSonic CDE4312 digital signage display operates on Android 9.0 Pie, providing a versatile platform for commercial deployments. This integrated operating system eliminates the need for external media players, allowing direct installation of digital signage applications, content streaming over network connections, and management of playback schedules through familiar Android interfaces.
Android 9.0 Pie supports a wide range of apps from the Google Play Store, enabling customization for specific signage needs such as interactive kiosks, real-time data feeds, or social media displays. The quad-core Cortex A53 processor and 2 GB of DDR4 SDRAM ensure smooth performance for app-based content, web browsing, and video playback, making this display a self-contained solution for dynamic digital signage environments.
For localization, the Android platform offers flexible language and regional settings, allowing content to be tailored to diverse audiences in retail, corporate, or public spaces. This adaptability, combined with the display's 4K resolution and connectivity options, ensures that the CDE4312 can deliver targeted messaging effectively in various commercial settings without requiring additional hardware.
Physical Profile
The CDE4312 features a slim 3.25-inch depth profile that minimizes protrusion when wall-mounted. With dimensions of 38.29 inches wide by 22.28 inches tall, the display presents a substantial visual canvas while maintaining a footprint suitable for most commercial installations. At approximately 14.55 pounds, the unit remains manageable for installers while providing the structural integrity needed for secure mounting.
- Width
- 38.29" (972.60 mm)
- Depth
- 3.25" (82.60 mm)
- Height
- 22.28" (566 mm)
- Weight
- 14.55 lb (6600 g)
What's in the Box
The CDE4312 arrives ready for installation with all necessary components included.
Package contents include CDE4312 Digital Signage Display Remote control Batteries Quick Start Guide Power cable HDMI cable Wall Mount Screws RS232 cable, CDE4312 Digital Signage Display. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- 43-inch 4K UHD LCD display with 3840 x 2160 resolution
- Integrated Android 9.0 operating system for standalone operation
- Quad-core Cortex A53 processor with 2GB DDR4 RAM
- 230 cd/m² brightness with Direct LED backlight technology
- Dual HDMI inputs plus USB and serial connectivity
- Built-in Wi-Fi, Ethernet, and Bluetooth wireless options
- Wall-mountable design with included mounting hardware
- Energy Star certified and RoHS compliant
- 3-year limited warranty for commercial deployment confidence
- Package includes remote, cables, and installation accessories
Specifications
| Specifications | |
|---|---|
| Manufacturer | ViewSonic Corporation |
| Manufacturer Part Number | CDE4312 |
| Brand Name | ViewSonic |
| Product Model | CDE4312 |
| Product Name | CDE4312 Digital Signage Display |
| Product Type | Digital Signage Display |
| Processor & Chipset | |
| Processor Model | Cortex A53 |
| Processor Speed | 1.50 GHz |
| Processor Core | Quad-core (4 Core) |
| Memory | |
| Standard Memory | 2 GB |
| Memory Technology | DDR4 SDRAM |
| Display & Graphics | |
| Number of Screens | 1 |
| Viewable Screen Size | 43" (1092.20 mm) |
| Display Screen Type | LCD |
| Response Time | 8 ms |
| Display Resolution | 3840 x 2160 |
| Backlight Technology | Direct LED |
| Graphics Controller Model | G52MP2 |
| Aspect Ratio | 16:9 |
| Video | |
| Scan Format | 2160p |
| Dynamic Contrast Ratio | 5,000:1 |
| Brightness | 230 cd/m² |
| Network & Communication | |
| Ethernet | Yes |
| Wireless LAN | Yes |
| Bluetooth | Yes |
| Interfaces/Ports | |
| USB | Yes |
| HDMI | Yes |
| Serial | Yes |
| Number of USB 2.0 Ports | 1 |
| Number of HDMI Inputs | 2 |
| Software | |
| Operating System | Android 9.0 Pie |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Physical Characteristics | |
| Mount Type | Wall Mountable |
| Height | 22.28" (566 mm) |
| Width | 38.29" (972.60 mm) |
| Depth | 3.25" (82.60 mm) |
| Weight (Approximate) | 14.55 lb (6600 g) |
| Miscellaneous | |
| Package Contents | CDE4312 Digital Signage Display Remote control Batteries Quick Start Guide Power cable HDMI cable Wall Mount Screws RS232 cable |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What screen size is listed?
It features a display specification of 43" (1092.20 mm), giving you clear visuals for work and media use.
What resolution or display format is specified?
It features a display specification of 3840 x 2160, giving you clear visuals for work and media use.
What refresh rate or brightness details are available?
The listed power specification is 230 cd/m², which helps position the unit for the right load level and installation role.
What input or connectivity options are listed?
Connectivity support is listed in the product specifications, including the relevant wireless or port options when available.
Does the display support VESA mounting or adjustment features?
It features a display specification of Wall Mountable, giving you clear visuals for work and media use.
What panel or display technology is mentioned?
It features a display specification of LCD, giving you clear visuals for work and media use.
