Zebra DS9308-SR4U2100AZW DS9300 Series 1D/2D Presentation Barcode Scanner - Cable Connectivity - Imager - Midnight Black
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This scanner utilizes an imager sensor for precise barcode capture, supporting 1D symbologies such as Code 39, Code 128, UPC/EAN, and GS1 DataBar, along with 2D formats including PDF417, DataMatrix, QR Code, and Aztec. It also handles OCR-A, OCR-B, MICR, and US currency recognition, making it suitable for diverse scanning applications beyond traditional barcodes.
Connectivity is provided through a cable with multiple host interface options: Serial, Keyboard Wedge, USB, and IBM 46XX. This flexibility ensures compatibility with various hardware setups, from legacy systems to modern POS terminals. The scanner operates in a standard range, balancing distance and accuracy for consistent performance in busy environments.
Relevant factors for this section include Connectivity Technology, Scanning Capability, Barcode Symbology Supported, Host Interface. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The DS9308-SR4U2100AZW excels in environments demanding reliable and fast barcode scanning. Its imager sensor ensures high first-read rates, reducing checkout times and minimizing errors in inventory management. The support for a broad range of symbologies, including emerging 2D codes and OCR, future-proofs your investment against evolving industry standards.
Durability and Design
Constructed with a desktop form factor and Midnight Black color, this scanner is built to withstand daily use in retail or warehouse settings. Its compact dimensions and lightweight design facilitate easy placement without occupying excessive counter space.
Environmental Compliance
This product is environmentally friendly and complies with Restriction of Hazardous Substances (RoHS) regulations, reflecting Zebra's commitment to sustainable manufacturing practices.
Deployment / Use Cases
Ideal for retail point-of-sale, this scanner speeds up checkout processes by quickly reading barcodes on products, coupons, and loyalty cards. Its ability to handle 2D codes like QR codes supports modern marketing and customer engagement initiatives, while OCR functionality aids in document processing.
In warehouse or logistics settings, the DS9308-SR4U2100AZW enhances inventory accuracy by scanning pallet labels, shipping manifests, and asset tags. The cable connectivity and multiple interface options allow seamless integration into existing systems, whether for real-time data entry or batch processing. Its standard range scanning is sufficient for most desktop applications, making it a versatile tool for various operational needs.
Relevant factors for this section include Connectivity Technology, Scanning Capability, Barcode Symbology Supported, Host Interface. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Physical Profile
The scanner measures 5.71 inches in height, 3.39 inches in width, and 3.27 inches in depth, with a weight of approximately 11.22 ounces. Its compact and lightweight design makes it easy to position on countertops or mounting stands, while the Midnight Black color blends seamlessly into professional environments. The desktop form factor ensures stability during use, reducing movement and improving scanning accuracy.
- Width
- 3.39" (86 mm)
- Depth
- 3.27" (83 mm)
- Height
- 5.71" (145 mm)
- Weight
- 11.22 oz (318 g)
Highlights
- 1D and 2D barcode scanning capability
- Imager sensor for reliable data capture
- Cable connectivity with Serial, Keyboard Wedge, USB, and IBM 46XX interfaces
- Supports a wide range of barcode symbologies and OCR
- Compact desktop form factor in Midnight Black
- Standard range scanning for flexible placement
- Environmentally friendly with RoHS compliance
- Three-year limited warranty for long-term reliability
Specifications
| Specifications | |
|---|---|
| Manufacturer | Zebra Technologies Corporation |
| Manufacturer Part Number | DS9308-SR4U2100AZW |
| Brand Name | Zebra |
| Product Series | DS9300 |
| Product Model | DS9308 |
| Product Name | DS9300 Series 1D/2D Presentation Barcode Scanner |
| Product Type | Barcode Scanner Kit |
| Technical Information | |
| Connectivity Technology | Cable |
| Scanning Capability | 1D,2D |
| Barcode Symbology Supported | 1D: Code 39 Code 128 Code 93 Codabar/NW7 Code 11 MSI Plessey UPC/EAN I 2 of 5 Korean 3 of 5 GS1 DataBar Base 32 (Italian Pharma) 2D: PDF417 Micro PDF417 Composite Codes TLC-39 Aztec DataMatrix MaxiCode QR Code Micro QR Han Xin Postal Codes securPharm DotCode Dotted DataMatrix OCR: OCR-A OCR-B MICR US currency |
| Image Sensor Type | Imager |
| Scanner Range | Standard Range |
| Interfaces/Ports | |
| Host Interface | Serial,Keyboard Wedge,USB,IBM 46XX |
| Physical Characteristics | |
| Form Factor | Desktop |
| Color Family | Black |
| Product Color | Midnight Black |
| Height | 5.71" (145 mm) |
| Width | 3.39" (86 mm) |
| Depth | 3.27" (83 mm) |
| Weight (Approximate) | 11.22 oz (318 g) |
| Miscellaneous | |
| Country of Origin | Vietnam |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What types of barcodes can this scanner read?
This scanner reads both 1D and 2D barcodes. Supported 1D symbologies include Code 39, Code 128, UPC/EAN, and GS1 DataBar, while 2D formats cover PDF417, DataMatrix, QR Code, and Aztec. It also supports OCR for text recognition and MICR for currency, making it versatile for various scanning needs.
How does this scanner connect to my system?
It uses cable connectivity with multiple host interface options: Serial, Keyboard Wedge, USB, and IBM 46XX. This allows compatibility with a wide range of hardware, from older POS systems to modern computers, ensuring easy integration into your existing setup.
What is the scanning range of this model?
The scanner operates at a standard range, which is typical for desktop presentation scanners. This range provides reliable barcode capture at common distances used in retail or inventory settings, balancing accuracy and flexibility for countertop or workstation use.
Is this scanner suitable for retail environments?
Yes, its imager sensor and support for diverse barcode types make it ideal for retail point-of-sale. It speeds up checkout processes by quickly reading product barcodes, coupons, and loyalty cards, while its durable design withstands daily use in busy stores.
What warranty does this product come with?
It includes a three-year limited warranty from Zebra, covering defects in materials and workmanship. This warranty provides assurance of quality and reliability, supporting long-term use in commercial applications.
Does this scanner support OCR and currency recognition?
Yes, it supports OCR-A, OCR-B, MICR, and US currency recognition in addition to barcode scanning. This functionality expands its use cases to include document processing and financial applications, enhancing its utility beyond traditional barcode reading.
